O W N E R ’ S M A N U A L

18” Powered Subwoofer

SRM1801

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other.

A grounding-type plug has two blades and a third grounding prong.

The wide blade or the third prong are provided for your safety. If the

provided plug does not ﬁt into your outlet, consult an electrician for

replacement of the obsolete outlet.

10.

Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

11.

Only use attachments/accessories speciﬁed by the manufacturer.

12.

Use only with a cart, stand, tripod, bracket, or

table speciﬁed by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13.

Unplug this apparatus during lightning storms or

when unused for long periods of time.

14.

Refer all servicing to qualiﬁed service personnel. Servicing is required

when the apparatus has been damaged in any way, such as power-

supply cord or plug is damaged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

15.

This apparatus shall not be exposed to dripping or splashing, and no

object ﬁlled with liquids, such as vases or beer glasses, shall be placed

on the apparatus.

16.

Do not overload wall outlets and extension cords as this can result in a

risk of ﬁre or electric shock.

17.

This apparatus has been designed with Class-I construction and must

be connected to a mains socket outlet with a protective earthing con-

nection (the third grounding prong).

18.

This apparatus has been equipped with a rocker-style AC mains power

switch. This switch is located on the rear panel and should remain

readily accessible to the user.

19.

The MAINS plug or an appliance coupler is used as the disconnect

device, so the disconnect device shall remain readily operable.

20. NOTE: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equip-

ment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandthereceiver.

• Connecttheequipmentintoanoutletonacircuitdifferentfrom

that to which the receiver is connected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

CAUTION: Changes or modiﬁcations to this device not expressly

approved by LOUD Technologies Inc. could void the user's authority to

operate the equipment under FCC rules.

21.

This apparatus does not exceed the Class A/Class B (whichever is

applicable)

limits for radio noise emissions from digital apparatus as

set out in the radio interference regulations of the Canadian Department

of Communications.

ATTENTION — Le présent appareil numérique n’émet pas de bruits

radioélectriques dépassant las limites applicables aux appareils

numériques de class A/de class B (selon le cas) prescrites dans le

réglement sur le brouillage radioélectrique édicté par les ministere des

communications du Canada.

22.

Exposure to extremely high noise levels may cause permanent hearing

loss. Individuals vary considerably in susceptibility to noise-induced

hearing loss, but nearly everyone will lose some hearing if exposed to

sufﬁciently intense noise for a period of time. The U.S. Government’s

Occupational Safety and Health Administration (OSHA) has speciﬁed

the permissible noise level exposures shown in the following chart.

According to OSHA, any exposure in excess of these permissible limits

could result in some hearing loss. To ensure against potentially danger-

ous exposure to high sound pressure levels, it is recommended that all

persons exposed to equipment capable of producing high sound pres-

sure levels use hearing protectors while the equipment is in operation.

Ear plugs or protectors in the ear canals or over the ears must be worn

when operating the equipment in order to prevent permanent hearing

loss if exposure is in excess of the limits set forth here:

Important Safety Instructions

PORTABLE CART

WARNING

CAUTION AVIS

RISK OF ELECTRIC . DO NOT OPENSHOCK

RISQUE DE ELECTRIQUE. NE PAS OUVRIRCHOC

CAUTION: REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK)TO

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNELTO

ATTENTION: POUR EVITER LES RISQUES DE CHOC ELECTRIQUE, NE PAS ENLEVER LE COUVERCLE.

AUCUN ENTRETIEN DE PIECES INTERIEURES PAR L'USAGER.

CONFIER L'ENTRETIEN AU PERSONNEL QUALIFIE.

AVIS: POUR EVITER LES RISQUES D'INCENDIE OU D'ELECTROCUTION, N'EXPOSEZ S CET TICLE PA AR

A A LA PLUIE OU L'HUMIDITE

The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of uninsulated "dangerous

voltage" within the product's enclosure, that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

Le symbole éclair avec point de flèche à l'intérieur d'un triangle équilatéral

est utilisé pour alerter l'utilisateur de la présence à l'intérieur du coffret de

"voltage dangereux" non isolé d'ampleur suffisante pour constituer un risque

d'éléctrocution.

The exclamation point within an equilateral triangle is intended to alert the

user of the presence of important operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

Le point d'exclamation à l'intérieur d'un triangle équilatéral est employé

pour alerter les utilisateurs de la présence d'instructions importantes pour le

fonctionnement et l'entretien (service) dans le livret d'instruction

accompagnant l'appareil.

WARNING — To reduce the risk of ﬁre or electric shock, do not

expose this apparatus to rain or moisture.

Duration,

per day in

hours

Sound Level

dBA, Slow

Response

Typical Example

8 90 Duo in small club

6 92

4 95 Subway Train

3 97

2 100 Veryloudclassicalmusic

1.5 102

1 105 Greg and Ben screaming at Troy

about deadlines

0.5 110

0.25 or less 115 Loudest parts at a rock concert

Part No. SW0842 Rev. C 07/11

What? Me read a manual?

