Sida 1/24
HMa
Wideband Plug-On Transmitter
With Digital Hybrid Wireless® Technology
HMa, HMa-941, HMa/E01, HMa/E02, HMa/E06, HMa/E07-941, HMa/X
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
Digital Hybrid Wireless®
US Patent 7,225,135
HMa, HMa-941, HMa/EO1, HMa/E02, HMa/E06, HMA/E07-941, HMa/X
LECTROSONICS, INC.
2
Wideband Digital Hybrid® Plug-On Transmitter
Rio Rancho, NM 3
Thank you for selecting a Lectrosonics HMa Plug-On
transmitter. The unique design provides several distinct
features for professional applications:
• Outstanding RF operating range
• Superb audio quality
• Corrosion-resistant housing
• Programmable compatibility modes for use with a
wide variety of different receivers
The Digital Hybrid Wireless® design (US Patent
7,225,135) combines 24-bit digital audio with analog
FM resulting in a system that has the same operating
range as analog systems, the same spectral efficiency
as analog systems, the same long battery life as analog
systems, plus the excellent audio fidelity typical of pure
digital systems.
The transmitter uses a standard 3-pin XLR input jack for
use with any microphone with a a mating XLR connec-
tor. An LCD, membrane switches and multi-color LEDs
on the control panel make input gain adjustments and
frequency and compatibility mode selection quick and
accurate, without having to view the receiver. The hous-
ing is machined from a solid aluminum block to provide
a lightweight and rugged package. A special non-corro-
sive finish resists salt water exposure and perspiration
in extreme environments.
The DSP-based design works with all Digital Hybrid
receivers, and is backward compatible for use with Lec-
trosonics 200 and 100 Series, Mode 3, Mode 6, Mode
7, and IFB receivers and some other brands of analog
wireless receivers. Companion receivers are covered in
separate manuals. Your Lectrosonics representative can
guide you through any compatibility concerns.
Table of Contents
General Technical Description ......................................... 4
Digital Hybrid Wireless® Technology ................................ 4
No Pre-Emphasis/De-Emphasis 4 ......................................
Low Frequency Roll-Off 5 ...................................................
Input Limiter 5 .....................................................................
Signal Encoding and Pilot Tone 5 .......................................
Microprocessor and DSP 5 .................................................
Compatibility Modes 5 .........................................................
Control Panel 5 ...................................................................
Controls and Functions 6 ....................................................
LCD Screen 6 .....................................................................
Power LED 6 .......................................................................
Audio Input Jack 6 ...............................................................
Battery Compartment....................................................... 6
USB Port 6 ..........................................................................
IR Port 6 ..............................................................................
Modulation LEDs 6 ..............................................................
Audio Button 6 ....................................................................
Freq Button 6 ..............................................................
UP/DOWN Arrows and Panel Lockout 6 .............................
Antenna 6 ............................................................................
Battery Installation 7 ............................................................
Attaching/Removing a Microphone 7 .................................
Operating Instructions 8 ......................................................
Power Up and Boot Sequence 8 .........................................
Power Down 8 .....................................................................
Automatic Power Restore 8 .................................................
Standby Mode 8 ..................................................................
UP Button Menu 8 ...............................................................
DOWN Button Menu 9 ........................................................
AUDIO Button Settings 10 ....................................................
FREQ Button Settings 11 ......................................................
Block 470/19 Frequency Overlap 11 .....................................
Lock/Unlock Screen 12 .........................................................
Remote Control with “Dweedle Tones” 12 .............................
LectroRM 13 ............................................................................
Accessories 14 .......................................................................
P/N 21750 Barrel Adapter 14 ................................................
MCA-M30 Barrel Adapter 14 .................................................
PHTRAN3 14 ........................................................................
MCA5X 14 .............................................................................
MCA-TPOWER 14 ................................................................
Specifications and Features 15 .............................................
Firmware Update 16 ...............................................................
Troubleshooting 18 .................................................................
Service and Repair 20 ............................................................
Returning Units for Repair 20 ...............................................
EU Declaration of Conformity 21 ..........................................
FCC Compliance:
This device complies with FCC radiation exposure limits as set
forth for an uncontrolled environment. This device should be
installed and operated so that its antenna(s) are not co-located or
operating in conjunction with any other antenna or transmitter.
Notice to the End User:
The normal condition of using this device is to keep the hand at
least 20mm away from the base of the microphone.
