KK T KOLBE Küche nte chnik G mb H & Co. KG
Ohmstraße 17 | D-96175 Pettstadt | +49 (0) 9502 667930 | info@kolbe.de
Installation Manual
Tile Roof Hook 06 Mounting Structure
KK T KOLB E Küche nte ch nik G mb H & Co. KG
Ohmstraße 17 | D-96175 Pettstadt | +49 (0) 9502 667930 | info@kolbe.de
Catalog
1. Product Introduction 1
2. Installation Tools 1
3. Components 2
4. Installation Guide 3
4.1 Installation of Tile Roof Hook 3
4.2 Installation of Rail 4
4.3 Installation of Solar Panels 5
4.4 Installation of Grounding Lug 5
5. Installation Notes 6
5.1 Safety Precautions 6
5.2 Stainless Steel Fasteners Notes 6
5.3 Notes after Finishing Work 6
1
1. Product Introduction
Tile roof mounting kit allow solar panel installed on tile roof. It’s a smart and
simple PV mounting solution for residential projects. The main material of this
mounting structure is aluminum alloy AL6005-T5 and stainless steel SUS304.
The product has strong corrosion resistance. This mounting kit has high
pre-assembled characteristics and saves installation time and cost greatly.
Please kindly read the whole manual carefully before installation.
2. Installation Tools
String Electric tool
(M8/M10)
Hexagon sleeve
(M8/M10) Drilling Bit 9mm Tape measure
Marking pen Torque wrench
(M8)
6# hexagonal
wrench Monkey wrench Rubber Hammer
