INSTRUCTION MANUAL

Cordless Angle Grinder

DGA419

DGA469

DGA519

ENGLISH: Original instructions

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: DGA419 DGA469 DGA519

Wheel diameter 100 mm (4″) 115 mm (4-1/2″) 125 mm (5″)

Max. wheel thickness 6 mm

Rated speed (n) 8,500 min-1

Overall length 396 mm

Rated voltage D.C. 18 V

Net weight 2.4 - 3.0 kg 2.5 - 3.1 kg

• Due to our continuing program of research and development, the specications herein are subject to change

without notice.

• Specications may dier from country to country.

• The weight may dier depending on the attachment(s), including the battery cartridge. The lightest and heavi-

est combination, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge and charger

Battery cartridge BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /

BL1840B / BL1850 / BL1850B / BL1860B

Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /

DC18SH

•

Some of the battery cartridges and chargers listed above may not be available depending on your region of residence.

WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges

and chargers may cause injury and/or re.

Symbols

The followings show the symbols used for the equip-

ment. Be sure that you understand their meaning before

use.

Read instruction manual.

Wear safety glasses.

Ni-MH

Li-ion

Only for EU countries

Do not dispose of electric equipment or

battery pack together with household waste

material!

In observance of the European Directives,

on Waste Electric and Electronic

Equipment and Batteries and Accumulators

and Waste Batteries and Accumulators

and their implementation in accordance

with national laws, electric equipment and

batteries and battery pack(s) that have

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

The tool is intended for grinding, sanding and cutting of

metal and stone materials without the use of water.

Noise

The typical A-weighted noise level determined accord-

ing to EN60745-2-3:

Model DGA419

Sound pressure level (L

pA) : 80 dB(A)

Uncertainty (K) : 3 dB(A)

Model DGA469

Sound pressure level (L

pA) : 80 dB(A)

Uncertainty (K) : 3 dB(A)

Model DGA519

Sound pressure level (L

pA) : 80 dB(A)

Uncertainty (K) : 3 dB(A)

The noise level under working may exceed 80 dB (A).

NOTE:

The declared noise emission value(s) has been

measured in accordance with a standard test method

and may be used for comparing one tool with another.

NOTE:

The declared noise emission value(s) may

also be used in a preliminary assessment of exposure.

WARNING: Wear ear protection.

WARNING: The noise emission during actual

use of the power tool can dier from the declared

value(s) depending on the ways in which the

tool is used especially what kind of workpiece is

processed.

WARNING: Be sure to identify safety mea-

sures to protect the operator that are based on an

estimation of exposure in the actual conditions of

use (taking account of all parts of the operating

cycle such as the times when the tool is switched

o and when it is running idle in addition to the

trigger time).

3 ENGLISH

Vibration

The vibration total value (tri-axial vector sum) deter-

mined according to EN60745-2-3:

Model DGA419

Work mode: surface grinding with normal side grip

Vibration emission (a

h, AG) : 4.5 m/s2

Uncertainty (K) : 1.5 m/s2

Work mode: surface grinding with anti vibration side grip

Vibration emission (a

h, AG) : 6.0 m/s2

Uncertainty (K) : 1.5 m/s2

Model DGA469

Work mode: surface grinding with normal side grip

Vibration emission (a

h, AG) : 5.0 m/s2

Uncertainty (K) : 1.5 m/s2

Work mode: surface grinding with anti vibration side grip

Vibration emission (a

h, AG) : 5.5 m/s2

Uncertainty (K) : 1.5 m/s2

Model DGA519

Work mode: surface grinding with normal side grip

Vibration emission (a

h, AG) : 5.5 m/s2

Uncertainty (K) : 1.5 m/s2

Work mode: surface grinding with anti vibration side grip

Vibration emission (a

h, AG) : 7.0 m/s2

Uncertainty (K) : 1.5 m/s2

NOTE: The declared vibration total value(s) has been

measured in accordance with a standard test method

and may be used for comparing one tool with another.

NOTE: The declared vibration total value(s) may also

be used in a preliminary assessment of exposure.

WARNING:

The vibration emission during actual

use of the power tool can dier from the declared val-

ue(s) depending on the ways in which the tool is used

especially what kind of workpiece is processed.

WARNING:

Be sure to identify safety measures

to protect the operator that are based on an estima-

tion of exposure in the actual conditions of use (tak-

ing account of all parts of the operating cycle such

as the times when the tool is switched o and when

it is running idle in addition to the trigger time).

WARNING: The declared vibration emission

value is used for main applications of the power tool.

However if the power tool is used for other applica-

tions, the vibration emission value may be dierent.

EC Declaration of Conformity

For European countries only

The EC declaration of conformity is included as Annex A

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING:

Read all safety warnings, instruc-

tions, illustrations and specications provided with this

power tool. Failure to follow all instructions listed below

may result in electric shock, re and/or serious injury.

Save all warnings and instruc-

tions for future reference.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodied plugs and matching outlets will

reduce risk of electric shock.

2. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators. There is an increased risk of elec-

tric shock if your body is earthed or grounded.

3. Do not expose power tools to rain or wet con-

ditions. Water entering a power tool will increase

the risk of electric shock.

4. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

When operating a power tool outdoors, use an exten-

sion cord suitable for outdoor use. Use of a cord suit-

able for outdoor use reduces the risk of electric shock.

6. If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

Power tools can produce electromagnetic elds

(EMF) that are not harmful to the user. However,

users of pacemakers and other similar medical

devices should contact the maker of their device and/

or doctor for advice before operating this power tool.

Personal safety

1. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the inuence of drugs, alcohol or med-

ication. A moment of inattention while operating

power tools may result in serious personal injury.

2. Use personal protective equipment. Always

wear eye protection. Protective equipment such

as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions

will reduce personal injuries.

3. Prevent unintentional starting. Ensure the

switch is in the o-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

your nger on the switch or energising power tools

that have the switch on invites accidents.