Before you begin, please make sure you read the

Safety Instructions on page 2 and Getting Started

on page 4.

Your new Mackie SRM1801 powered subwoofers

are designed to set up quickly and operate easily.

We know it’s often seen as a sign of weakness to

read a manual, along with asking for directions

when lost, but we hope you will read the rest of the

manual, at least while nobody is looking.

It is important to keep your receipt in a

safe place, and not a bad idea to write your

product information below for future reference

(i.e., insurance claims, tech support, return

authorization, etc.).

Don’t forget to visit our website at www.mackie.com

for more information about this and other Mackie products.

Subwoofer 1 Subwoofer 2

Please write the serial number for your SRM1801 here

(or for both SRM1801’s if you have two) for future reference

(i.e., insurance claims, tech support, return authorization, etc.):

Purchased at:___________________________________ Date of Purchase:_____________

CONTENTS

SAFETY INSTRUCTIONS 2 ...........................................

GETTING STARTED 4 ...................................................

INTRODUCTION 5 ......................................................

HOOKUP DIAGRAMS............................................... 6

MACKIE SRM1801 FEATURES 8 .................................

1. IEC AC RECEPTACLE 8 .....................................

2. POWER ..................................................... 8

3. INPUTS ...................................................... 9

4. FULL RANGE OUTPUTS 9 ................................

5. HIGH PASS OUTPUTS 9 ..................................

6. POLARITY .................................................. 9

7. LEVEL ....................................................... 10

8. THERMAL LED 10 ...........................................

9. OL LED 10 .....................................................

10. SIGNAL LED 10 ..............................................

11. POWER LED 10 ..............................................

INS AND OUTS OF POLARITY 11 .................................

PROTECTION CIRCUITS 12 ..........................................

LIMITING 12 ..............................................................

OVEREXCURSION PROTECTION 12 .............................

THERMAL PROTECTION 12 .........................................

PLACEMENT 12 ..........................................................

CARE AND MAINTENANCE 12 .....................................

APPENDIX A: SERVICE INFORMATION 13 ....................

APPENDIX B: CONNECTIONS ................................. 15

APPENDIX C: SRM1801 SPECIFICATIONS 16 ...............

MACKIE LIMITED WARRANTY 18 ................................

