P/N 07.04.924.00 © 2019 Hatco Corporation
Do not operate this equipment unless you
have read and understood the contents
of this manual! Failure to follow the
instructions contained in this manual
may result in serious injury or death.
This manual contains important safety
information concerning the maintenance,
use, and operation of this product. If
you’re unable to understand the contents
of this manual, please bring it to the
attention of your supervisor. Keep this
manual in a safe location for future
reference.
English = p 2
WARNING
No opere este equipo al menos que haya
leído y comprendido el contenido de este
manual! Cualquier falla en el seguimiento
de las instrucciones contenidas en
este manual puede resultar en un serio
lesión o muerte. Este manual contiene
importante información sobre seguridad
concerniente al mantenimiento, uso y
operación de este producto. Si usted
no puede entender el contenido de
este manual por favor pregunte a su
supervisor. Almacenar este manual en
una localización segura para la referencia
futura.
ADVERTENCIA
Ne pas utiliser cet équipement sans avoir
lu et compris le contenu de ce manuel ! Le
non-respect des instructions contenues
dans ce manuel peut entraîner de
graves blessures ou la mort. Ce manuel
contient des informations importantes
concernant l’entretien, l’utilisation et le
fonctionnement de ce produit. Si vous ne
comprenez pas le contenu de ce manuel,
veuillez le signaler à votre supérieur.
Conservez ce manuel dans un endroit
sûr pour pouvoir vous y référer plus tard.
Français = p 13
AVERTISSEMENT
Waffle Makers
Gaufriers
KWM Series • Série KWM
Installation and Operating Manual
Manuel d’installation et d’utilisation
2Form No. KWMM-0519
English
INTRODUCTION
Waffle Makers cook continuous, excellent-quality waffles
for commercial kitchens and display cooking locations. The
adjustable temperature control enables operators to cook
consistent quality waffles from a variety of different batters.
Exclusive, removable top and bottom heating element packs
provide exceptional heat distribution over the entire waffle plate
surface. The Waffle Maker’s easy clean System® provides
quick removal and easy cleaning of the waffle plates.
Waffle Makers are products of extensive research and field
testing. The materials used were selected for maximum
durability, attractive appearance, and optimum performance.
Every unit is inspected and tested thoroughly prior to shipment.
This manual provides installation, safety, and operating
instructions for Waffle Makers. Hatco recommends all
installation, operating, and safety instructions appearing in this
manual be read prior to installation or operation of a unit.
Safety information that appears in this manual is identified by
the following signal word panels:
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE
NOTICE is used to address practices not related to
personal injury.
Important Owner Information ..............................................2
Introduction 2 ...........................................................................
Important Safety Information ..............................................3
Model Description ................................................................4
Model Designation ...............................................................4
Specifications 5 .......................................................................
Plug Configurations .............................................................5
Electrical Rating Charts .......................................................5
Dimensions 5 ..........................................................................
Installation 6 .............................................................................
General 6 ................................................................................
Operation 7 ...............................................................................
General 7 ................................................................................
Control Panel .......................................................................7
Seasoning the Waffle Plates ...............................................7
Operating the Unit ...............................................................8
Maintenance 9 ..........................................................................
General 9 ................................................................................
Daily Cleaning .....................................................................9
Removing the Waffle Plates ..............................................10
Troubleshooting Guide ...................................................... 11
Options and Accessories ..................................................12
Limited Warranty ................................................................12
Authorized Parts Distributors Back Cover ...........................
IMPORTANT OWNER INFORMATION
Record the model number, serial number, voltage, and purchase
date of the unit in the spaces below (specification label located
on the bottom the unit). Please have this information available
when calling Hatco for service assistance.
Model No. ________________________________________
Serial No. _________________________________________
Voltage ___________________________________________
Date of Purchase ___________________________________
Register your unit!
Completing online warranty registration will prevent delay in
obtaining warranty coverage. Access the Hatco website at
www.hatcocorp.com, select the Support pull-down menu,
and click on “Warranty”.
