Safety & Compliance Notices: Notice Concerning FCC Regulations: You are

cautioned that changes or modifications not expressly approved by the part responsible for

compliance could void the user’s authority to operate the equipment. This equipment has been

tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC rules. These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures: (a) Reorient or relocate the receiving antenna;

(b) move this unit; (c) increase the separation between the equipment and receiver; connect the (d)

equipment into an outlet on a circuit different from that to which the receiver is connected; (e) be

sure that all cables are properly shielded, using a choke or ferrite where appropriate; (f) consult the

dealer or an experienced radio/television technician for help.

User Guide (English)

For more information about this product (system

requirements, compatibility information, etc.), product

registration, or product support, visit m-audio.com. For safety

and warranty information, visit m-audio.com/warranty.

Package Contents: Micro DAC, USB extension cable,

coaxial digital cable, carrying pouch, user guide

1. USB Port: Insert this connector to a USB port on your

computer (powered on). The connection will supply the

necessary power to Micro DAC.

If necessary, use the included USB extension cable so

Micro DAC does not block any adjacent connections on

your computer.

2. Power Indicator: This light illuminates when Micro DAC is

powered on.

3. Headphone Output: Connect standard 1/8” (3.5mm)

stereo headphones to analog output.

4. Coaxial Output: Use the included coaxial digital cable to

connect this digital output to the coaxial input of a receiver

or playback device.

5. Impedance Selector: Set this switch to the higher setting

(HI) if you are using headphones (connected to the

headphone output) with low impedance (approximately

64 Ω).

Note: To set the volume, adjust the volume level on your

connected headphones, receiver or playback device, or your

computer’s sound card.

Guía del usuario (Español)

Para más información acerca de este producto (requisitos de

sistema, información de compatibilidad, etc.), registro o

soporte del producto, visite m-audio.com. Para información

sobre la seguridad y la garantía, visite m-audio.com/warranty.

Contenido del paquete: Micro DAC, cable alargador USB,

cable coaxial digital, cartuchera de transporte, guía del usuario

1. Puerto USB: Inserte este conector en un puerto USB de su

ordenador (encendido). La conexión suministrará la

corriente necesaria al Micro DAC.

De ser necesario, utilice el cable alargador USB incluido

para que el Micro DAC no obstruya ninguna otra conexión

adyacente en su ordenador.

2. Indicador de encendido: Esta luz se ilumina cuando el

Micro DAC está encendido.

3. Salida para auriculares: Conecte auriculares estéreo

estándar de 3,5 mm (1/8 pulg.) a esta salida.

4. Salida coaxial: Utilice el cable digital coaxial incluido para

conectar esta salida digital a la entrada coaxial del receptor

o dispositivo de reproducción.

5. Selector de impedancia: Ajuste este interruptor al valor

más alto (HI) si está utilizando auriculares (conectados a la

salida para auriculares) con baja impedancia

(aproximadamente 64 Ω).

Nota: Para regular el volumen, ajuste el nivel de volumen en

sus auriculares, receptor o dispositivo de reproducción

conectados, o en la tarjeta de sonido de su ordenador.

Technical Specifications

Analog Outputs: (1) 1/8” (3.5mm) headphone

Digital Outputs: (1) coaxial

Power: via USB connection

Dimensions (WxDxH): 2.8” x 0.9” x 0.4” / 70 x 24 x 10 mm

Weight: 0.06 lbs. / 0.03 kg

Specifications are subject to change without notice.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure

limits set forth for an uncontrolled environment. End users must follow the specific operating

instructions for satisfying RF exposure compliance. This transmitter must not be co-located or

operating in conjunction with any other antenna or transmitter. For best audio quality, avoid using this

device in a high RF-radiated environment. RSS Statement for Canadian models: This device

complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference, and (2) this device must accept any

interference, including interference that may cause undesired operation of the device This unit does

not exceed the Class B limits for radio noise emission from digital apparatus set out in the radio

interference re

ulations of the Canadian Department of Communications.

ESD/EFT Warning: This unit may contain a microcomputer for signal processing and

control functions. In very rare situations, severe interference, noise from an external

source, or static electricity may cause it to lock up. In the unlikely event that this should

happen, turn off the unit, wait at least five seconds, and then turn it back on again. In an

environment with radio frequency interference, the unit may malfunction and resume

normal operation after removal of the interference.

Trademarks and Licenses: M-Audio is a trademark of inMusic Brands, Inc., registered in

the U.S. and other countries. All other product or company names are trademarks or registered

trademarks of their respective owners.

User Guide

Guía del usuario

Guide d’utilisation

Guida per l’uso

Benutzerhandbuch

English

Español

Français

Italiano

Deutsch
