For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below.
Refer to the model and serial numbers whenever you call upon your Kenwood dealer for information or service on the product.
Model KDC-MP172U
Serial number
US Residents Only
Register Online
Register your Kenwood product at http://www.kenwood.com/usa/
B5A-2089-00 (KN)© 2017 JVC KENWOOD Corporation
KDC-MP172U
CD-RECEIVER
INSTRUCTION MANUAL
AMPLI-TUNER LECTEUR DE CD
MODE D’EMPLOI
REPRODUCTOR DE DISCOS COMPACTOS RECEPTOR DE FM/AM
MANUAL DE INSTRUCCIONES
2
CONTENTS BEFORE USE
IMPORTANT
•
To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe
Warning and Caution in this manual.
•
Please keep the manual in a safe and accessible place for future reference.
WARNING
•
Do not operate any function that takes your attention away from safe driving.
•
Do not ingest the battery, Chemical Burn Hazard
The remote control supplied with this product contains a coin/button cell battery.
If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
Caution
Volume setting:
•
Adjust the volume so that you can hear sounds outside the car to prevent accidents.
•
Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level.
General:
•
Avoid using the external device if it might hinder safe driving.
•
Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
•
Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short circuit.
•
If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to evaporate.
•
Depending on the types of cars, the antenna will automatically extend when you turn on the unit with the antenna control wire connected
( 17)
. Turn off the unit or change the source to STANDBY when parking at a low ceiling area.
Remote control (RC-406):
•
Do not leave the remote control in hot places such as on the dashboard.
•
The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or equivalent type.
•
The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
How to read this manual
•
Operations are explained mainly using buttons on the faceplate.
•
English indications are used for the purpose of explanation. You can select the display language from the
[FUNCTION]
menu.
( 5)
•
[XX]
indicates the selected items.
•
( XX)
indicates references are available on the stated page.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Select the display language
and cancel the demonstration
2 Set the clock and date
3 Set the initial settings
RADIO 5
CD/USB/ANDROID 7
AUX 9
AUDIO SETTINGS 10
DISPLAY SETTINGS 11
TROUBLESHOOTING 12
REFERENCES 14
Maintenance
More information
INSTALLATION/
CONNECTION 15
SPECIFICATIONS 18
ENGLISH
ENGLISH 5
TUNER SETTING
PRESET TYPE NORMAL
:Memorizes one station for each preset button in each band
(FM1/FM2/FM3/AM).;
MIX
:Memorizes one station for each preset
button, regardless of the selected band.
SYSTEM
KEY BEEP ON
:Activates the keypress tone.;
OFF
:Deactivates.
SOURCE SELECT
BUILT-IN AUX ON
:Enables AUX in source selection.;
OFF
:Disables.
( 9)
CD READ 1
:Automatically distinguishes between audio file disc and music CD.;
2
:Forces to play as a music CD. No sound can be heard if an audio file disc
is played.
F/W UPDATE
UPDATE SYSTEM
F/W UP xxxx YES
:Starts upgrading the firmware.;
NO
:Cancels (upgrading is not
activated).
For details on how to update the firmware, visit
<www.kenwood.com/cs/ce/>.
CLOCK
CLOCK DISPLAY ON
:The clock time is shown on the display even when the unit is turned
off.;
OFF
:Cancels.
ENGLISH
Select the display language for
[FUNCTION]
menu and music information
if applicable.
By default,
[ENGLISH]
is selected.
ESPANOL
GETTING STARTED RADIO
Search for a station
1 Press repeatedly to select RADIO.
2 Press repeatedly (or press / on the remote
control) to select FM1/FM2/FM3/AM.
3 Press / (or press / on the remote control) to S T S
search for a station.
• : Press To change the searching method for /S T
repeatedly.
: Automatically search for a station.AUTO1
: Search for a preset station.AUTO2
: Manually search for a station.MANUAL
• : Press and hold one of the number buttons ( to ).To store a station 1 6
• : Press one of the number buttons ( to ) (or To select a stored station 1 6
press one of the number buttons ( to ) on the remote control).1 6
Direct Access Tuning
(using the remote control)
1 Press to enter Direct Access Tuning.DIRECT
2 Press the number buttons to enter a frequency.
3 Press to search for a station.
• To cancel, press or .DIRECT
• If no operation is done for 10seconds after step2, Direct Access Tuning
is automatically canceled.
6
RADIO
Other settings
1 Press the volume knob to enter
[FUNCTION]
.
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 2Repeat step until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
TUNER SETTING
AUTO
MEMORY
YES
:Automatically starts memorizing 6 stations with good reception.;
NO
:Cancels.
•
Selectable only if
[NORMAL]
is selected for
[PRESET TYPE]
.
( 5)
MONO SET ON
:Improves the FM reception, but the stereo effect may be lost.;
OFF
:Cancels.
NEWS SET ON
: The unit will temporarily switch to News Programme if available. ;
OFF
: Cancels.
REGIONAL ON
