P/N: 2900-301659 Rev 1 www.kramer .comav
USER MANUAL
MODEL:
KDS-100EN -100DEC / KDS
4K AVoIP H.264 / H.265 Encoder / Decoder

Kramer Electronics Ltd.
KDS-100 Series Contents –
2
Contents
Contents 2
Introduction 3
Getting Started 3
Overview 4
Typical Applications 5
Controlling your KDS-100 device 6
Dening the KDS- 7100
Dening KDS-100EN 7
Dening KDS-100DEC 9
Mounting KDS-100 11
Connecting KDS- 100 12
Connecting KDS-100EN to KDS-100DEC 12
Connecting RS- 232 13
Connecting the Audio/Input Output 14
Installing the SFP transceiver (optical SM/MM or copper) 14
Operating and Controlling KDS-100 Devices 15
Conguring the Network Switch 15
Using the Channel Selection Buttons 15
Operating via Ethernet 16
KDS-100EN: Using the Embedded Web Pages 19
Dashboard: Set channel and audio, view input signal 20
Streaming: Multicast settings and time to live 21
Encoding: Method, protocol, scaling, bitrate and more 22
EDID: Set display metadata 24
Gateway: RS-232 settings 25
Device: General device, network and time settings 26
Security: Passwords, HTTPS and 802.1X 29
About: Web version and contact details 32
KDS-100DEC: Using the Embedded Web Pages 33
Dashboard: Set channel and audio, view input signal 34
Video: Decoding method and output resolution 36
External Devices: Connecting External RTSP Streams 37
EDID: Set display metadata 39
Gateway: RS-232 settings 40
Device: General device, network and time settings 41
Security: Passwords, HTTPS and 802.1X 44
About: Web version and contact details 47
Upgrading Firmware 48
Technical Specications 49
KDS-100EN Specications 49
KDS-100DEC Specications 50
Default Communication Parameters 51
Protocol 3000 52
Understanding Protocol 3000 52
Protocol 3000 Commands 53
Result and Error Codes 64

Kramer Electronics Ltd.
KDS-100 Series Introduction –
3
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to https://www.kramerav.com/downloads/kds-100en or
https://www.kramerav.com/downloads/kds-100dec check for up- -date user manuals, to to
application programs, and to check if rmware upgrades are available (where appropriate).
Achieving Best Performance
• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
• Position your Kramer /
KDS-100EN KDS-100DEC away from moisture, excessive
sunlight and dust.
Safety Instructions
Caution:
• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• If not using PoE, use only the optional power cord supplied for the unit.
Produktspecifikationer
Varumärke: | Kramer |
Kategori: | AV extender |
Modell: | KDS-100DEC |
