Sida 1/40
User Guide English (2–8)
Guía del usuario Español (9–15)
Guide d'utilisation Français (16–22)
Guida per l'uso Italiano (23–29)
Benutzerhandbuch Deutsch (30–36)
Appendix English (38–39)
2
User Guide ( )English
Introduction
The AVS answers the need for a high-performance equipment package that includes everything
required for streaming and podcasting. This system has a full HD webcam with built-in H.264 video
compression, a high-quality 48 kHz/16-bit USB condenser boundary microphone built into the base,
and a dimmable LED light ring, daylight-balanced, with cool, warm, and diffused daylight filters. The
Marantz AVS is a unique, all-in-one broadcast system that gives any video conferencer, live Internet
streamer, or podcaster high-quality components with a multitude of configurations for creating a
professional presentation. It’s compact and simple, perfect on a desktop, and portable enough to
take on location.
To make the system capable of handling any streaming/podcast task without the need for additional
equipment, the AVS has a high speed, low latency USB-C computer output, an internal USB hub, and
an onboard headphone amplifier that makes audio monitoring a snap. Everything the demanding
streaming/broadcasting enthusiast needs is right here in one convenient, high-performance package.
Please see this guide’s Setup chapter to learn how to integrate the AVS with your audio system, and
then refer to the Operation chapter to start using the AVS.
Box Contents
Tower
Base (with Built-in Microphone)
(3) Lighting Filters (Cool Diffuse, Warm Diffuse, Diffused Daylight)
USB Type-C–to–Type-A Cable
Power Adapter
User Guide
Safety & Warranty Manual
Support
For the latest information about this product (documentation, technical specifications, system
requirements, compatibility information, etc.) and product registration, visit marantzpro.com.
For additional product support, visit marantzpro.com/support.
3
Setup
Connection
Items not listed under Introduction > Box Contents are sold separately.
1. Use the included power adapter to connect the Power Input to a power outlet.
2. Use the included USB cable to connect the USB Port labeled To PC to your computer.
3. Optional: Connect USB flash drives to USB Ports 1 and/or 2. You can to use your computer to
access these drives.
4. Optional: Use a 1/8” (3.5 mm) stereo audio cable to connect this output to the input of an
external mixer, speaker, etc.
5. Optional: Attach the desired lighting filter to the LED Ring Light. Use the Brightness knob to
adjust the brightness of the light ring around it.
Note: Remove the plastic film from the lighting filter before use.
6. Connect 1/8” (3.5 mm) stereo headphones to the Headphone Output. Use the Headphone
Volume knob to adjust the volume.
7. Use the Mix knob to adjust the balance between the microphone signal (Mic) and the signal
from your computer (PC) that you hear in the headphones.
8. Open your video or audio recording software, and select Marantz AVS as your computer’s
default playback and recording devices.
9. You’re now ready to start recording.
