Sida 1/16
1
ENGLISH (Original instructions)
INSTRUCTION MANUAL
DOUBLE INSULATION
IMPORTANT: Read Before Using.
Angle Grinder
GA7030,GA7030S
GA7040S
GA9030, GA9030S
GA9040S
007051
2
ENGLISH (Original instructions)
SPECIFICATIONS
Model
GA7030/GA7030S
GA7040S
GA9030/GA9030S
GA9040S
Depressed center wheel diameter 180 mm 230 mm
Spindle thread M14 M14
Rated speed (n)/ No load speed (n
0) 8,500 min-1
6,600 min-1
Overall length 511 mm 511 mm
Net weight 6.0 kg 6.4 kg 6.3 kg 6.7 kg
Safety class /II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END202-6
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ Wear safety glasses.
･ Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible recycling
facility.
ENE048-1
Intended use
The tool is intended for grinding, sanding and cutting of
metal and stone materials without the use of water.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
ENF100-1
For public low-voltage distribution systems of
between 220 V and 250 V.
Switching operations of electric apparatus cause voltage
fluctuations. The operation of this device under
unfavorable mains conditions can have adverse effects
to the operation of other equipment. With a mains
impedance equal or less than 0.23 Ohms it can be
presumed that there will be no negative effects. The
mains socket used for this device must be protected with
a fuse or protective circuit breaker having slow tripping
characteristics.
For Model GA7030,GA7030S
ENG102-3
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA) : 89 dB(A)
Sound power level (L
WA) : 100 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG208-5
Vibration
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Work mode : surface grinding
Vibration emission (ah,AG) : 6.5 m/s2
Uncertainty (K) : 1.5 m/s2
The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
The declared vibration emission value is used for main
applications of the power tool. However if the power tool
is used for other applications, the vibration emission
value may be different.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
3
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
For Model GA7040S
ENG102-3
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA) : 90 dB(A)
Sound power level (L
WA) : 101 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG208-5
Vibration
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Work mode : surface grinding
Vibration emission (ah,AG) : 7.5 m/s2
Uncertainty (K) : 1.5 m/s2
The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
The declared vibration emission value is used for main
applications of the power tool. However if the power tool
is used for other applications, the vibration emission
value may be different.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
For Model GA9030, GA9030S
ENG102-3
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA) : 90 dB(A)
Sound power level (L
WA) : 101 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG208-5
Vibration
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Work mode : surface grinding
Vibration emission (ah,AG) : 6.5 m/s2
Uncertainty (K) : 1.5 m/s2
The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
The declared vibration emission value is used for main
applications of the power tool. However if the power tool
is used for other applications, the vibration emission
value may be different.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
For Model GA9040S
ENG102-3
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA) : 90 dB(A)
Sound power level (L
WA) : 101 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG208-5
Vibration
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Work mode : surface grinding
Vibration emission (ah,AG) : 5.5 m/s2
Uncertainty (K) : 1.5 m/s2
The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
The declared vibration emission value is used for main
applications of the power tool. However if the power tool
is used for other applications, the vibration emission
value may be different.
