Sida 1/1
POWER
MENU
VIDEO
SELECT
VIDEO
MODE
SELECT
MODE
TFT LCD
MO N I TO R M O BI L E
REMOTE CONTROL
1. Power
2. V1/V2 Change
3. Positive Increase
4. Menu
5. Negative Decrease
6. Mode Selection
POWER
1
2
3
4
5
6
Connection
MONITOR:
1. IR
2. R/C Window
3. Power
4. Mode
5. Negative Decrease
6. Menu
7. Positive Increase
CAUTION:
For your safety, please rotate the angle of the display or turn off the
display while driving.
SPECIAL STATEMENT:
LCD may have a few bright dots,which is normal for the matrix
display technology, and doesn't indicate defects of faults
NOTICE:
Please operate instruction manual completely before use;
The unit is manufactured with precision elements pay attention to
protection against dampeness;
Prevent the hard object from scratching LCD surface;
High voltage inside non-technical authorized person is not allowed
to dismantle the unit.
SPECIFICATIONS:
Display size: 6 inch (16:9)
Pixel : 1200(w)×234(h)
Power supply: DC 12V
Input: Dual video input ; two stereo audio input
System: PAL/NTSC auto switching
All functions are controlled by remote control; OSD menu
Mode: 16:9 and 4:3 auto switching
Blue screen when no signal
IR1: L channel 2.3MHZ, R channel 2.8MHZ
IR2: L channel 3.2MHZ, R channel 3.8MHZ
MONITOR with IR
Red to battery+12V
Black to grounding
Video 1
Video 2
Audio1(Red)
Audio1(White)
Audio2(Red)
Audio2(White)
1 2 3 4 5 6 7
