O W N E R ’ S M A N U A L
Part No. SW1191 Rev. A 12/16
©2016 LOUD Technologies Inc. All Rights Reserved.
2
Big Knob Passive Monitor Controller
Big Knob Passive Monitor Controller
Like us
Follow us
Watch our dang videos
Please write your serial number here for future
reference (i.e., insurance claims, tech support,
return authorization, make dad proud, etc.)
Purchased at:
Date of purchase:
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
PORTABLE CART
WARNING
CAUTION
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the prescence of uninsulated “dangerous voltage”
within the product’s enclosure, that may be of significant ma-
gnitude to constitute a risk of electric shock to persons.
RISK OF ELECTRIC SHOCK! DO NOT OPEN!
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
The exclamation point within an equilateral triangle is
intended to alert the user of the prescence of important
operating and maintaining (servicing) instructions in the
literature accompanying the appliance.
WARNING — To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or moisture.
11. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
12. Exposure to extremely high noise levels may cause permanent hearing loss.
Individuals vary considerably in susceptibility to noise-induced hearing loss,
but nearly everyone will lose some hearing if exposed to sufficiently intense
noise for a period of time. The U.S. Government’s Occupational Safety and
Health Administration (OSHA) has specified the permissible noise level
exposures shown in the following chart.
According to OSHA, any exposure in excess of these permissible limits could
result in some hearing loss. To ensure against potentially dangerous exposure
to high sound pressure levels, it is recommended that all persons exposed
to equipment capable of producing high sound pressure levels use hearing
protectors while the equipment is in operation. Ear plugs or protectors in the
ear canals or over the ears must be worn when operating the equipment in
order to prevent permanent hearing loss if exposure is in excess of the limits
set forth here:
8 90 Duo in small club
6 92
4 95 Subway Train
3 97
2 100 Very loud classical music
1.5 102
1 105 Jon screaming at Troy about deadlines
0.5 110
0.25 or less 115 Loudest parts at a rock concert
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.
Apparatet må tilkoples jordet stikkontakt.
Apparaten skall anslutas till jordat uttag.
Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE directive
(2012/19/EU) and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and electronic equipment (EEE).
Improper handling of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally
associated with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For more information
about where you can drop off your waste equipment for recycling, please contact your local city office, waste authority, or your household waste disposal service.
3
Owner’s Manual
Owner’s Manual
• Excruciatingly simple 2x2 monitor controller
•
Choose between two sources and two
monitor pairs.
•
Classic Big Knob volume control.
•
Professional mono, mute and dim functions.
•
Pristine audio quality
•
Passive audio path with no power supply needed.
•
Sturdy “Built-Like-A-Tank” design
Contents
Big Knob Passive Features
Introduction
The Big Knob Passive benets from a proven,
bestselling design to deliver professional level control,
plus source and monitor selection for studios of any size.
The passive audio path ensures pristine sonic integrity
is maintained throughout your signal chain. More than
just a level control solution, Big Knob Passive features
the ability to choose between two sources and two
monitor pairs.
Ideal for simple level control at a home or project
studio or for integration in a large studio or group of
editing suites, Big Knob Passive is the “Built-Like-A-
Tank,” affordable monitoring control solution.
Quick Start
We realize that you can’t wait to hook up your Big
Knob Passive and try it out. Nevertheless, please take
the time to read this page NOW, and the rest can wait
until you’re good and ready.
1. Turn down all knobs.
2. Disengage all switches.
3. Plug signal sources into the Big Knob, such as:
• Audio interface.
• Line-level sources such as keyboards, drum
machines, or MP3 players plugged into the
line-level inputs.
• Other stereo playback devices.
4. Connect cords from the monitor outs to powered
speakers (or to an amplier connected to passive
speakers).
5. Turn the powered studio monitors (or ampliers) on.
6. Be sure that the volume of the input is the same
as it would be during normal use.
7. Engage the desired input source select and monitor
select switches.
8. Slowly bring up the volume knob to a comfortable
listening level.
IMPORTANT SAFETY INSTRUCTIONS ...............................................2
TABLE OF CONTENTS ........................................................................3
BIG KNOB PASSIVE FEATURES .........................................................3
INTRODUCTION ...............................................................................3
QUICK START ...................................................................................3
HOOKUP DIAGRAM ......................................................................... 4
REAR PANEL DESCRIPTION .............................................................5
1. 1/4" SOURCE INPUTS......................................................5
2. 1/8" STEREO LINE INPUT ................................................5
3. MON OUTPUTS ................................................................5
FRONT PANEL DESCRIPTION ............................................................ 6
4. SOURCE SELECT SWITCH .................................................6
5. MONITOR SELECT SWITCH ..............................................6
6. MONO SWITCH ............................................................... 6
7. MUTE SWITCH ................................................................6
8. DIM SWITCH ...................................................................6
9. VOLUME KNOB [AKA BIG KNOB] .................................... 6
APPENDIX A: SERVICE INFO ............................................................7
TROUBLESHOOTING / REPAIR .............................................7
APPENDIX B: TECHNICAL INFORMATION .........................................8
BIG KNOB PASSIVE SPECIFICATIONS .......................................8
BIG KNOB PASSIVE DIMENSIONS ............................................9
BIG KNOB PASSIVE BLOCK DIAGRAM ...................................10
BIG KNOB PASSIVE LIMITED WARRANTY ......................................11
