Sida 1/72

GB Battery Charger 3 ................. KK Аккумуляторларға арналған

зарядтау құрылғысы ..........36

FChargeur 5 ............................ PL

Ładowarka akumulatorów

...39

DLadegerät ........................... 7 HU Akkumulátortöltő .............41

ICarica batteria 9 ................... SK Nabíjačka batérií .............43

NL Accuoplader .....................11 CS Nabíječka akumulátoru ...45

ECargador de Batería ........13 SL Polnilnik akumulatorjev ... 47

PCarregador de Bateria .....15 SQ Karikuesi i baterisë .........49

DK Akku-ladeaggregat ..........17 BG Зарядно устройство за

акумулаторна батерия ...51

GR Φρτιστής μπαταρίας..........18 HR Punjač baterija .................53

TR Batarya Şarj Cihazı ..........21 MK Полнач за батерии .........55

SBatteriladdar ....................22 SR Пуњач батерија ..............57

NBatterilader ......................24 RO

Încărcător de acumulatori

... 59

FIN Akkulataaja ......................26 UK Зарядний пристрій .........61

LV Akumulatora lādētājs ......28

ZHCN

电池充电器 (保留备用) ..........64

LT Akumuliatorių įkroviklis ...30

ZHTW

電池充電器...........................66

EE Akulaadija ........................32 PR ....69

RUS Зарядное Устройство Для

Аккумуляторов ................34 AR ....71

DC10SB

DC10WD

(DC10SB)

≧32mm

(1-9/32”)

≧50mm

(1-31/32”)

≧75mm

(2-31/32”)

≧115mm

(4-17/32”)

110mm

(4-11/32”)

≧30mm

(1-3/16”)

≧30mm

(1-3/16”)

8mm

(5/16”)

≧180mm

(7-3/32”)

69mm

(2-23/32”)

≧90mm

(3-9/16”)

(DC10WD)

≧30mm

(1-3/16”)

≧40mm

(1-19/32”)

≧50mm

(1-31/32”)

≧105mm

(4-5/32”)

≧65mm

(2-9/16”)

113mm

(4-15/32”)

≧55mm

(2-3/16”)

≧35mm

(1-3/8”)

4mm

(5/32”)

113mm

(4-15/32”)

≧115mm

(4-17/32”)

3 4

ENGLISH

Warning: This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance shall not be

made by children without supervision.

Symbols

The followings show the symbols used for the equipment. Be sure that you understand their meaning before use.

• Indoor use only. • Read instruction manual.

• DOUBLE INSULATION • Ready to charge.

• Charging. • Charging complete.

• Delay charge (Battery cooling, or too cold

battery). • Defective battery.

• Delay charge (Too hot or too cold battery). • Cooling abnormality.

• Do not short battery. • Do not destroy battery by re.

• Do not expose battery to water or rain. • Always recycle battery.

• Only for EU countries

Do not dispose of electric equipment or battery pack together with household waste material!

In observance of the European Directives, on Waste Electric and Electronic Equipment and Batteries and

Accumulators and Waste Batteries and Accumulators and their implementation in accordance with national laws,

electric equipment and batteries and battery pack(s) that have reached the end of their life must be collected

separately and returned to an environmentally compatible recycling facility.

CAUTION:

1. SAVE THESE INSTRUCTIONS – This manual contains

important safety and operating instructions for battery

charger.

2. Before using battery charger, read all instructions and

cautionary markings on (1) battery charger, (2) battery, and

(3) product using battery.

3. CAUTION – To reduce risk of injury, charge only Makita type

rechargeable batteries. Other types of batteries may burst

causing personal injury and damage.

4. Non-rechargeable batteries cannot be charged with this

battery charger.

5. Use a power source with the voltage specied on the

nameplate of the charger.

6. Do not charge the battery cartridge in presence of ammable

liquids or gases.

7. Do not expose charger to rain or snow.

8. Never carry charger by cord or yank it to disconnect from

receptacle.

9. After charging or before attempting any maintenance or

cleaning, unplug the charger from the power source. Pull by

plug rather than cord whenever disconnecting charger.

10. Make sure cord is located so that it will not be stepped on,

tripped over, or otherwise subjected to damage or stress.

11. Do not operate charger with damaged cord or plug. If the cord

or plug is damaged, ask Makita authorized service center to

replace it in order to avoid a hazard.

12. Do not operate or disassemble charger if it has received a

sharp blow, been dropped, or otherwise damaged in any way;

take it to a qualied serviceman. Incorrect use or reassembly

may result in a risk of electric shock or re.

13. Do not charge battery cartridge when room temperature is

BELOW 10°C (50°F) or ABOVE 40°C (104°F). At the cold

temperature, charging may not start.

14. Do not attempt to use a step-up transformer, an engine

generator or DC power receptacle.

15. Do not allow anything to cover or clog the charger vents.

Charging

1. Plug the battery charger into the proper AC voltage source.

Charging light will ash in green color repeatedly.

2. Insert the battery cartridge into charger until it stops adjusting

to the guide of charger.

3. When the battery cartridge is inserted, the charging light color

will change from green to red and charging will begin. The

charging light will keep lighting up steadily during charging.

One red charging light indicates charged condition in 0

– 80% and red and green ones indicate 80 – 100%. The

80% indication mentioned above is approximate value. The

indication may differ according to battery temperature or

battery condition.

4. With nish of charge, the charging lights will change from red

and green ones to green one.

5. Charging time varies by temperature (10°C (50°F) – 40°C

(104°F)) that battery cartridge is charged at and conditions of

the battery cartridge, such as a battery cartridge which is new

or has not been used for a long period of time.

6. After charging, remove the battery cartridge from charger and

unplug the charger.
