ENGLISH: Original instructions
INSTRUCTION MANUAL
Rechargeable Green Multi Line
Laser
SK312GD
SK209GD
Read before use.
2 ENGLISH
CONTENTS
SPECIFICATIONS 3 -----------------------------------------------------
Symbols 4 ---------------------------------------------------------------------
Intended use 4 ----------------------------------------------------------------
Laser Beam Related Safety Standards 4 ------------------------------
Safety Declaration 5 --------------------------------------------------------
Noise Related Safety Standards 6 --------------------------------------
Safety Warnings 7 -----------------------------------------------------------
NAMES OF PARTS 13 --------------------------------------------------
Optional Accessories --------------------------------------------------- 13
Installing or removing battery cartridge 14 ----------------------------
Battery Protection System 15 --------------------------------------------
Using the USB adapter (optional accessory) 16 --------------------
Using the Multi Line Laser 17 --------------------------------------------
Installing the Multi Line Laser 17 -------------------------------------
Operating the power switch 18 ---------------------------------------
Brightness selection 18 -------------------------------------------------
Line beam mode selection 19 ----------------------------------------
CHECKING THE ACCURACY ------------------------------------ 21
Checking the horizontal line 21 ---------------------------------------
Checking the plumbing point and vertical line 22 ----------------
Checking the 180°vertical line 23 ------------------------------------
Checking the 90°vertical line 24 --------------------------------------
MAINTENANCE 26 ------------------------------------------------------
3 ENGLISH
SPECIFICATIONS
SK312GD SK209GD
Laser source Line beam: Green semiconductor laser
Lower dot beam: Red semiconductor laser
Laser wavelength 510 to 530 nm (lower dot beam 650 to 660 nm)
Laser output Each 1 mW or less (CLASS 2 LASER PRODUCT)
IEC 60825-1:2014
Laser line emission angle Vertical 130°±10%
180° vertical line 240°±20%
Horizontal 110°±10%
Vertical 130°±10%
Horizontal 110°±10%
Laser dot diameter 1.5 mm / 1 m (lower dot beam)
Laser beam selection Horizontal line /
Horizontal/vertical line /
3-vertical line/horizontal line
Horizontal line /
2-vertical line /
2-vertical line/horizontal line
Brightness selection 3 modes (constant pulse) Eco mode/ Normal mode / Bright mode
Indication method Automatic vertical line indication by gimbal mechanism
Vertical line indication range
±2° (alarm given by light off outside range)
Horizontal
ne-adjustment range
Entire circumference
Control method Magnet damper method
Accuracy Emitted laser ±1 mm / 10 m *(Before shipment from factory)
2-vertical line 90°±0.01°
Power supply Makita battery cartridge / USB adapter
Rated Voltage D.C.10.8V - 12Vmax, D.C. in 5V
Operating time
(when BL1015 or BL1016
is used)
At 3-vertical line/horizontal line
Bright mode: Approx. 10 h
Normal mode: Approx. 16 h
Eco mode: Approx. 21 h
At 2-vertical line/horizontal line
Bright mode: Approx. 15 h
Normal mode: Approx. 23 h
Eco mode: Approx. 28 h
Operating temperature range
-10°C to +40°C (14°F to 104°F)
ESD protective measures Level: 4 (IEC61000-4-2)
Dimensions 87 mm (dia.) x 230 mm (height) (excluding protrusions)
Battery cartridge BL1015, BL1016, BL1020B, BL1021B, BL1040B, BL1041B
Net weight 1.5 kg - 1.6 kg
Tripod screw W 5/8"
NOTE: Use the product in the following operating environment.
• Indoor use
• Altitude:up to 2000m
• Humidity:Maximum relative humidity 80% temperature rise to 31°C (87.8°F) decreasing linearly to
50% relative humidity at 40°C (104°F)
• Pollution degree 3
* Due to our continuing program of research and development, the specications herein are subject to
change without notice.
* Specication values vary according to operating environment conditions and other factors.
* Specications and battery cartridge may differ from country to country.
