witch -40 to 75C

Guide

v1.00 - 1401

IES-0610 Page 1

Overview

LevelOne IES-0610 Industry Ethernet Switch provides 4 PoE ports of

10/100/1000Base-T plus 1 ports of 10/100/1000Base-T Ethernet plus

2 ports of Gigabit SFP to enable high speed network at mission-

critical environment. The compact metal housing is designed for

desktop space saving, plus the clearly visible status LEDs provide

simple monitoring of port link activity. Moreover, the SFP slots

support pluggable modules that enabling you to choose from a

variety of transceivers.

High Reliability

All components are built to withstand harsh environment

applications without compromise where humidity, temperature

variation and even shock vibration are concerns, including Electric

& Utility, Critical Infrastructure, Transportation and Surveillance

Security. This device operates under -40 to 75 Celsius (-40 to 167

Fahrenheit) temperature.

Plug & Play

This unmanaged Industrial Ethernet Switch is designed for the

demanding industrial environments at businesses in need of

instant connectivity with no setup or configure required, truly plug

and play.

Power over Ethernet

This switch is Power Sourcing Equipment (PSE), and it is fully

complied with IEEE 802.3at PoE standard at maximum 30W power

budget per port. It helps to save infrastructure wiring costs

dramatically by eliminating electric wiring and less UPS needed.

Also, it is compatible with IEEE802.3af standard PD devices.

IES-0610 Page 2

Features

 Meets NEMA TS1/TS2 Environmental requirements such as temperature, shock,

and vibration for traffic control equipment

 Meets EN61000-6-2 & EN61000-6-4 EMC Generic Standard Immunity for

industrial environment

 Supports 1024 MAC addresses. Provides 1M bits memory buffer

 Supports IEEE802.3af PoE 15.4W and IEEE802.3at PoE+ 30W

 Provides one combo Gigabit ports. SFP socket for Gigabit fibre optic expansion.

 Store-and-forward mechanism. Full wire-speed forwarding rate.

 Power Supply: 47~57VDC Terminal Block power input.

 5.52W power consumption 48VDC @ 0.12A (unit only)

 -40 to 75 (-40 to 167 ) operating temperature range. ℃ ℃ ℉ ℉

 Tested for functional operation @ -40 to 85 (-40 to 185 ). ℃ ℃ ℉ ℉

 Hardened metal case

Package Contents

 IES-0610

 Quick Installation Guide

IES-0610 Page 3

LED Status

LED Status Description

PWR 1, 2

Steady Power On

Off Power Off

P1 ~ P4

Steady PD is connected

Off No PD is connected

10/100/1000Base-TX (T1 ~ T5)

LNK

Steady Network connection established

Flashing Transmitting or Receiving data

SPD

Steady Power Device (PD) is connected

Off Power Device (PD) is disconnected

1000Base-SFP

Steady Network connection established

Flashing Transmitting or Receiving data

Steady A valid connection established

Off No connection is being established

IES-0610 Page 4

Power Input

Terminal Block

IES-0610 Page 5

DIP Switch

DIP1 DIP1

OFF T5 (RJ45) enabled 1000M

ON F5 (SFP) enabled 100M

Note: Port5 (T5 & F5) is shared combo port, enable either RJ45 or

SFP via DIP1 switch

IES-0610 Page 6

DIN Rail Mount

 Assembly: Place the switch on the DIN rail from above using the

slot. Push the front of the switch toward the mounting surface

until it audibly snaps into place

 Start-up: Connect the supply voltage to start up the switch via

the terminal block (or DC JACK)

 Dismantling: Pull out the lower edge and then remove the switch

from the DIN rail.

IES-0610 Page 7

10/100/1000Base-TX Pin

The following lists the pin-out of 10/100/1000Base-TX ports

Pin 10/100 DC & Data 1000 DC & Bi-Data

1 Rx + DC + TxRx A + DC +

2 Rx - DC + TxRx A - DC +

3 Tx + DC - TxRx B + DC -

4 unused TxRx C +

5 unused TxRx C -

6 Tx - DC - TxRx B - DC -

7 unused TxRx D +

8 unused TxRx D -
