GB Nibbler INSTRUCTION MANUAL
S Nibblingsmaskin BRUKSANVISNING
N Nibbler BRUKSANVISNING
FIN Nakertaja KÄYTTÖOHJE
LV Skārda cirtnis LIETOŠANAS INSTRUKCIJA
LT Skylių kalimo mašina NAUDOJIMO INSTRUKCIJA
EE Plekilõikur KASUTUSJUHEND
RUS Высечные ножницы
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
JN3201
2
1
2
1 013355
1 2
2 013356
1
2
3
3 013357
1
23
4 013358
1
23
4
5
5 004785 6 013359
7 013360
1
2
3
4
5
8 004792
1
2
9 004793
1
2
3
10 004794
1
11 001145
1
2
12 013361
3
ENGLISH (Original instructions)
Explanation of general view
1-1. Stainless steel gauge 2.5 mm
(3/32")
1-2. Mild steel gauge 3.2 mm (1/8")
2-1. Switch trigger
2-2. Lock button
3-1. Wrench
3-2. Lock nut
3-3. Die holder
4-1. Punch
4-2. Screw
4-3. Wrench
5-1. Cutting edge
5-2. Punch
5-3. Groove
5-4. Punch holder
5-5. Pin
8-1. Screw
8-2. Hex wrench
8-3. Washer
8-4. Insert washer in between
8-5. Die
9-1. Grind/sharpen; 0.3 - 0.4 mm
(1/64")
9-2. Remove dull portion
10-1. 3.5 -4.0 mm (1/8" - 5/32")
10-2. Die
10-3. Washer
11-1. Limit mark
12-1. Screwdriver
12-2. Brush holder cap
SPECIFICATIONS
Model JN3201
Steel up to 400 N/mm2 3.2 mm / 10 ga
Steel up to 600 N/mm2 2.5 mm / 13 ga
Steel up to 800 N/mm2 1.0 mm / 20 ga
Max. cutting capacities
Aluminum up to 200 N/mm2 3.5 mm / 10 ga
Outside edge 128 mm
Min. cutting radius Inside edge 120 mm
Strokes per minute (min-1
) 1,300
Overall length 225 mm
Net weight 3.4 kg
Safety class /II
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE037-1
Intended use
The tool is intended for cutting sheet steel and stainless
sheet steel.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN60745:
Sound pressure level (L
pA) : 81 dB(A)
Sound power level (L
WA) : 92 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode : cutting sheet metal
Vibration emission (ah) : 10.0 m/s2
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