Business
Hours: 7:00 am to 5:00 pm Monday–Friday,
Central Time (CT)
(Summer Hours June to September— :
7:00 am pm to 5:00 Monday–Thursday
7:00 am pm to 4:00 Friday)
Telephone: 800-558-0607; 414-671-6350
E-mail: support@hatcocorp.com
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling 800-558-0607.
Additional information can be found by visiting our web site at
www.hatcocorp.com.
CONTENTS
Form No. KWMM-0519 3
English
IMPORTANT SAFETY INFORMATION
WARNING
ELECTRIC SHOCK HAZARD:
• Plug unit into a properly grounded electrical receptacle
of the correct voltage, size, and plug configuration. If
plug and receptacle do not match, contact a qualified
electrician to determine and install proper voltage and
size electrical receptacle.
• Turn OFF power switch, unplug power cord, and
allow unit to cool before performing any cleaning,
adjustments, or maintenance.
• Unit is not weatherproof. Locate unit indoors where
ambient air temperature is a maximum of 104°F (40°C).
• DO NOT submerge or saturate with water. Unit is not
waterproof. Do not operate if unit has been submerged
or saturated with water.
• Do not steam clean or use excessive water on unit.
• This unit is not “jet-proof” construction. Do not use jet-
clean spray to clean this unit.
• Do not clean unit when it is energized or hot.
• Do not allow liquids to spill into unit.
• Do not pull unit by power cord.
• Do not allow power cord to hang over edge of counter.
• Discontinue use if power cord is frayed or worn.
• Do not attempt to repair or replace a damaged power
cord. Cord must be replaced by Hatco, an Authorized
Hatco Service Agent, or a person with similar
qualifications.
• This unit must be serviced by qualified personnel only.
Service by unqualified personnel may lead to electric
shock or burn.
• Use only Genuine Hatco Replacement Parts when
service is required. Failure to use Genuine Hatco
Replacement Parts will void all warranties and may
subject operators of the equipment to hazardous
electrical voltage, resulting in electrical shock or burn.
Genuine Hatco Replacement Parts are specified to
operate safely in the environments in which they are
used. Some aftermarket or generic replacement parts
do not have the characteristics that will allow them to
operate safely in Hatco equipment.
EXPLOSION HAZARD: Do not store or use gasoline or
other flammable vapors or liquids in the vicinity of this or
any other appliance.
Make sure all operators have been instructed on the safe
and proper use of the unit.
This unit is not intended for use by children or persons
with reduced physical, sensory, or mental capabilities.
Ensure proper supervision of children and keep them away
from the unit.
Never leave unit unattended during use.
Do not use unit for any purpose other than for which it is
designed.
WARNING
FIRE HAZARD:
• Locateunitaminimumof8″(203mm)fromcombustible
walls and materials. If safe distances are not maintained,
discoloration or combustion could occur.
• Do not obstruct air ventilation openings on outer
housing of unit. Unit combustion or malfunction may
occur.
This unit has no “user-serviceable” parts. If service
is required on this unit, contact an Authorized Hatco
Service Agent or contact the Hatco Service Department at
800-558-0607 or 414-671-6350.
CAUTION
BURN HAZARD:
• Some exterior surfaces on unit will get hot. Avoid
unnecessary contact with unit.
• Do not come in contact with waffle plates during
operation. Both plates are very hot.
• Allow unit to cool before performing any cleaning,
adjustments, or maintenance.
Locate unit at proper counter height in an area that is
convenient for use. Location should be level and strong
enough to support weight of unit and contents.
NOTICE
Do not locate unit in an area subject to excessive
temperatures or grease from grills, fryers, etc. Excessive
temperatures and grease could cause damage to unit.
Damage to any countertop material caused by heat
generated from Hatco equipment is not covered under
the Hatco warranty. Contact manufacturer of countertop
material for application information.
For steel surfaces, use non-abrasive cleaners and cloths
only. Abrasive cleaners and cloths could scratch finish of
unit, marring its appearance and making it susceptible to
soil accumulation.
Do not use harsh chemicals such as bleach, cleaners
containing bleach, or oven cleaners to clean this unit.
Do not attempt to cool hot waffle plates quickly, such as by
immersing in water. Damage to plates will occur.