: Switches to another station only in the specific region using the “AF”
control.;
OFF
:Cancels.
AF SET ON
: Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF
:Cancels.
TI ON
:Allows the unit to temporarily switch to Traffic Information if available
(“TI” lights up).;
OFF
:Cancels.
PTY SEARCH
1
Turn the volume knob to select the available Program Type (see the
following), then press the knob.
2
Turn the volume knob to select the PTY language (
ENGLISH
/
FRENCH
/
GERMAN
), then press the knob.
3
Press
S T/
to start searching.
CLOCK
TIME SYNC ON
:Synchronizes the unit’s time to the Radio Data System station time.;
OFF
:Cancels.
Available Program Type for
[PTY SEARCH]
SPEECH
:
NEWS
,
AFFAIRS
,
INFO
(information),
SPORT
,
EDUCATE
,
DRAMA
,
CULTURE
,
SCIENCE
,
VARIED
,
WEATHER
,
FINANCE
,
CHILDREN
,
SOCIAL
,
RELIGION
,
PHONE IN
,
TRAVEL
,
LEISURE
,
DOCUMENT
MUSIC
:
POP M
(music),
ROCK M
(music),
EASY M
(music),
LIGHT M
(music),
CLASSICS
,
OTHER M
(music),
JAZZ
,
COUNTRY
,
NATION M
(music),
OLDIES
,
FOLK M
(music)
The unit will search for the Program Type categorized under
[SPEECH]
or
[MUSIC]
if selected.
•
[MONO SET]
/
[NEWS SET]
/
[REGIONAL]
/
[AF SET]
/
[TI]
/
[PTY SEARCH]
is selectable
only when the band is FM1/FM2/FM3.
• If the volume is adjusted during reception of traffic information or news
bulletin, the adjusted volume is memorized automatically. It will be
applied the next time traffic information or news bulletin is turned on.
ENGLISH
ENGLISH 9
CD/USB/ANDROID
Other settings
1 Press the volume knob to enter
[FUNCTION]
.
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 2Repeat step until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
USB
MUSIC DRIVE DRIVE CHANGE
:The next drive (
[DRIVE 1]
to
[DRIVE 5]
) is selected
automatically and playback starts.
Repeat steps
1
to
3
to select the following drives.
SKIP SEARCH 0.5%
/
1%
/
5%
/
10%
: While listening to ANDROID source, selects the skip
search ratio over the total files.
AUX
Preparation:
Select
[ON]
for
[BUILT-IN AUX]
in
[SOURCE SELECT]
.
( 5)
Start listening
1 Connect a portable audio player (commercially available).
2 Press repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Set the AUX name
While listening to a portable audio player connected to the unit...
1 Press the volume knob to enter
[FUNCTION]
.
2 Turn the volume knob to select
[SYSTEM]
, then press the knob.
3 Turn the volume knob to select
[AUX NAME SET]
, then press the knob.
4 Turn the volume knob to select an item, then press the knob.
AUX
(default)/
DVD
/
PORTABLE
/
GAME
/
VIDEO
/
TV
5 Press and hold to exit.
To return to the previous setting item, press .
Auxiliary input jack
Portable audio player
3.5mm (1/8") stereo mini plug with “L” shaped
connector (commercially available)
10
AUDIO SETTINGS
While listening to any source...
1 Press to enter AUD
[AUDIO CONTROL]
directly.
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 2Repeat step until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
(or using the remote control)
1 Press to enter AUD
[AUDIO CONTROL]
.
2 Press to select an item, then press .J / K
Default:
XX
AUDIO CONTROL
SUB-W LEVEL –15
to
+15
(
0
) Adjusts the subwoofer output level.
BASS LEVEL –8
to
+8
(
+2
)Adjusts the level to memorize for each source. (Before
making an adjustment, select the source you want
to adjust.)
MID LEVEL –8
to
+8
(
+1
)
TRE LEVEL –8
to
+8
(
+1
)
EQ PRO
(This setting is stored to
[USER]
.)
BASS ADJUST BASS CTR FRQ 60
/
80
/
100
/
200
: Selects the center frequency.
BASS LEVEL –8
to
+8
(
+2
):Adjusts the level.
BASS Q FACTOR 1.00
/
1.25
/
1.50
/
2.00
:Adjusts the quality factor.
BASS EXTEND ON
:Turns on the extended bass.;
OFF
:Cancels.
MID ADJUST MID CTR FRQ 0.5KHZ
/
1.0KHZ
/
1.5KHZ
/
2.5KHZ
:Selects the
center frequency.
MID LEVEL –8
to
+8
(
+1
):Adjusts the level.
MID Q FACTOR 0.75
/
1.00
/
1.25
:Adjusts the quality factor.
TRE ADJUST TRE CTR FRQ 10.0KHZ
/
12.5KHZ
/
15.0KHZ
/
17.5KHZ
:Selects the
center frequency.
TRE LEVEL –8
to
+8
(
+1
):Adjusts the level.
PRESET EQ DRIVE EQ
/
TOP40
/
POWERFUL
/
ROCK
/
POPS
/
EASY
/
JAZZ
/
NATURAL
/
USER
:Selects a preset equalizer suitable to the music genre. (Select
[USER]
to use the settings made in
[EQ PRO]
.)
[DRIVE EQ]
is a preset equalizer that reduces noise outside the car or
running noise of the tyres.
BASS BOOST LV1
/
LV2
/
LV3
:Selects your preferred bass boost level.;
OFF
:Cancels.
LOUDNESS LV1
/
LV2
:Selects your preferred low and high frequencies boost to
produce a well-balanced sound at a low volume level.;
OFF
:Cancels.
SUBWOOFER SET ON
:Turns on the subwoofer output.;
OFF
:Cancels.
ENGLISH
12
DISPLAY SETTINGS
Default:
XX
DISPLAY
DIMMER
Dim the illumination.
ON
:Dimmer is turned on.;
OFF
:Cancels.
DIMMER TIME
:Set the dimmer on and off time.
1
Turn the volume knob to adjust the
[ON]
time,
then press the knob.
2
Turn the volume knob to adjust the
[OFF]
time,
then press the knob.
(Default:
[ON]
:
6:00PM
;
[OFF]
:
6:00AM
)
BRIGHTNESS
1
Select a zone. (See illustration on page 11.)
2
0
—
31
: Select your preferred brightness level
for the selected zone.
