Sida 1/12
09/23/13
TYPE1
Stationary Mount Base Model
TYPE2
Stationary Mount + Shelf
TYPE3
Stationary Mount + Shelf +
Camera Mount
TYPE4
Rotating Mount + Shelf
Flat Panel Series Mobile
Stand Instructions
2 / 12
Table of Contents
Table of Contents and Warnings 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part List 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assembly and Installation
Adjust upper and lower poles 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Attaching to the base assembly 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install steel cross rods 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Height adjustment 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Media shelf assembly 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assemble at panel mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Install mount to the frame 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install camera mount 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable and wire installation 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VESA mounting patterns 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WARNING!
Severe personal injury and property damage can result from improper installation. Read
instructions carefully before beginning.
• If you do not understand the instructions or have any concerns please contact a
qualied local installer.
• Do not install or assemble if the product or hardware is damaged or missing, if you
require replacement parts contact your local dealer.
• This product ts most 40˝- 60˝ at panel displays; maximum weight for the display
is 100 lbs. / 45.5kg.
• Do not use this product for anything other than what it was originally designed.
• This product contains moving parts, please use caution.
• The manufacturer disclaims any liability for the modications, improper installation
and installation exceeding maximum weight capacity. The manufacturer will not be
liable for any damages arising out of the use of, or inability to use the product.
Tools Required
-Phillips Screwdriver
-Wrench
3 / 12
Part List
A1 x1
R1 x1
R2 x1 R3 x1
S1 x1
S2 x1
A2 x4
A3 x4
A4 x1
C1 x1
C1 x1 C2 x2
C2 x2 C3 x4
C3 x2
C4 x4C5 x4
B2 x2
B1 x1
B2 x2
B1 x1
B3 x2 B5 x2
B5 x2*
B4 x4
TYPE4
TYPE4
TYPE1, TYPE2, TYPE3
TYPE1, TYPE2, TYPE3
only: TYPE1,
TYPE2, TYPE3
only: TYPE2,
TYPE3, TYPE4
only: TYPE2,
TYPE3, TYPE4
(B3 is pre-
installed)
*1 is pre-installed
only: TYPE3
only: TYPE3
only: TYPE3
E F x4 x4G x4
D x2
H J x4 x4
K L M x4 x1 x1T x8N P x2 x2
M8x25mm
M8x20mm M6x10mmM5x10mm
M6x25mm M5x25mm
