P/N: 2900-300619 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
VM-10H2
4K HDMI 2.0 1:10 DA
Kramer Electronics Ltd.
VM-10H2 Contents –
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Controlling Your VM-10H2 3
Firmware Update 3
Defining the VM-10H2 4K HDMI 2.0 1:10 DA 4
Mounting VM-10H2 5
Connecting the VM-10H2 6
Connecting to VM-10H2 via RS-232 6
Operating the VM-10H2 7
Setting the DIP-Switches 7
Acquiring and Setting the Current EDID 8
Default EDID 9
Technical Specifications 11
Default Communication Parameters 11
Protocol 3000 12
Understanding Protocol 3000 13
Kramer Protocol 3000 Syntax 14
Protocol 3000 Commands 15
Kramer Electronics Ltd.
VM-10H2 Introduction –
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional a daily basis. In recent years, we on
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/VM-10H2 to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving the Best Performance
• For optimum range and performance, use the recommended Kramer cables available
at www.kramerav.com/product/VM-10H2.
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
• Position your Kramer away from moisture, excessive sunlight and dust. VM-10H2
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
Safety Instructions
Caution:
• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• Disconnect the power and unplug the unit from the wall before installing.
• Do not open the unit. High voltages can cause electrical shock! Servicing by qualified
personnel only.
• To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which located on the bottom of the unit.