TEXT SCROLL AUTO
/
ONCE
:Select whether to scroll the display
information automatically, or scroll only once.;
OFF
:Cancels.
TROUBLESHOOTING
Symptom Remedy
General
Sound cannot be heard.
•
Adjust the volume to the optimum level.
•
Check the cords and connections.
“MISWIRING CHECK WIRING
THEN PWR ON” appears.
Turn the power off, then check to be sure the terminals of the speaker
wires are insulated properly. Turn the power on again.
“PROTECTING SEND SERVICE”
appears.
Send the unit to the nearest service center.
•
Sound cannot be heard.
•
The unit does not turn on.
•
Information shown on the
display is incorrect.
Clean the connectors.
( 14)
The unit does not work at all. Reset the unit.
( 3)
Radio
•
Radio reception is poor.
•
Static noise while listening to
the radio.
Connect the antenna firmly.
CD/USB
Disc cannot be ejected. Press and hold
M
to forcibly eject the disc. Be careful not to drop the disc
when it is ejected. If this does not solve the problem, reset the unit.
( 3)
Noise is generated. Skip to another track or change the disc.
Tracks do not play back as you
intended them to play.
Playback order is determined when files are recorded.
“READING” keeps flashing. Do not use too many hierarchical levels or folders.
Elapsed playing time is not
correct.
This is caused by how the tracks are recorded.
Correct characters are not
displayed (e.g. album name).
•
This unit can only display uppercase letters, numbers, and a limited
number of symbols.
•
Depending on the display language you have selected
( 5)
, some
characters may not be displayed correctly.
“NA FILE” Make sure the disc contains supported audio files.
( 14)
“NO DISC” Insert a playable disc into the loading slot.
ENGLISH
ENGLISH 13
Symptom Remedy
CD/USB
“TOC ERROR” Make sure the disc is clean and inserted properly.
“PLEASE EJECT” Reset the unit. If this does not solve the problem, consult
your nearest service center.
“NO DEVICE” Connect a USB device, and change the source to USB again.
“COPY PRO” A copy-protected file is played.
“NA DEVICE” Connect a supported USB device, and check the
connections.
“NO MUSIC” Connect a USB device that contains playable audio files.
ANDROID
•
Sound cannot
be heard during
playback.
•
Sound output only
from the Android
device.
•
Reconnect the Android device.
•
If in
[HAND MODE]
, launch any media player application
on the Android device and start playback.
•
If in
[HAND MODE]
, relaunch the current media player
application or use another media player application.
•
Restart the Android device.
•
If this does not solve the problem, the connected Android
device is unable to route the audio signal to unit.
( 14)
Cannot playback at
[BROWSE MODE]
.
•
Make sure KENWOOD MUSIC PLAY APP is installed on the
Android device.
( 7)
•
Reconnect the Android device and select the appropriate
control mode.
•
If this does not solve the problem, the connected Android
device does not support
[BROWSE MODE]
.
( 14)
“NO DEVICE” or
“READING” keeps
flashing.
•
Switch off the developer options on the Android device.
•
Reconnect the Android device.
•
If this does not solve the problem, the connected Android
device does not support
[BROWSE MODE]
.
( 14)
TROUBLESHOOTING
Symptom Remedy
ANDROID
Playback is intermittent
or sound skips.
Turn off the power saving mode on the Android device.
“ANDROID ERROR”/
“NADEVICE”
•
Reconnect the Android device.
•
Restart the Android device.
Muting upon the reception of a phone call
Connect the MUTE wire to your telephone using a commercial telephone accessory.
( 17)
When a call comes in, “CALL” appears.
(The audio system pauses.)
•
To continue listening to the audio system during a call, press . “CALL” disappears
and the audio system resumes.
When the call ends, “CALL” disappears.
(The audio system resumes.)
ENGLISH 17
Wiring connection
Fuse (10A)
Output terminals
Antenna terminal
Car fuse box
Car fuse box
Battery
Ignition switch Blue/White
(Power control wire/
Antenna control wire)
(12V 350mA)
Light blue/yellow
(Steering remote
control wire)
Red
(Ignition wire)
Yellow
(Battery wire)
Black (Ground wire)
To the metallic body or chassis of the car
To the power control terminal when using
the optional power amplifier or to the
antenna control terminal in the vehicle
Brown
(Mute control wire)
White
Gray
Green
Purple
White/Black
Gray/Black
Green/Black
Purple/Black
To the terminal that is grounded when the
telephone rings or during conversation
( 13)
(To connect the Kenwood navigation
system, refer your navigation manual.)
To front speaker (left)
To rear speaker (left)
To front speaker (right)
To rear speaker (right)
If no connections are made, do not let the wire come out from the tab.
To the steering wheel remote control
adapter
When connecting to an external amplifier, connect
its ground wire to the car’s chassis to avoid damaging
the unit.
IMPORTANT:
We recommend installing the unit with a
commercially available custom wiring harness specific
for your car and leave this job to professionals for your
safety. Consult your car audio dealer.
INSTALLATION/CONNECTION

