Kramer Electronics, Ltd.
USER MANUAL
Models:
VP-200XLTHD XGA Line Amp/CAT 5 Transmitter
VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter
VP-5R CAT 5 Receiver/1:5 VGA/UXGA Distributor
Contents
i
Contents
1 1Introduction
2 1Getting Started
2.1Quick Start 2
3Overview 4
3.1About the Power Connect™ Feature 4
3.2Shielded Twisted Pair/Unshielded Twisted Pair 4
3.3Recommendations for Achieving the Best Performance 5
4 6Defining the VP-200XLTHD XGA Line Amp/CAT 5 Transmitter
5Defining the VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter 8
6Defining the VP-5R CAT 5 Receiver/1:5 VGA/UXGA Distributor 10
7Connecting the VP-200XLTHD 11
8 13Connecting the VP-5THD and the VP-5R
8.1Wiring the CAT 5 LINE IN/LINE OUT RJ-45 Connectors 15
9Technical Specifications 15
Figures
Figure 1: VP-200XLTHD XGA Line Amp/CAT 5 Transmitter 6
Figure 2: VP-200XLTHD XGA Line Amp/CAT 5 Transmitter Underside 7
Figure 3: VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter 8
Figure 4: VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter Underside 9
Figure 5: VP-5R CAT 5 Receiver/1:5 VGA/UXGA Distributor 10
Figure 6: VP-5R CAT 5 Receiver/1:5 VGA/UXGA Distributor Underside 11
Figure 7: Connecting the VP-200XLTHD 12
Figure 8: Connecting the VP-5THD and the VP-5R 14
Figure 9: TP Connector 15
Tables
Table 1: VP-200XLTHD XGA Line Amp/CAT 5 Transmitter Features 7
Table 2: VP-200XLTHD XGA Line Amp/CAT 5 Transmitter Underside Features 7
Table 3: VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter Features 9
Table 4: VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter Underside Features 9
Table 5: VP-5R CAT 5 Receiver/1:5 VGA/UXGA Distributor Features 10
Table 6: VP-5R CAT 5 Rece Underside Features iver/1:5 VGA/UXGA Distributor 11
Table 7: TP Connector Pinout 15
Table 8: Technical Specifications of the VP-200XLTHD (with 30m CAT 5 cable) 15
Table 9: Technical Specifications of the VP-5THD (with 60m CAT 5 cable) 16
Table 10: Technical Specifications of the VP-5R (with 30m CAT 5 cable) 16
Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 1,000-plus different models now
appear in 11 groups1 that are clearly defined by function.
Thank you for purchasing the Kramer: VP-200XLTHD XGA Line Amp/CAT 5
Transmitter, VP-5THD 1:4 VGA/UXGA Distributor/CAT 5 Transmitter, and/or
VP-5R CAT 5 Receiver/1:5 VGA/UXGA Distributor which are ideal for:
• Presentation and multimedia applications
• Long range graphics distribution for schools, hospitals, security, and stores
The package includes:
• One or more VP-200XLTHD, and/or VP-5THD, and/or VP-5R
• Power cord2
• This user manual3
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high-performance high-resolution cables4
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 We recommend that you use only the power cord supplied with this device
3 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com
4 The complete list of Kramer cables is available at http://www.kramerelectronics.com
