Sida 1/34
P/N: - Rev 4 2900 300856 www.KramerAV.com
USER MANUAL
MODEL:
VS-622DT
6x2 HDMI/HDBT Audio Matrix Switcher
VS-622DT Introduction –
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Controlling your VS-622DT 4
Dening VS-622DT 5
Mounting VS-622DT 7
Connecting VS-622DT 8
Connecting the Audio Outputs 10
Connecting to VS-622DT via RS-232 10
Connecting VS-622DT via the Ethernet Port 11
Operating VS-622DT via Front Panel Buttons 14
Capturing the EDID 14
Using the Web Pages 15
Switching and Setting Ports 17
Managing EDID 23
Copying EDID from an Output to an Input 23
Copying EDID from an Input to an Input 26
Copying EDID from the Default EDID to an input 28
Loading a Customized EDID from a File 28
Changing the Device Settings 29
Saving and Loading Settings 29
Resetting to Factory Default Parameters 30
Managing Ethernet Settings 30
Setting the Date and Time 34
Upgrading the Firmware 35
Setting Authentication 37
Managing IO Gateway Settings 40
Conguring RS-232 Signal Tunneling 40
Setting GPI/O Parameters 42
Setting Relays 47
Conguring Room Automation 48
Viewing General Information 49
Technical Specications 50
Default Parameters 51
Protocol 3000 52
Understanding Protocol 3000 53
Kramer Protocol 3000 Syntax 54
Protocol 3000 Commands 54
Kramer Electronics Ltd.
VS-622DT Introduction –
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Our 1,000-plus different models now appear in 15 groups that are clearly dened by function:
GROUP 1: Distribution Ampliers; GROUP 2: Switchers and Routers; GROUP 3: Control
Systems; GROUP 4: Format & Standards Converters; GROUP 5: Range Extenders &
Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scalers; GROUP 8: Cables and
Connectors; GROUP 9: Room Connectivity; GROUP 10: Mounting and Rack Adapters;
GROUP 11: Sierra Video; GROUP 12: Digital Signage; GROUP 13: Audio; GROUP 14:
Collaboration; and GROUP 15: KM & KVM Switches.
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/VS-622DT to check for up- -date user manuals, to
application programs, and to check if rmware upgrades are available (where appropriate).
Achieving the Best Performance
• e only good quality connection cables (we recommend Kramer high-performance, Us
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
• Position your Kramer away from moisture, excessive sunlight and dust. VS-622DT
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning:
Use only the power cord that is supplied with the unit.
Warning:
Do not open the unit. High voltages can cause electrical shock! Servicing by qualied
personnel only.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
