Sida 1/8
QCS Series HC-49/U-S SMD 2-Pad
Freq. Range: 3.200 to 70.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +85°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QCL Series HC-49/U-S (short)
Freq. Range: 3.200 to 70.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +85°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QC4 Series HC-49/U-S SMD 4-Pad
Freq. Range: 3.200 to 70.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +85°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QTC4 Series QTC3 Series QTC2 Series 1.5x4.1 SMD 1.5x3.2 SMD 1.2x2.0 SMD
4.1±0.1
1.5 ± 0. 1 0.75 ± 0.11.3
3.3
0.6
1.1
3.4
1.9
1,2
max.0,60
1,5
0,8
0,7
0,8
0,550,55
2,0
0,7
1,5
0,7
3,2
max.0,65
1,8
1,51,0 1,0
QTP9 Series QTP8 Series QTP7 Series 4.0x9.6 Plastic SMD 3.8x8.7 Plastic SMD 1.4x6.9 Plastic SMD
1.35±0.05
6.90±0.10
6.70
1.40±0.10
0.55
0.40±0.10
0.30±0.10
Freq. Range: 32.768kHz • Tolerance: ±10ppm, ±20ppm, ±30ppm at 25°C • Stability: Inverse Parabolic
Operating Temp.: -40 to +85°C • Load Capacitance: 6pF, 7pf, 9pF, 12.5pF • Aging per Year: ±3ppm max. Custom Specication on request.
SUMMARY SPECIFICATIONS
QUARTZ CRYSTALS
METAL CAN PACKAGES
TUNING FORK CRYSTALS
CERAMIC & PLASTIC PACKAGES
SUMMARY SPECIFICATIONS
QC7A Series 5x7 4-Pad SMD
Also available in 2pad version (QC7B)
but not recommended for new design
Freq. Range: 6.000 to 150.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +105°C
-40 to 85°C • -40 to +125°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QC6A Series QC5A Series 3.5x6.0 4-Pad SMD 3.2x5.0 4-Pad SMD
Also available in 2pad version (QC5B)
but not recommended for new design
Freq. Range: 8.000 to 160.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +105°C
-40 to 85°C • -40 to +125°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
Also available in 2pad version (QC6B)
but not recommended for new design
Freq. Range: 8.000 to 150.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +105°C
-40 to 85°C • -40 to +125°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QC4A Series 2.5x4.0 4-Pad SMD
Freq. Range: 12.000 to 52.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +85°C
Load Capacitance: 10 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QC32 Series QC25 Series 2.5x3.2 4-Pad SMD 2.0x2.5 4-Pad SMD
Freq. Range: 16.000 to 50.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +105°C
-40 to 85°C • -40 to +125°C
Load Capacitance: 7 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
Freq. Range: 10.000 to 60.000MHz
Tolerance: ±10 to ±100ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +105°C
-40 to 85°C • -40 to +125°C
Load Capacitance: 7 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QC20 Series 1.6x2.0 4-Pad SMD
Freq. Range: 20.000 to 52.000MHz
Tolerance: ±10 to ±30ppm at 25°C
Stability: ±10 to ±100ppm
Operating Temp.: -20 to 70°C • -40 to +85°C
Load Capacitance: 7 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
QC16 Series 1.2x1.6 4-Pad SMD
Freq. Range: 24.000 to 40.000MHz
Tolerance: ±15 to ±30ppm at 25°C
Stability: ±15 to ±50ppm
Operating Temp.: -20 to 70°C • -40 to 85°C
Load Capacitance: 7 to 32pF
Aging per Year: ±3ppm max.
Custom Specication on request.
0.4 max.
#1 #2
#4 #3
2.5 ± 0.1
#1 #2
4.0 ± 0.1
#4 #3
0.7
#3#4
2.0
#2#1
0.8
0.9
SUMMARY SPECIFICATIONS
QUARTZ CRYSTALS
CERAMIC PACKAGES
