Sida 1/7
www.khind.com.my
model / 型号
VC66B
VC68P
P/N: 40-51316-00
Instruction Manual / Buku Panduan说明指示书/
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / Mustahak重要/
This manual is also available online.
Vacuum Cleaner
/
吸尘机
/
Pembersih Vakum
Cleaning & Maintenance
1. Always switch o the appliance, unplug from the mains and let the appliance cools down when the appliance
is not in use or before cleaning or before putting on or taking o parts.
2. It is recommended to regularly clean the Dust Container and HEPA Filter.
3. Do not clean the appliance’s surface with metal sourcing pads as it may scratch the surface or cause
electrical shock. Use only a damp soft cloth to clean it.
4. Do not immerse the appliance into the water or other liquids when cleaning.
5. Do not use abrasive chemicals cleaning solvents like petrol, thinner or benzene to clean the appliance.，
1 2
Safety Precaution Information
!
Safety & warning information
1. Read the instruction manual carefully and follow the instruction closely.
2. Use only the attached parts which are supplied by the manufacturer.
3. This appliance is intended for household use only, commercial use will void warranty.
4. Do not leave the appliance unattended while it is connected to the main power outlet.
5. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
6. Do not pull, lift or carry the appliance by its power cord. In order to avoid damages to the cord, do not pull
the cord around sharp corners and edges.
7. Always switch o the power before unplugging the unit from the socket. Do not unplug by pulling and
jerking the cord with force.
8. Do not handle the plug or the appliance with wet hands.
9. Do not vacuum the followings: corrosive or inammable liquids, lighted cigarette butts, ash or matches,
sharp objects or objects which could block and get stuck in the tube.
10. Do not use the appliance on wet surfaces
11. Make sure the household voltage is the same as that indicated on the rating label of the unit.
12. Do not use appliance without the lters.
13. Kept the appliance dry to protect against electric shock.
14. Keep appliance away from ovens and stoves etc.
15. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Note :
1) This appliance must only be used for domestic use.
2) It is not suitable for industrial or commercial use.
Parts Identications
Main Floor Brush
1. Plastic Plated Floor Brush (VC66B)
2. High Ecient Floor Brush (VC68P)
Tube
3. Plastic Tube p2-x2 (VC66B)
4. Retractable Aluminium Telescopic Tube (VC68P)
5. Dust Container
6. Dust Container Bottom Lid Release Lever
7. ON/OFF Power Button
8. Motor Body
9. Power Cord
* Pictures are for illustration purpose only.
Accessories
VC68P
VC66B
Crevice Nozzle Wall Mount Base
HEPA Filter
Filter Outer Shelf
2
4
5
9
6
7
8
13
5
9
6
7
8
34
Specications
How to Use
How to Use
1. Remove and assemble the extension tube and main Floor Brush or crevice nozzle from the box.
6. How to clean the HEPA lter from the Filter Outer Shelf.
7. Wall Mout Base for main unit and crevice brush.
2. Connect to the power supply.
3. Switch on the power supply and press the ON/OFF Power Button to start operating the vacuum.
4. The Dust Container should be emptied regulary to obtain consisten best results.
5. How to empty the dust container.
a. Insert the extention tube to the vacuum
body
b. Insert the main oor brush or crevice nozzle to
the extension tube
a. Remove the extension tube
then take it out
b. Press the release button c. Empty the dust container
* Specications are subject to change without prior notice.
Model
Voltage
Power
Suction power
Noise Level
Air Flow
Dust Container Capacity
Cable Length
Filtration Type
Net Weight
Product Dimension (LxWxH)mm
:
:
:
:
:
:
:
:
:
:
:
VC66B
220-240V~ 50-60Hz
600W
120W; 15kPa
80dB
78m /h
0.8L
5m
HEPA
2kg
375 x 135 x 220mm
VC68P
220-240V~ 50-60Hz
600W
120W; 15kPa
80dB
78m /h
0.8L
6.8m
HEPA
2.2kg
375 x 135 x 220mm
3 3
a. Turn the Filter Outer Shelf
anti-clockwise to detach
from the dust container
b. Remove the HEPA
Filter from the outer
shelf
c. Tap the HEPA lter
against the side of the
dustbin to remove
excess dust
a. Nail the wall mout base on the at surface and insert the main
unit into the base.
b. Place the crevice nozzle next to the main unit
d. Use the soft brush to
remove dirt from the
pleats
“tap”
“tap”
U
N
L
O
C
K
Note :
The appliance and the lter should be cleaned regularly in order to maintain the suction power.
