Sida 1/35

Model/Modelo: 796.8107#, 796.9107#

Kenmore Elite®

Steam Dryer

Secador con vapor

P/N MFL67731003

Sears Brand Management Corporation

Homan Estates, IL 60179 U.S.A.

www.kenmore.com

www.sears.com

Use & Care Guide

Manual de Uso y Cuidado

English / Español

# = color number, numero de color

INSTALLATION INSTRUCTIONS

CONNECTING GAS DRYERS

GASREQUIREMENTS(GASMODELSONLY)

To reduce the risk of re,

electric shock, or injury to persons when using this

appliance, follow basic precautions, including

the following:

WARNING:

•Gassupplyrequirements:Asshippedfromthe

factory,thisdryerisconguredforusewithnatural

gas(NG).Itcanbeconvertedforusewithpropane

(LP)gas.Gaspressuremustnotexceed8inches

watercolumnfor(NG),or13incheswatercolumnfor

(LP).

•Aqualiedserviceorgascompanytechnicianmust

connect the dryer to the gas service. Failure to follow

these instructions can result in re, explosion, or death.

•Isolate the dryer from the gas supply system by

closingitsindividualmanualshutovalveduringany

pressure testing of the gas supply. Failure to do so can

result in re, explosion, or death.

•Supplylinerequirements:Yourlaundryroommust

have a rigid gas supply line to your dryer. In the

UnitedStates,anindividualmanualshutovalve

MUSTbeinstalledwithinatleast6ft.(1.8m)ofthe

dryer, in accordance with the National Fuel Gas Code

ANSI Z223.1 or Canadian gas installation code CSA

B149.1.A⅛inchNPTpipeplugmustbeinstalled.

Failure to do so can result in re, explosion, or death.

•If using a rigid pipe, the rigid pipe should be ½ inch

IPS. If acceptable under local codes and ordinances

andwhenacceptabletoyourgassupplier,⅜inch

approved tubing may be used where lengths are less

than20ft.(6.1m).Largertubingshouldbeusedfor

lengthsinexcessof20ft.(6.1m). Failure to do so can

result in re, explosion, or death.

ELECTRICAL REQUIREMENTS FOR

GAS MODELS ONLY

•Do not, under any circumstances, cut or remove the

third(ground)prongfromthepowercord. Failure

to follow this warning can result in re, explosion, or

death.

•For personal safety, this dryer must be properly

grounded. Failure to follow this warning can result in

re, explosion, or death.

•Thepowercordofthisdryerisequippedwith

a3-prong(grounding)plugwhichmateswitha

standard3-prong(grounding)walloutlettominimize

the possibility of electric shock hazard from this

appliance. Failure to follow this warning can result in

re, explosion, or death.

•This dryer must be plugged into a 120-VAC, 60-Hz.

grounded outlet protected by a 15-ampere fuse or

circuit breaker. Failure to follow this warning can result

in re, explosion, or death.

•Where a standard 2-prong wall outlet is encountered,

it is your personal responsibility and obligation to

have it replaced with a properly grounded 3-prong

wall outlet. Failure to follow this warning can result in

re, explosion, or death.

•Connect the dryer to the type of gas shown on

the nameplate. Failure to do so can result in re,

explosion, or death.

•To prevent contamination of the gas valve, purge the

gas supply of air and sediment before connecting

the gas supply to the dryer. Before tightening the

connection between the gas supply and the dryer,

purge remaining air until the odor of gas is detected.

Failure to do so can result in re, explosion, or death.

•DONOTuseanopenametoinspectforgasleaks.

Useanoncorrosiveleakdetectionuid.Failure to do

so can result in re, explosion, or death.

•UseonlyanewAGA-orCSA-certiedgassupply

linewithexiblestainlesssteelconnectors. Failure to

do so can result in re, explosion, or death.

•Securely tighten all gas connections. Failure to do so

can result in re, explosion, or death.

•UseTeontapeorapipe-jointcompoundthatis

insolubleinpropane(LP)gasonallpipethreads.

Failure to do so can result in re, explosion,

or death.

•DO NOT attempt any disassembly of the dryer;

disassemblyrequirestheattentionandtoolsof

anauthorizedandqualiedservicetechnicianor

company. Failure to follow this warning can result in re,

explosion, or death.

3-prong

grounding

plug

3-prong

grounding

type wall

receptacle

Ensure proper

ground exists

before use.

To reduce the risk of re,

electric shock, or injury to persons when using this

appliance, follow basic precautions, including

the following:

•Installation and service must be performed by a

qualiedinstaller,serviceagency,orthegassupplier.

Failure to do so can result in re, explosion, or death.

•Useonlyanewstainlesssteelexibleconnectorand

anewAGA-certiedconnector.Failure to do so can

result in re, explosion, or death.

•Agasshutovalvemustbeinstalledwithin6ft.

(1.8m)ofthedryer. Failure to do so can result in re,

explosion, or death.

•Thedryerisconguredfornaturalgaswhen

shipped from the factory. Make sure that the dryer

isequippedwiththecorrectburnernozzleforthe

typeofgasbeingused(naturalgasorpropanegas).

Failure to do so can result in re, explosion, or death.

ConnectingtheGasSupply

NOTE: This dryer is congured from the factory set for

natural gas (NG). If dryer is to be used with propane

(LP) gas, it must be converted by a qualied

service technician.

Make sure that the gas supply to the laundry room is

turned OFF and the dryer is unplugged. Conrm that

the type of gas available in your laundry room is

appropriate for the dryer.

Remove the shipping cap from the gas tting at the

back of the dryer. Be careful not to damage the

threads of the gas connector when removing the

shipping cap.

Connect the dryer to your laundry room’s gas supply

using a new exible stainless steel connector with a ⅜

inches NPT tting.

NOTE: DO NOT use old connectors.

Securely tighten all connections between the dryer

and your laundry room’s gas supply.

Turn on the gas supply.

Check all pipe connections (both internal and external)

for gas leaks with a noncorrosive leak-detection uid.

Proceed to Venting the Dryer.

High-AltitudeInstallations

The BTU rating of this dryer is AGA-certied for

elevations below 10,000 feet.

If your gas dryer is being installed at an elevation

above 10,000 feet, it must be derated by a qualied

technician or gas supplier.

•Ifnecessary,thecorrectnozzle(fortheLPnozzlekit,

orderpartnumber383EEL3002D)shouldbeinstalled

byaqualiedtechnicianandthechangeshouldbe

noted on the dryer. Failure to do so can result in re,

explosion, or death.

•All connections must be in accordance with local

codes and regulations. Failure to do so can result in

re, explosion, or death.

•Gas dryers MUST exhaust to the outdoors. Failure to do

so can result in re, explosion, or death.

WARNING:

INSTALLATION INSTRUCTIONS

3/8" NP T Gas

Connection

Gas Supply

Shuto alveff V

AGA/CSA-Certiﬁed

Stainless Steel

Flexible Connector

1/8" NP T Pipe Plug

⅜ in. NPT Gas

Connection

⅛ in. NPT Pipe Plug

AGA/CSA-Certied

Stainless Steel Flexible

Connector

Gas Supply

Shuto Valve

CONNECTINGGASDRYERS(continued)