Produktspecifikationer

Varumärke:	Mackie
Kategori:	Subwoofer
Modell:	SRM1801
Färg på produkten:	Zwart
Vikt:	1410 g
Bredd:	36 mm
Djup:	176 mm
Höjd:	182 mm
Användarmanual:	Ja
Blåtand:	Ja
Processorfrekvens:	2.5 GHz
Processorfamilj:	Intel® Core™ i5
Processormodel:	i5-6500T
Antal processorkärnor:	4
Inkluderar operativsystem:	Windows 7 Professional
Placeringsstöd:	Horizontaal/Verticaal
Ethernet LAN:	Ja
Integrerad minneskortläsare:	Nee
Ljudsystem:	HD
Processor litografi:	14 nm
Inkluderar AC-adapter:	Ja
Antal USB 2.0-portar:	2
Antal HDMI-portar:	1
Mikrofon, linjeingång:	Nee
DVI-port:	Nee
Antal Ethernet LAN (RJ-45)-portar:	1
Monteringsalternativ för kabellås:	Ja
Kabellåsspårtyp:	Kensington
Lösenordsskydd:	Ja
Nätförsörjning:	65 W
Internminne:	8 GB
Förvarings media:	HDD
Internminnestyp:	DDR3L-SDRAM
HDMI-version:	1.4
Antal DisplayPorts:	1
Ethernet LAN, dataöverföringshastigheter:	10,100,1000 Mbit/s
Kabelteknik:	10/100/1000Base-T(X)
Förvaringstemperatur:	-40 - 65 °C
Intel® Wireless Display (Intel® WiDi):	Ja
Antal portar USB 3.2 Gen 1 (3.1 Gen 1) Typ A:	4
Processoruttag:	LGA 1151 (Socket H4)
Stepping:	R0
Systembuss:	8 GT/s
Processor antal trådar:	4
PCI Express-kortplatsversion:	3.0
Processorns driftlägen:	64-bit
Processorns cache:	6 MB
Busstyp:	DMI3
PCI Express-konfigurationer:	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP):	35 W
Kodnamnsprocessor:	Skylake
Maximalt antal PCI Express-linjer:	16
Typ av processorcache:	Smart Cache
ECC stöds av processor:	Nee
Processorfabrikant:	Intel
Operativsystems arkitektur:	64-bit
Maximalt internminne:	16 GB
Total lagringskapacitet:	500 GB
Typ av optisk enhet:	Nee
Inbyggd grafikadapter:	Ja
Familjens inbyggda grafikadapter:	Intel® HD Graphics
Inbyggd grafikadaptermodell:	Intel® HD Graphics 530
Grundläggande frekvens inbyggd grafikadapter:	350 MHz
Inbyggd grafikadapter dynamisk frekvens (max):	1100 MHz
Inbyggt grafikkort-ID:	0x1912
Maximalt minne inbyggd grafikadapter:	1.7 GB
Inbyggd grafikadapter DirectX-version:	12.0
Inbyggd grafikadapter OpenGL version:	4.4
Instruktionsuppsättningar som stöds:	SSE4.2, AVX 2.0, SSE4.1
Intel® My WiFi Technology (Intel® MWT):	Nee
Intel® Hyper Threading Technology (Intel® HT Technology):	Nee
Intel® Turbo Boost-teknik:	2.0
Intel® Quick Sync-videoteknik:	Ja
Intel® InTru™ 3D-teknik:	Ja
Intel® Clear Video HD-teknik (Intel® CVT HD):	Ja
Intel® Insider™:	Ja
Intel® Flex Memory Access:	Nee
Intel® AES nya instruktioner (Intel® AES-NI):	Ja
Förbättrad Intel SpeedStep-teknik:	Ja
Kör Disable Bit:	Ja
Idle stater:	Ja
Termisk övervakningsteknik:	Ja
CPU-konfiguration (max):	1
Intel® Enhanced Halt State:	Ja
Intel® Clear Video Technology för mobila internetenheter (Intel® CVT för MID):	Ja
Intel® VT-x med utökade sidtabeller (EPT):	Ja
Inbyggda alternativ tillgängliga:	Nee
Grafik & IMC litografi:	14 nm
Intel® Small Business Advantage (Intel® SBA):	Ja
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Clear Video-teknik:	Ja
Intel® Software Guard Extensions (Intel® SGX):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Processorpaketstorlek:	37.5 x 37.5 mm
Konfliktfri processor:	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Versie Intel® Identity Protection Technology:	1.00
Versie Intel® Secure Key Technology:	1.00
ARK ID-processor:	88183
Intel® Trusted Execution Technology:	Ja
Intel® TSX:	Ja
Intel® Stable Image Platform Program (SIPP):	Ja
Versie Intel® Stable Image Platform Program (SIPP):	1.00
Intel® TSX-NI-version:	1.00
Intel® Anti-Theft Technology (Intel® AT):	Nee
Kombinerad hörlurs/mikrofonport:	Ja
Förvaringsfuktighet:	5 - 95 procent
Maximal processorturbofrekvens:	3.1 GHz
Processorkod:	SR2BZ
Diskret grafikadaptermodell:	Niet beschikbaar
Bostadstyp:	mini PC
Maximalt internminne som stöds av processorn:	64 GB
Minnestyper som stöds av processorn:	DDR3L-SDRAM, DDR4-SDRAM
Klockminneshastigheter som stöds av processorn:	2133,1333,1600,1866 MHz
Klockhastighetsminne:	1600 MHz
Minnesplatser:	2x SO-DIMM
Antal skärmar som stöds (av inbyggd grafikadapter):	3
Antal installerade processorer:	1
Minnesbandbredd som stöds av processorn (max):	34.1 GB/s
Antal lagringsenheter installerade:	1
Linjeutgång:	Ja
Chipset moderkort:	Intel® H110
Inkluderar monitor:	Nee
Skalbarhet:	1S
Specifikation för termisk lösning:	PCG 2015A
Höjd, drift:	-15.2 - 3048 m
Höjd vid förvaring:	-15.2 - 10668 m
Antalet installerade hårddiskar:	1
HDD kapacitet:	500 GB
HDD-gränssnitt:	SATA III
FSB-paritet:	Nee
Bussprocessor på framsidan:	- MHz
Tcase:	66 °C
Intel® efterfrågebaserad växling:	Nee
Burstfrekvens för inbyggd grafikadapter:	1100 MHz
Medföljande drivrutiner:	Ja
Processorserie:	Intel Core i5-6500 Desktop series
Valfritt operativsystem medföljer:	Windows 10 Pro
Intel® Dual Display Capable Technology:	Nee
Intel® FDI-teknik:	Nee
Intel® Rapid Storage Technology:	Nee
Intel® Fast Memory Access:	Nee
Intel® Smart Cache:	Ja
Intel® Small Business Advantage (SBA)-version:	1.00
Minneskanal:	Dubbelkanaals
Intel® segmenttaggning:	Enterprise, Small Business
Grafikkort, stöd för Open GL:	Ja
Intel® HD-grafik:	Ja
Intel® Inbyggd Visuals-teknik:	Ja
Volym:	1.2 l
Wifi:	Ja
Drifttemperatur (TT):	5 - 35 °C
Relativ luftfuktighet i drift (VV):	20 - 80 procent
Typ produkt:	Mini PC
Spänningsminne stöds av processor:	1.35 V
Vattenkylningssystem:	Nee
Processorgenerering:	Zesde generatie Intel® Core™ i5
