User Guide
English ( 2 – 6 )
Guía del usuario
Español ( 7 – 11 )
Guide d'utilisation
Français ( 12 – 16 )
Guida per l'uso
Italiano ( 17 – 21 )
Benutzerhandbuch
Deutsch ( 22 – 25 )
Appendix
English ( 26 – 27 )
2
User Guide (English)
Introduction
Box Contents
M-Track Duo
USB-B–to–USB-A Cable
Software Download Cards
User Guide
Safety & Warranty Manual
Support
For the latest information about this product (system requirements, compatibility information,
etc.) and product registration, visit m-audio.com.
For additional product support, visit m-audio.com/support.
Quick Start
macOS users: No driver installation is needed for class-compliant operation with M-Track
Duo.
iOS users: The power available from an iOS device is not sufficient to power M-Track Duo.
Use the Apple Camera Connection Kit (sold separately), a USB break-out cable (sold
separately), and a USB power adapter (sold separately) which will provide an additional USB
connector to power M-Track Duo.
Windows users: Before connecting M-Track Duo to your computer, install the drivers:
1. Go to m-audio.com/drivers and download the latest M-Track Duo driver for your
operating system.
2. Open the file you downloaded and double-click the driver installer file.
3. Follow the on-screen instructions to install the drivers.
Software: We've included Pro Tools | First M-Audio Edition and MPC Beats with your
M-Track Duo so you can get started making music with professional software right out of the
box. Register your M-Track Duo on m-audio.com/softwaredownload, and follow the install
instructions in your User Account.
Virtual Instruments: Follow the instructions in your user account for installing the included
virtual instrument plugins. After installation, most DAWs will not load virtual instrument plugins
automatically. In order to access the virtual instrument plugins with Pro Tools | First M-Audio
Edition, you will need to choose the plugin folder for the software to scan:
Pro Tools | First M-Audio Edition (AAX) plugin folders:
Windows (32-bit): C:\Program Files (x86)\Common Files\Avid\Audio\Plug-Ins
Windows (64-bit): C:\Program Files\Common Files\Avid\Audio\Plug-Ins
macOS: Macintosh HD/Library/Application Support/Avid/Audio/Plug-Ins
3
To set M-Track Duo as your default playback device, follow the directions below based on
your computer’s operating system.
Windows:
1. Use the included USB cable to connect the M-Track Duo to your computer.
2. In the Taskbar, locate the Volume Control "speaker" icon. Right-click the speaker and
open Sound Settings > Sounds.
Alternatively, go to Start Menu > System > Sound > Sound Control Panel.
3. In the Windows Sound control panel select the Playback tab and select USB Audio
Codec as the default device.
4. Click the Recording tab and select USB Audio Codec as the default device.
5. Click Properties in the lower right-hand corner.
6. In the new window, click the Advanced tab and select 2-channel, 16-bit, 48000 Hz
(Studio Quality) as the default format.
7. Uncheck both boxes under Exclusive Mode.
8. Click OK to close the Properties window.
9. Click OK to close the Sound control panel.
macOS:
1. Use the included USB cable to connect the M-Track Duo to your computer.
2. Go to Applications > Utilities > Audio MIDI Setup.
3. In the Audio Devices window, select USB Audio Codec in the left column.
4. Right-click USB Audio Codec, and select Use this device for sound input.
5. Right-click USB Audio Codec, and select Use this device for sound output.
6. Quit Audio MIDI Setup.
Connection Diagram
Items not listed under Introduction > Box Contents are sold separately.
Note: Use the +48V (Phantom Power) Switch only if a microphone requires phantom power.
Most dynamic microphones and ribbon microphones do not require phantom power, but most
condenser microphones do. Consult your microphone's documentation to find out whether it
needs phantom power.
Front Panel
Rear Panel
Monitors Headphones
Guitar
Computer
Microphone