This unit is intended for commercial use only—NOT for
household use.
Clean unit daily to avoid malfunctions and maintain
sanitary operation.
Read the following important safety information before using this equipment to avoid serious
injury or death and to avoid damage to equipment or property.
Produktspecifikationer
| Varumärke: | Krampouz |
| Kategori: | Våffelbryggare |
| Modell: | KWMSL.2LG413620 |
Behöver du hjälp?
Om du behöver hjälp med Krampouz KWMSL.2LG413620 ställ en fråga nedan och andra användare kommer att svara dig
Våffelbryggare Krampouz Manualer
16 September 2024
16 September 2024
16 September 2024
16 September 2024
16 September 2024
16 September 2024
16 September 2024
16 September 2024
16 September 2024
16 September 2024
Våffelbryggare Manualer
- Våffelbryggare Philips
- Våffelbryggare Delonghi
- Våffelbryggare Krups
- Våffelbryggare Quigg
- Våffelbryggare Tefal
- Våffelbryggare Adler
- Våffelbryggare Ambiano
- Våffelbryggare Arendo
- Våffelbryggare Aroma
- Våffelbryggare Bartscher
- Våffelbryggare Salton
- Våffelbryggare Princess
- Våffelbryggare Severin
- Våffelbryggare Gorenje
- Våffelbryggare Silvercrest
- Våffelbryggare Korona
- Våffelbryggare Black And Decker
- Våffelbryggare Breville
- Våffelbryggare Tristar
- Våffelbryggare Domo
- Våffelbryggare Trisa
- Våffelbryggare Waring Commercial
- Våffelbryggare Tomado
- Våffelbryggare Livoo
- Våffelbryggare OBH Nordica
- Våffelbryggare Bestron
- Våffelbryggare ECG
- Våffelbryggare Melissa
- Våffelbryggare Emerio
- Våffelbryggare Fritel
- Våffelbryggare Cuisinart
- Våffelbryggare Logik
- Våffelbryggare Stirling
- Våffelbryggare Bella
- Våffelbryggare Vitek
- Våffelbryggare Eldom
- Våffelbryggare Suntec
- Våffelbryggare Trebs
- Våffelbryggare Steba
- Våffelbryggare Beem
- Våffelbryggare Exquisit
- Våffelbryggare Sage
- Våffelbryggare Champion
- Våffelbryggare Bomann
- Våffelbryggare Hamilton Beach
- Våffelbryggare Farberware
- Våffelbryggare Rommelsbacher
- Våffelbryggare Wilfa
- Våffelbryggare Arzum
- Våffelbryggare FriFri
- Våffelbryggare Bifinett
- Våffelbryggare Nova
- Våffelbryggare Tower
- Våffelbryggare Gastroback
- Våffelbryggare MPM
- Våffelbryggare Vivax
- Våffelbryggare Gourmetmaxx
- Våffelbryggare Waves
- Våffelbryggare Coline
- Våffelbryggare Dash
- Våffelbryggare Chefman
- Våffelbryggare Kalorik
- Våffelbryggare Gutfels
- Våffelbryggare Orava
- Våffelbryggare Witt
- Våffelbryggare Venga
- Våffelbryggare Rival
- Våffelbryggare Duronic
- Våffelbryggare Exido
- Våffelbryggare Kogan
- Våffelbryggare PowerXL
- Våffelbryggare Carnival King
- Våffelbryggare Hatco
- Våffelbryggare GreenPan
- Våffelbryggare Lagrange
- Våffelbryggare WestBend
- Våffelbryggare Petra Electric
- Våffelbryggare Nemco
- Våffelbryggare Neumärker
- Våffelbryggare Ravanson
- Våffelbryggare Casselin
- Våffelbryggare Euro Cuisine
- Våffelbryggare Beautiful
- Våffelbryggare Smart Planet
- Våffelbryggare Chef's Choice
- Våffelbryggare Royal Catering
- Våffelbryggare Brentwood
- Våffelbryggare Imarflex
Nyaste Våffelbryggare Manualer
27 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
14 Oktober 2024
14 Oktober 2024