Produktspecifikationer

Varumärke: Kenwood
Kategori: CD-spelare/brännare
Modell: KDC-MP172U

Behöver du hjälp?

Om du behöver hjälp med Kenwood KDC-MP172U ställ en fråga nedan och andra användare kommer att svara dig


CD-spelare/brännare Kenwood Manualer

Kenwood

Kenwood K-575BT-S Bruksanvisning

1 September 2024
Kenwood

Kenwood KDC-MP382BT Bruksanvisning

24 Augusti 2024
Kenwood

Kenwood KDC-MP378BT Bruksanvisning

20 Augusti 2024
Kenwood

Kenwood KDC-MP172U Bruksanvisning

16 Augusti 2024
Kenwood

Kenwood KDC-MP145 Bruksanvisning

31 Juli 2024
Kenwood

Kenwood eXcelon KDC-X994 Bruksanvisning

30 Juli 2024
Kenwood

Kenwood KDC-BT645U Bruksanvisning

29 Juli 2024

CD-spelare/brännare Manualer

Nyaste CD-spelare/brännare Manualer

Proscan

Proscan PRCD1025 Bruksanvisning

10 Mars 2025
Proscan

Proscan PCD300-BLACK Bruksanvisning

5 Mars 2025
Atoll

Atoll CD100 Bruksanvisning

20 Februari 2025
Atoll

Atoll CD200 Bruksanvisning

20 Februari 2025
AVM

AVM CD 30.3 Bruksanvisning

20 Februari 2025
AVM

AVM Evolution CD 3.2 MKII Bruksanvisning

20 Februari 2025
Atoll

Atoll CD50 Bruksanvisning

20 Februari 2025
Atoll

Atoll DR100 Bruksanvisning

20 Februari 2025
Gold Note

Gold Note CD-1000 MK II Bruksanvisning

20 Februari 2025
Marantz

Marantz SA-12SE Bruksanvisning

7 Februari 2025
