ENGLISH

HDS Gen2 Touch

Operator manual

lowrance.com

Lowrance® and Navico® are registered

trademarks of Navico.

Fishing Hot Spots® is a registered trademark

Fishing Hot Spots.

Navionics® is a registered trademark of

Navionics, Inc.

NMEA 2000® is a registered trademark of the

National Marine Electronics Association.

Maptech.

Warning: It is your sole responsibility

to install and use the instrument and

transducer(s) in a manner that will not

cause accidents, personal injury or property

damage. Always observe safe boating

practices.

Sonar performance: The accuracy of the

sonar depth display can be aﬀected by many

factors, including the type and location of the

transducer and water conditions. Never use this

instrument to gauge depth or other conditions

for swimming or diving.

The choice, location, and installation of

transducers and other components of the system

are critical to the performance of the system as

intended. If in doubt, consult your local dealer.

To reduce the risk of misusing or misinterpreting

this unit, you must read and understand all

aspects of this Installation and Operation

Manual. We also recommend that you practice

all operations using the built-in simulator before

using this unit on the water.

Global Positioning System: The Global

Positioning System (GPS) is operated by the US

Government which is solely responsible for its

operation, accuracy and maintenance. The GPS

is subject to changes which could aﬀect the

accuracy and performance of all GPS equipment

anywhere in the world, including this instrument.

Electronic Chart: The electronic chart used by

this instrument is an aid to navigation designed

to supplement, not replace, oﬃcial government

charts. Only oﬃcial government charts

supplemented by notices to mariners contain

the information required for safe and prudent

navigation. Always supplement the electronic

information provided by this instrument with

other plotting sources such as observations,

depth soundings, radar and hand compass

bearings. Should the information not agree, the

discrepancy must be resolved before proceeding

any further.

Navico may nd it necessary to change or

end our policies, regulations and special

oers at any time. We reserve the right

to do so without notice. All features and

specications subject to change without

notice.

IMPORTANT NOTE ABOUT RESTRICTED

OPERATION OUTSIDE OF THE AMERICAS

Units designed for sale in the Americas will have

limited Language and Units functionality outside

of a zone deﬁned as 30 degrees West longitude

on the East and the International Date Line on

the West. Language options will be restricted to

English (US) only and Units will be restricted to

non-metric measures.

Units sold with Enhanced US Basemap, Nautic

Insight, Lake Insight or Insight USA units are

impacted and will not have this functionality

outside of the deﬁned region. Units sold with

WorldWide Basemap will function without these

restrictions.

| 1

Preface

As Navico is continuously improving this product, we retain the

right to make changes to the product at any time which may not

be reﬂected in this version of the manual. Please contact your

Lowrance dealer if you require any further assistance.

It is the owner’s sole responsibility to install and use the instrument

and transducers in a manner that will not cause accidents, personal

injury or property damage. The user of this product is solely

responsible for observing safe boating practices.

NAVICO HOLDING AS AND ITS SUBSIDIARIES, BRANCHES AND

AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE OF THIS PRODUCT

IN A WAY THAT MAY CAUSE ACCIDENTS, DAMAGE OR THAT MAY

VIOLATE THE LAW.

Governing Language: This statement, any instruction manuals,

user guides and other information relating to the product

(Documentation) may be translated to, or has been translated from,

another language (Translation). In the event of any conﬂict between

any Translation of the Documentation, the English language

version of the Documentation will be the oﬃcial version of the

Documentation.

This manual represents the product as at the time of printing.

Navico Holding AS and its subsidiaries, branches and aﬃliates

reserve the right to make changes to speciﬁcations without notice.

Warranty

The warranty card is supplied as a separate document.

In case of any queries, refer to the brand web site of your display or

system: www.lowrance.com

Declarations and conformance

This equipment is intended for use in international waters as well as

inland waters and coastal sea areas administered by countries of the

USA, E.U. and E.E.A. For more information refer to the separate HDS

Gen 2 Touch Installation manual.
