INSTRUCTION MANUAL
Cordless Grass Trimmer
DUR368A
DUR368L
ENGLISH: Original instructions
Read before use.
2 ENGLISH
SPECIFICATIONS
Model: DUR368A DUR368L
Handle type Bike handle Loop handle
No load speed
(at each rotation speed level)
Cutter blade / Nylon cutting
head / Plastic blade
3: 6,500 min-1
2: 5,300 min-1
1: 3,500 min-1
Overall length
(without cutting tool)
1,758 mm
Nylon cord diameter 2.0 - 2.4 mm
Applicable cutting tool and
cutting diameter
3-tooth blade
(P/N: 195298-3)
230 mm
4-tooth blade
(P/N: B-14118)
230 mm
8-tooth blade
(P/N: B-14130)
230 mm
Nylon cutting head
(P/N: 198893-8)
350 mm
Plastic blade
(P/N: 198383-1)
255 mm
Rated voltage D.C. 36 V
Net weight 4.1 - 4.7 kg 3.9 - 4.5 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge, battery adapter and charger
Battery cartridge BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /
BL1840B / BL1850 / BL1850B / BL1860B
Battery Adapter BAP182 / BL36120A
Charger
DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF / DC18SH
• Some of the battery cartridges, battery adapters and chargers listed above may not be available depending on
your region of residence.
WARNING: Only use the battery cartridges, battery adapters and chargers listed above. Use of any
otherbatterycartridges,batteryadaptersandchargersmaycauseinjuryand/orre.
Noise
Applicable standard : ISO22868
Model DUR368A
Cutting tool Sound pressure level (LpA)
dB(A)
Sound power level (LWA)
dB(A)
LpA dB(A)
Uncertainty (K)
dB(A)
LWA dB(A)
Uncertainty (K)
dB(A)
4-tooth blade 74.7 1.0 89.2 1.6
Nylon cutting head 76.4 1.6 89 1.0
Plastic blade 75.1 0.3 86 0.4
3 ENGLISH
Model DUR368L
Cutting tool Sound pressure level (LpA)
dB(A)
Sound power level (LWA)
dB(A)
LpA dB(A)
Uncertainty (K)
dB(A)
LWA dB(A)
Uncertainty (K)
dB(A)
4-tooth blade 74.7 1.0 89.2 1.6
Nylon cutting head 76.4 1.6 89 1.0
Plastic blade 75.1 0.3 86 0.4
• Even if the sound pressure level listed above is 80 dB (A) or less, the level under working may exceed 80 dB
(A). Wear ear protection.
NOTE: The declared noise emission value(s) has been measured in accordance with a standard test method and
may be used for comparing one tool with another.
NOTE: The declared noise emission value(s) may also be used in a preliminary assessment of exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual use of the power tool can differ from the declared val-
ue(s) depending on the ways in which the tool is used especially what kind of workpiece is processed.
WARNING: Be sure to identify safety measures to protect the operator that are based on an estimation
of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the
times when the tool is switched off and when it is running idle in addition to the trigger time).
Vibration
Applicable standard : ISO22867
Model DUR368A
Cutting tool Left hand Right hand
ah,W (m/s2) Uncertainty K
(m/s2)
ah,W (m/s2) Uncertainty K
(m/s2)
4-tooth blade 2.5 1.5 2.5 1.5
Nylon cutting head 2.5 1.5 2.5 1.5
Plastic blade 2.5 1.5 2.5 1.5
Model DUR368L
Cutting tool Left hand Right hand
ah,W (m/s2) Uncertainty K
(m/s2)
ah,W (m/s2) Uncertainty K
(m/s2)
4-tooth blade 2.5 1.5 2.5 1.5
Nylon cutting head 2.5 1.5 2.5 1.5
Plastic blade 2.5 1.5 2.5 1.5
NOTE: The declared vibration total value(s) has been measured in accordance with a standard test method and
may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also be used in a preliminary assessment of exposure.
WARNING: The vibration emission during actual use of the power tool can differ from the declared
value(s) depending on the ways in which the tool is used especially what kind of workpiece is processed.
WARNING: Be sure to identify safety measures to protect the operator that are based on an estimation
of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the
times when the tool is switched off and when it is running idle in addition to the trigger time).
