www.khind.com.my
model / 型号 FZF252D / FZF362D
P/N: 40-50557-00
This manual is also available online
Freezer-frid /
冷冻柜
/
Peti Dingin Beku
Instruction Manual / Buku Panduan说明指示书/
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / Mustahak重要/
1
Specifications
Note : Specifications are subject to change without prior notice.
Model Number
Product External Dimension (mm) L
W
H
Product Internal Dimension (mm)
Freezer/Fridge Compartment
Gross Freezer/Fridge Capacity (Litres)
Net Freezer/Fridge Capacity (Litres)
Door Type
Rated Voltage
Rated Current
Rated Power Input
Power Consumption
Temperature Control
Compressor Fan
Defrosting
Cooling System
Temperature range at 30˚C ambient
Compressor :Type - Hermatic
Basket Quantity
Door Lock & Key
Castors Quantity
Net Weight
Gross Weight
Carton Dimension (mm)
L
W
H
FZF252D
Lifting
1195
620
930
900
1155
580
129L/129L
126L/126L
1/6HP
1
Yes
4
52kg
58kg
220-240V~ 50Hz
1.5A
125W
1.05kW.h/24h
Mechanical
Mechanical
Direct
Freezer: -22˚C ~ -27˚C
Fridge: -2˚C ~ -6˚C
530/530
498/498
432/432
R134a
2
Yes
FZF362D
Lifting
1490
700
930
915
1450
624
226L/146L
220L/142L
Total Gross Capacity (Litres)
Total Net Capacity (Litres)
258L
252L
372L
362L
1/5HP
1
Yes
4
65kg
72kg
220-240V~ 50Hz
1.75A
200W
1.36kW.h/24h
Mechanical
Mechanical
Direct
Freezer: -22˚C ~ -27˚C
Fridge: -2˚C ~ -6˚C
650/485
624/624
474/474
R134a
2
Yes
Refrigerant
Door Quantity
Yes Yes
Sliding Glass Door
L
W
H
2
General Information
Part Identification
1. Power Indicator Light - Red
2. Compressor Running Indicator
Light - Green
3. Thermostat Control Knob
4. Ventilation Panel
5. Handle with Key Lock
6. Basket
7. Freezer Door
8. Castors
9. Sliding Glass Door
1. The refrigerating system for this freezer is mainly composed of fully-closed refrigerating compressor, an
interior evaporator, closely compacted, properly processed with a good cooling result, it is convenient for
use, quiet and saves on electricity.
2. The hard Polyaminiester foam (made from spot high-pressured foaming) is used for the thermal insulation
which result in good performance and durability.
3. The interior door case is non-poisonous and odourless and formed by easy to clean ABS plastic. It is made of
a specially treated embossed aluminium sheet, which result in a generally good clean looking and durable
unit.
4. The cabinet and door are made of imported cold-rolled sheets which have been bonderized and
electrostatic-painted, is consistent in thickness, corrosion resistant, flexible and scratch resistant.
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
3. Must use separate, well-earthed and 3 core cable & plug top.
4. Do not squeeze, fold, knot or damage the cord.
5. Keep children away from package and its parts. Danger of suffocation from folding cartons and plastic film.
6. Do not climb, sit, stand or lean on the unit.
7. When repairing or cleaning the appliance, pull out the plug.
8. When pulling out the plug, do not pull cord to avoid cord damage.
9. The appliance should be recycled by appointed institutions. Personal handling may cause danger.
Please follow according to local regulations regarding the disposal of the appliance for its flammable
blowing gas.
10. This appliance is intended for household used only, do not use outdoors.
4
6
7
3
5
21
8
9
Cautions
Safety and warning information
Reminder Before Use
Heat sources
Sunlight
<45
1. Keep as upright as possible during handling, tilt <45˚, never upside down or
horizontally and do not roll unit on an uneven surface at high speed.
2. The freezer should be placed in ventilation area avoiding direct sunlight. Heat
source and rain. There should be no corrosive gases in surrounding air.
3. Keep stable placing and adjusting the four castors when necessary.
4. All packaging material should be removed. Do not use bottom foam as
vibrator proof material.
3
The freezer should be placed on the even floor, preferably in a well ventilated room and as far away as possible
from any source heat. Any side of the freezer should be at least 4” from the wall so that the warm air from the
compressor motor and the mild heat from the cabinet’s exterior are all circulate freely.
Installation
Diagram 2
4”
4”
4” 4”
4
Cautions
DANGER
1. Do not put inside flammable & explosive material (e.g. alcohol, gasoline etc).
Risk of explosion and fire!
2. Do not store bottled or canned drinks (especially carbonated drinks) in the freezer compartment.
Risk of explosion!
3. Do not touch food or metal container in the freezer compartment with wet hands. Do not put frozen food
straight from the freezer compartment into your mouth.
Risk of low-temperature burns!
WARNING
1. Do not damage the refrigerant circuit. Refrigerant leakage may ignite or cause eye injuries. Wash the eyes at
once and see a doctor.
2. Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer. (e.g. heaters, electric ice maker, etc.)
Do not use microwave oven, rice cooker and voltage regulator on the top of the appliance.
3. Keep ventilation holes, in the appliance enclosure or in the built-in structure, clear of obstruction.
4. To avoid hazard due to instability of the appliance, it must be fixed in accordance with the instructions.
Electrical Connection
Thermostat
Connect this appliance to the electricity supply using a 13A three pin plug (single receptacle power source)
WARNING - this appliance must be earthed. The wires in this mains lead are colored in accordance with the
following code:
Green Earth -
Blue
- Neutral
Brown Live -
Ensure that all connections are tight and that there are no loose strands or wire left free or insulations on the leads
trapped under the termina l in the plug, also that the cord clamp on the plug grips the outer sheath of the cord.
The inside temperature can be adjusted through the
thermostat control knob.
1. The higher means the lower temperature
Alert:
1) The temperature will be affected by:
Room temperature
How often the door is opened
How much food is stored
Position of the appliance
2) Please remember each time the lid is opened, cold air escapes and the internal temperature rises. Therefore,
never leave the lid open and ensure it is closed immediately after food is put in or removed.
3) DO NOT frequently power ON / OFF the freezer.
4) If there is an electricity cut-off, please wait for 5 minutes before operating the appliance again to avoid damage
to the compressor.
OFF
4
3
2
1
7
6
5
POWER RUNNING
Freezer
˚C
-14 ~ -19
-16 ~ -20
-18 ~ -20
-18 ~ -21
-19 ~ -23
-21 ~ -24
-24.5
Position
1
2
3
4
5
6
7
Fridge
˚C
4 ~ 10
2 ~ 7
1.5 ~ 3.5
1.3 ~ 2.5
1.2 ~ 2.3
-1 ~ 1
0 ~ -2
Freezer
˚C
-14 ~ -19
-15.5 ~ -20
-18 ~ -20
-18.5 ~ -21
-19 ~ -22.5
-20 ~ -24.5
-25
Fridge
˚C
4 ~ 10
3 ~ 8
1.5 ~ 3
1.5 ~ 2.6
1.2 ~ 2.3
-1 ~ 1
0 ~ -2
FZF252D FZF362D
