Oxygen Series
User Guide
M
-
AUDIO
Oxygen Series User Guide
2
1 Introduction
Congratulations on purchasing an M-Audio Oxygen Series keyboard. Oxygen keyboards now offer DirectLink, which
provides support for Digital Audio Workstations (DAW)1 such as Pro Tools 8 by automatically mapping the track and
master volume sliders, slider buttons, pan knobs and transport controls to their corresponding functions in the program.
A single USB connection not only sends MIDI data to the computer, but also provides power to the keyboard. All
Oxygen Series keyboards function as class-compliant devices and will be recognized by your computer without the
need to install additional drivers. Simply use the included USB cable to connect the keyboard to an available USB port
on your computer and set the power switch to the On position.
Please refer to Section 5 of this Guide for more information on keyboard setup (including optional driver installation),
and configuration of your recording application.
2 What’s in the Box
The Oxygen Series keyboard packaging includes the following:
Oxygen Series keyboard
USB Cable
Printed Quick Start Guide
Oxygen Series disk
1 Please check www.m-audio.com for a current list of supported recording applications, the most recent DirectLink
installers, and configuration instructions. Applications not directly supported via DirectLink can be controlled by
using your recording application’s "MIDI learn" feature or by mapping the Oxygen controls manually. See
sections 8 and 9 of this guide for more information.
Oxygen Series User Guide
3
3 Oxygen Series Features
25, 49 or 61 velocity sensitive full-size keys
Automatic mapping of top panel controls to supported DAWs
Advanced programming functions via the keyboard
Octave/Transpose buttons
2 Track Select buttons
9 sliders (1 on Oxygen 25); MIDI re-assignable
9 buttons (Oxygen 49/61 only); MIDI re-assignable
8 knobs; MIDI re-assignable
Pitch Bend and Modulation wheels; MIDI re-assignable
6 Transport Buttons; MIDI re-assignable
Sustain pedal input; MIDI re-assignable
10 user editable memory locations
3 digit LED screen
USB 2.0 port (backward compatible with USB 1.1)
4 Minimum System Requirements
Minimum system requirements can be found on the Oxygen Series product packaging as well as the M-Audio website
at www.m-audio.com.
5 Setup
Oxygen Series keyboards function as class-compliant devices and will be recognized by your computer without the
need to install additional drivers. Simply use the included USB cable to connect the keyboard to an available USB port
on your computer and set the power switch to the On position.
Windows users, who are planning to:
• use the keyboard with more than one application at the same time
or
• simultaneously use other class-compliant USB devices with audio capabilities
...must install the latest Oxygen Series drivers found at the M-Audio website
www.m-audio.com.
