Sida 1/32
GB
Blower Instruction Manual
F
Aspirateur Manuel d’instructions
D
Gebläse Betriebsanleitung
I
Soffiatrice-Aspiratore Istruzioni per l’uso
NL
Blazer Gebruiksaanwijzing
E
Sopladora Aspiradora Manual de instrucciones
P
Soprador Aspirador Manual de instruções
DK
Blæser Brugsanvisning
S
Blåsmaskin Bruksanvisning
N
Blåsemaskin Bruksanvisning
SF
Puhallin Käyttöohje
GR Φυοητήρας Οδηγίες χρήσεως
UB1100
UB1101
2
1 2
3 4
5 6
7
4
2
1
3
1
2
5
6
7
10
6
87
9
11
13 12
3
ENGLISH
Explanation of general view
1 Nozzle
2 Blower outlet
3 Suction inlet
4 Dust bag
5 Fastener
6 Switch trigger
7 Lock button
8 Speed control screw
9 Higher
10 Lower
11 Limit mark
12 Screwdriver
13 Brush holder cap
SPECIFICATIONS
Model UB1100 UB1101
Capacities
Air pressure (water column)..................................................................... 5.5 kPa 0 – 5.5 kPa
Max. air volume ....................................................................................... 2.8 m 3/min. 0 – 2.8 m3/min.
No load speed (min–1)................................................................................ 16,000 0 – 16,000
Overall length ............................................................................................. 480 mm 480 mm
Net weight................................................................................................... 1.7 kg 1.7 kg
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
Intended use
The tool is intended for blowing dust.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated in accordance with European Standard
and can, therefore, also be used from sockets without
earth wire.
Safety hints
For your own safety, please refer to the enclosed safety
instructions.
ADDITIONAL SAFETY RULES
ENB017-1
1. Always use protective goggles, a cap and mask
when using the blower.
2. Never point the nozzle at anyone in the vicinity
when using the blower.
3. Always use the dust bag when collecting dust,
chips and the like.
4. Do not collect still smoldering cigarette ashes,
freshly cut metals shavings, screws, nails and
the like.
Warning – Electric shock could occur if used on
wet surfaces. Do not expose to rain. Store
indoors.
5. Never block suction inlet and/or blower outlet.
Increased motor revolution may cause danger-
ous fan breakage.
6. The blower is not intended for use by young chil-
dren or infirm persons without supervision.
7. Young children should be supervised to ensure
that they do not play with the blower.
SAVE THESE INSTRUCTIONS.
OPERATING INSTRUCTIONS
Blowing (Fig. 1)
For dust blowing, attach nozzle to blower outlet, turning
clockwise to lock it in place.
Dust suction (Fig. 2 & 3)
Note:
Dust bags are optional accessories in some countries.
For dust suction, fit nozzle onto suction inlet and dust bag
onto blower outlet.
After the bag fills with dust, empty the contents of the
dust bag into a dust bin by releasing the fastener.
Switch action
CAUTION:
Before plugging in the tool, always check to see that the
switch trigger actuates properly and returns to the “OFF”
position when released.
For UB1100 (Fig. 4)
To start the tool, simply pull the trigger. Release the trig-
ger to stop. For continuous operation, pull the trigger and
then push in the lock button. To stop the tool from the
locked position, pull the trigger fully, then release it.
For UB1101 (Fig. 5)
To start the tool, simply pull the trigger. Tool speed is
increased by increasing pressure on the trigger. Release
the trigger to stop. For continuous operation, pull the trig-
ger and then push in the lock button. To stop the tool from
the locked position, pull the trigger fully, then release it.
A speed control screw is provided so that maximum tool
speed can be limited (variable). Turn the speed control
screw clockwise for higher speed, and counterclockwise
for lower speed.
MAINTENANCE
CAUTION:
Always be sure that the tool is switched off and
unplugged before carrying out any work on the tool.
Replacement of carbon brushes (Fig. 6 & 7)
Replace carbon brushes when they are worn down to the
limit mark. Both identical carbon brushes should be
replaced at the same time.
To maintain product safety and reliability, repairs, mainte-
nance or adjustment should be carried out by a Makita
Authorized Service Center.
