Key Digital Phantom KD-HD1X4PROK Bruksanvisning
Key Digital
hi-fi system
Phantom KD-HD1X4PROK
Läs nedan 📖 manual på svenska för Key Digital Phantom KD-HD1X4PROK (12 sidor) i kategorin hi-fi system. Denna guide var användbar för 12 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/12

Key Digital® Systems 521 East 3rd Street Mount Vernon, NY 10553 :: ::
Phone 914.667.9700 Fax 914.668.8666 Web www.keydigital.com : : :
The Experts in Digital Video Technology and Solutions ™
Key Digital®, led by digital video pioneer Mike Tsinberg,
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital
®
is at the forefront of the video industry for Home Theater
Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers.
Rev 0 – Jan 2015
HDMI Distribution Amplifiers,
Audio De-embedders of Coaxial Digital Audio
& Analog L/R, support Ultra HD/4K
KD-HD1x2ProK KD-HD1x4ProK


4 1
Introduction
Key Digital® Phantom Series™ HDMI Distribution Amps are designed and engineered to
offer best quality in class, performance, and reliability. Phantom Series
™ Distribution Amps
support all HD and SD video standards, including Ultra HD/4K, 3D and 1080p/60.
KD-HD1x2ProK / KD-HD1x4ProK units feature status-monitoring LEDs, and are capable
of de-embedding HDMI audio for external distribution. The Phantom Series
™ distribution
amplifiers support multiple unit expandability, and are individually addressable.
Key Features
HDMI Distribution:
1 HDMI source to 2/4 HDMI outputs
Resolution Support: SD, HD, and VESA up to UHD/4K (4096x2160/60/30/24 or
3840x2160/60/30/24)
Ultra HD/4K: Supports Ultra HD/4K Signal transmission
3D Ready:
Capability to pass 3D stereoscopic signal formats
Audio De-Embedder:
Can de-embed audio from the HDMI input and send it to
external digital or analog audio outputs
Hot Plug Detection Control:
Enables integrator to choose if active signal voltage
is forced to connected input device
Full Buffer System™
:
Manages TMDS re-clocking / signal re-generation, HDCP
authentication to source & display, and EDID Control handshake
EDID:
Internal library with 16 default EDID congurations for input,
in addition to native EDID data for any Output/Display
Cascading Units:
Up to 64 outputs or displays
Lossless Compressed Digital Audio:
Dolby® TrueHD, Dolby® Digital Plus and
DTS-HD Master Audio™
Deep Color Support:
Up to 12 bits/color
I2C Communication:
EDID and HDCP authentication to Source
Licensing:
Fully licensed and compatible with all HDMI and HDCP technologies
Control:
Front status LEDs and RS-232 control
Major Control System Support:
Compass Control®, AMX®, Control4®
, Crestron®, Extron,
Leviton®, RTI®, Savant, URC®, etc.
Signal rates:
up to 3.4 Gb per second
Firmware upgradable
Rack mountable
Accessories
External power supply: 5V 2A
HDMI Lacing Clips
Rack Ears
Operating Instructions
Warranty Card
Always follow the instructions provided in this Operating Manual.
© 2015 Key Digital, Inc. All rights reserved.
Table of Contents
Introduction 1 ...............................................................
Quick Setup Guide 2..........................................................
Installation and Operation 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVI Applications 3............................................................
Settings 4 ..................................................................
RS-232 Commands and Protocol 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specications.............................................................. 7
Important Product Warnings & Safety Instructions: 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Contact Key Digital
®
.................................................. 9
Warranty Information 9 ........................................................
