MULTIMEDIA RECEIVER
INSTRUCTION MANUALS

2
CONTENTS
PRECAUTION........................................................ 2
SPECIFICATION .................................................... 2
FRONT PANEL ....................................................... 3
REMOTE CONTROL .............................................. 4
MP4/MP5 OPERATION .......................................... 5
INSTALLATION ...................................................... 6
TROUBLE SHOOTING ........................................... 7
PRECAUTIONS
Use only in a 12-volt DC negative-ground electrical system.
Be sure to connect the color coded leads according to the
diagram.
Incorrect connections may cause the unit to malfunction or
damage the vehicles, electrical system.
Be sure to connect the speaker (-) leads to the speaker (-)
terminal.
Never connect the left and right channel speaker cables each
other or to the vehicle body.
Make sure all the connections are completely correct before
turning on your unit.
Using a fuse with a higher amperage rating may cause
serious damage to the unit.
DO NOT attempt to disassemble the unit.
Laser beams from the optical pick up are dangerous to the
eyes.
Do NOT block vents or radiator panels. Doing so many
cause heat to build up inside and may result in fire.
Make sure those pins or other foreign objects do not get
inside the unit; they may cause malfunctions, or create safety
hazards such as electrical shock or laser beam exposure.
Keep the volume at a level at which you can hear outside
warning sounds (horns sirens, etc.).
Stop the vehicle before carrying out any operation that could
interfere with your driving.
Do NOT work in extremely high or low temperature.
Be sure the temperature inside the vehicle is between +60℃
and -10℃ before turning on your unit.
SPECIFICATION
GENERAL
Power Supply Requirements
Chassis Dimensions
Bass (at 100 Hz)
Treble (at 10 kHz)
Maximum Output Power
Safety fuse
DC 12 Volts,
Negative Ground
178x 92x 50 mm
+ 10 dB / 10 dB
+ 10 dB / 10 dB
4 x 40W
15 Ampere (max.)
FM STEREO RADIO
Frequency Coverage
IF
Sensitivity(S/N=30dB)
Stereo Separation
87.5 to 108.0 Mhz
10.7 Mhz
10dB
30 dB
MW STEREO RADIO
Frequency Coverage
IF
Sensitivity(S/N=20dB)
522 to 1620 kHz
450 kHz
32 dBu
ACCESSORIES
Mounting Bracket(Half Sleeve)
Trim plate
Mounting Screw M5
Rubber
Release key
User manual
Wire connector
Remote control
1
1
1
1
2
1
1
1
Note:
Due to continuous product improvement, specifications and
design are subject to change without prior notice.

3
FRONT PANEL
1.
Press this button to switch on the unit. When the system is on,
press this button to shut off the sound output and press again
to resume.
When the system is on, press and hold this button to turn off
the unit.
2/9. I<</>>I
In radio mode, press the keys to search for a station
automatically, press and hold to search for a station
manually.
In playback mode, press these keys to select the track you
want to play. Press and hold to active fast forward or fast
rewind search.
3/10. ▲ / ▼
In radio mode, press the buttons to select the previous or next
preset stations.
In playback mode, press the buttons to select a 10+or 10-
song.
A Picture viewing can be rotated by pressing the button.
4. AF/ >II
In radio mode, press this button to turn on or off AF function.
In playback mode, press the button to pause/start play.
5. VOL
Rotating: Rotate to adjust the volume level.
Press once: Press and rotate to select the functions provided.
Following functions can be accessed by press the volume
control knob; in the order specified:
VOL→BASS→TREB→BAL→FAD →SUBW
Rotate the volume control to change the setting of these
functions.
In radio mode, press and hold to enter system setup.
Press I<< / >>I button to select the BEEP, CLO ADJ , CLO
MODE, RADIO AREA and TFT BRIGHT settings and press
VOL button to confirm.
In BEEP mode, press the I<< / >>I button to select turn ON
the BEEP function, press again to resume.
In CLO ADJ mode, press I<< / >>I button to start the hour
setting or minute setting.
In CLO MODE mode, press I<< / >>I button to select 12H
or 24 H mode.
In AREA mode, press I<</>>I button to select one of the
following areas: EUROPE, USA, OIRT, JAPAN,M-EAST,
AUSTRALIA, LATIN and ASIA.
In TFT BRIGHT mode, press I<< / >>I button to adjust the
TFT brightness (0~20), the defaulted is 10.
In the above setting, press VOL button to confirm then press
VOL button again to exit.
6. REL: Press this button to release the front panel.
7. IR windows
8. MODE
Press the button to switch between the input modes.
11. AMS/BAND
In radio mode,
press once: To select one of the radio bands;
press and hold : To store the station into the memory in the
descending order of the instantaneous signal strength.
In playback mode, press the button to switch to audio list,
video list and picture list.
12. AUX IN
Insert audio cord, press MODE button on the unit to switch
to AUX mode.
13. TFT display
14. SD Card slot
Insert SD card, it will play the files of SD card automatically.
Note: Once the SD cards could not eject after pressing, just
take it out manually.
15. USB insert slot
Insert USB device, it will play the files in it automatically.
