Sida 1/1
MR8 RECESSED BASIC TRIM - 15490CBR
MR8 RECESSED WITH COWL - 15491CBR
MR8 RECESSED 15492CBR LOUVERED -
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS
Lighted lamp is HOT!
WARNING — To reduce the risk of FIRE OR INJURY TO PERSONS.
1) urn off / unplug and allow to cool before replacing lamp.T
2) Lamp gets HOT quickly!
3) Do not touch hot lens or cowl.
4) Do not touch lamp or fixture if warm.
5) Do not look directly at lamp when on.
6) Keep lamp away from combustible materials.
7) Use only with wattage and lamp marked on fixture.
8) Do not touch the inner glass envelope of the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
9) Do not operate the fixture with a damaged or missing lens.
2)
SAFETY INSTRUCTIONS
READ THIS FIRST
KEEP THESE INSTRUCTIONS
This fixture is intended for installation in accordance with the National Electric
Code (NEC) and Local code specifications. Failure to adhere to these codes and
instructions may result in serious injury and/or property damage and will void the
warranty.
1) WARNING: This fixture is not to be installed within 10 feet (3M) of a pool, spa
or fountain.
This fixture is to be used only with a power unit (transformer) rated a maximum of
300 W (25 AMPS) 15 volts per circuits.
3) The #18 ga. fixture wire is not intended for direct burial or direct connection to
transformer.
4) Direct burial rated wire is to be buried a minimum of 6” (152mm) beneath the
surface of the ground. If additional Direct Burial wire is needed, contact NOTE:
your local Kichler®
landscape distributor.
• 8 GA wire can be purchased in length of 250’ (76 M), 15503-BK.
•10 GA wire can be purchased in length of 250’ (76 M), 15504-BK.
•12 GA wire can be purchased in lengths of 100’ (30 M), 15501-BK; 250’ (76 M),
15502-BK; 500’ (152M), 15505-BK; and 1000’ (304 M), 15506-BK.
5) Fixture shall not use a tungsten halogen lamp unless the fixture is marked for
use with such lamps.
6) Wiring connections must be made with approved/listed wire connection device(s)
suitable for the application. Do not exceed manufacturers’ wiring combination
specifications for size and quantity of conductors.
Eyelid cover
15491CBR
Open cover
15490CBR
1
2
3
4
5
6
7
8
Pre-mounting sleeve
1. Cover 2. Glass . Socket . Spring . O-Ring 3 4 5 6. Housing
7. Cable gland . 8Wire
Grill cover
15492CBR
CAUTION
WHEN INSTALLING KICHLER LANDSCAPE LIGHTING (LINE VOLTAGE OR LOW VOLTAGE), CARE SHOULD BE TAKEN TO KEEP CLEAR OF POTENTIALL Y COMBUSTIBLE
MATERIALS.
WHEN MAINTAINING THE FIXTURES, BE SURE TO REMOVE LEAVES, PINE NEEDLES, OR ANY DEBRIS THAT HAS ACCUMULATED ON THE GRASS CLIPPINGS, MULCH,
LIGHT BULB, LENS, OR BODY OF THE FIXTURE.
ASSEMBLY AND INSTALLATION
1. TURN OFF POWER
2. Determine desired location. Check area for obstructions such as sprinklers, plant material, etc. Assess soil conditions.
3. Unscrew the cover , then screw the cover back on. (Take spring out if you would like lamp to be and install lamp into socket
more .)recessed
4. approximatelyDig a hole approximately 1 " by " . This allows 2 deep 3 wider than the well light 3" of pea gravel or sand to
surround ABS housing.
a. For concrete applications, use a 1 3/4 inch core drill at least 6 inches deep.
5. Strip the two leads from luminaire pigtail wire. Using the wire connectors (not included), connect the leads from the
luminaires to the main supply cable leads. Allow 12-18" of extra wire (coiled inside the bottom of the well light) to allow for
lamp removal / replacement.
6. Place fixture at final height leaving 1-2 inches of the fixture above grade to minimize debris collection (in lawn areas they
should be flush with grade).
7. Install luminaire in hole and fill hole after installation with pea gravel or sand. Backfill and compact the soil around the fixture
thus securing it in the ground.
8. Power luminaire and check for proper operation.
9. Call Factory for additional installation options.
For warranty information please visit: http://www.landscapelighting.com/portal/warranty_page
Para informacion de la garantia por favor visite: www.landscapelighting.com/portal/warranty_page
Date Issued: 4/27/17
IS- -
15490 US
IS-15491-US
IS-15492-US
Weʼre here to help 844-542-4537
Hrs: M-F 8am to 6:30pm EST
