ENGLISH (Original instructions)
INSTRUCTION MANUAL
DOUBLE INSULATION
IMPORTANT: Read Before Using.
Slide Compound Miter Saw
LS1216
LS1216L
LS1216F
LS1216FL
010049
2
ENGLISH (Original instructions)
SPECIFICATIONS
Model LS1216/ LS1216L/ LS1216F/ LS1216FL
Blade diameter 305 mm
Blade body thickness 1.6 mm - 2.4 mm
Hole diameter European countries: 30 mm, other than European countries: 25.4 mm
Max. Miter angle Left 52° , Right 60°
Max. Bevel angle Left and Right 45°
Max. Cutting capacities (H x W)
Bevel angle
Miter angle 45°(left) 0° 45°(right)
0° 59mm×382mm 87mm×382mm 44mm×382mm
69mm×363mm 102mm×363mm 54mm×363mm
35mm 78mm×290 mm 115mm×300mm 61mm×290mm
Thickness of wood facing on guide
fence for increased height of cut 60mm ― 120mm×250mm ―
45°(left and right) 59mm×268mm 87mm×268mm 44mm×268mm
69mm×255mm 102mm×255mm 54mm×255mm
30mm ― 115mm×202mm ―
Thickness of wood facing on guide
fence for increased height of cut 45mm ― 120mm×172mm ―
52°(left and right) ― 87mm×233mm ―
― 102mm×220mm ―
25mm ― 115mm×178mm ―
Thickness of wood facing on guide
fence for increased height of cut 35mm ― 120mm×155mm ―
60°(right) ― 87mm×185mm ―
― 102mm×178mm ―
25mm ― 115mm×140mm ―
Thickness of wood facing on guide
fence for increased height of cut 35mm ― 120mm×122mm ―
Special Max. Cutting capacities
Crown molding 45°type
(with Crown molding stopper used) 203 mm
Base board (H)
(with Horizontal vise used) 165 mm
Special Max Width Cutting Capacities
(with 38 mm (1-1/2") thick platform used)
Bevel angle Miter angle Max. cutting
0° 416 mm
0° 45° (Left and right) 292 mm
Refer to OPERATION for the cutting procedure.
No load speed (min
-1) 3,200
Laser Type (LS1216L,LS1216FL only) Red Laser 650 nm, 1.6mW ( Laser Class 2M )
Dimensions (L x W x H) 806 mm x 640 mm x 721 mm
3
Net weight
For all countries other than European countries
LS1216…26.3 kg
LS1216L/LS1216F …26.4 kg
LS1216FL …26.5 kg
For European countries
LS1216…26.5 kg
LS1216L/LS1216F …26.6 kg
LS1216FL …26.7 kg
Safety class /II
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
• Weight according to EPTA-Procedure 1/2003
END210-6
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ To avoid injury from flying debris, keep
holding the saw head down, after
making cuts, until the blade has come
to a complete stop.
･ When performing slide cut, first pull
carriage fully and press down handle,
then push carriage toward the guide
fence.
･ Do not place hand or fingers close to
the blade.
･ Never look into the laser beam. Direct
laser beam may injure your eyes.
･ Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE006-1
Intended use
The tool is intended for accurate straight and miter
cutting in wood. With appropriate saw blades, aluminum
can also be sawed.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN61029:
Sound pressure level (L
pA) : 91 dB(A)
Sound power level (L
WA) : 100 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN61029:
Vibration emission (ah) : 2.5 m/s2 or less
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
