Sida 1/59
K R A M E R E L E C T R O N I C S L T D .
USER MANUAL
MODELS:
FC FC-21ETH, -22ETH and
FC-24ETH
Ethernet Controller
P/N: 2900-300221 Rev 6
Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3 Overview 4
4 Defining the FC-21ETH, FC-22ETH and FC-24ETH Ethernet Controllers 6
4.1 Defining the FC-21ETH Ethernet Controller 6
4.2 Defining the FC-22ETH Ethernet Controller 8
4.3 Defining the FC-24ETH Ethernet Controller 10
5 Initial Configuration and Use Overview 12
5.1 Configuring the FC-21ETH, FC-22ETH and FC-24ETH 13
5.2 Configuring a Virtual Port on the PC 14
5.3 Configuring an Ethernet Connection on the PC 14
6 Connecting the FC-21ETH, FC-22ETH and FC-24ETH 15
6.1 Connecting via Ethernet 17
6.2 Connecting to the Ethernet Controller via RS- 232 20
6.3 Connecting to a Controlled Device via the RS-485 Port 21
7 Remote Operation via the Web Pages 22
7.1 Browsing the FC-24ETH Web Pages 22
7.2 Connected Clients Page 24
7.3 Device Settings Page 25
7.4 Communication Page 26
7.5 Serial Port Settings Page 27
7.6 Security Page 28
7.7 Logs Page 30
7.8 About Us Page 31
8 Configuring and Maintaining the FC-21ETH, FC-22ETH and FC-24ETH 32
8.1 Selecting the RS-232 or RS-485 Serial Port 32
8.2 Terminating the RS-485 Bus 32
8.3 Activating DHCP 33
8.4 Resetting to the Factory Default Settings 33
8.5 Upgrading the Firmware 33
9 Technical Specifications 34
9.1 Data Handling Performance 35
9.2 Example Bandwidth Calculation 35
10 Default Communication Parameters 36
11 Kramer Protocol 3000 37
11.1 Kramer Protocol 3000 Syntax –37
11.2 Kramer Protocol 3000 Command List –40
11.3 Kramer Protocol 3000 Detailed Commands –41
11.4 Parameters 53
