20129 / 20060817 - INVISIBLE SCART 300™
ALL RIGHTS RESERVED MARMITEK © 2006
SCART
INVISIBLE
SCART 300™
USER MANUAL 3
GEBRAUCHSANLEITUNG 11
GUIDE UTILISATEUR 19
MODO DE EMPLEO 27
MANUALE D’ISTRUZIONI 35
GEBRUIKSAANWIJZING 43
20129_20060817_UG_scart300 26-09-2006 11:02 Pagina 1
SAFETY WARNINGS.
• To prevent short circuits, this product should only be used inside and only in dry spaces.
Do not expose the components to rain or moisture. Do not use the product close to a
bath, swimming pool etc.
• Do not expose the components of your systems to extremely high temperatures or bright
light sources.
• Do not open the product: the device contains live parts. The product should only be
repaired or serviced by a qualified repairman.
• In case of improper usage or if you have opened, altered and repaired the product
yourself, all guarantees expire. Marmitek does not accept responsibility in the case of
improper usage of the product or when the product is used for purposes other than
specified. Marmitek does not accept responsibility for additional damage other than
covered by the legal product responsibility.
• Adapters: Only connect the adapter to the mains after checking whether the mains
voltage is the same as the values on the identification tags. Never connect an adapter or
power cord when it is damaged. In that case, contact your supplier.
• Batteries: keep batteries out of the reach of children. Dispose of batteries as chemical
waste. Never use old and new batteries or different types of batteries together. Remove
the batteries when you are not using the system for a longer period of time. Check the
polarity (+/-) of the batteries when inserting them in the product. Wrong positioning can
cause an explosion.
CONTENTS.
1. Introduction._______________________________________________________________________________________________ 3
2. Set contents._______________________________________________________________________________________________ 4
3. Installing the transmitter. _______________________________________________________________________________ 4
4. Installing the receiver.____________________________________________________________________________________ 5
5. Installing the IR receiver. ________________________________________________________________________________ 5
6. Installing the IR extender. _______________________________________________________________________________ 6
7. Installing the Invisible Scart 300™ on your PC.____________________________________________________ 6
8. Using the Invisible Scart 300™. _______________________________________________________________________ 7
9. FAQs. ________________________________________________________________________________________________________ 7
10. Technical data. ____________________________________________________________________________________________ 9
11. Optional accessories._____________________________________________________________________________________ 9
1. INTRODUCTION.
Congratulations on purchasing the Marmitek Invisible Scart 300™. You can now connect your
TV screen to any A/V device wirelessly (e.g. video recorder, DVD player, DVD recorder, satellite
receiver, Set Top Box, PC etc.). This is ideal if you cannot or do not want to place your A/V
device close to the TV. With the IR (infra-red) receiver you can continue to control your A/V
device with your own remote control, even if you have placed it in a locked cupboard, on the
other side of the room or even in a different room! Because of its compact design, the
Invisible Scart 300™ looks smart in combination with a flat screen (LCD, plasma TV), but it
can be used with any TV with a scart connection.
3INVISIBLE SCART 300™
ENGLISH
20129_20060817_UG_scart300 26-09-2006 11:02 Pagina 3
2. SET CONTENTS.
1 Transmitter.
1 Receiver (scart).
1 IR receiver.
2 Power adapters.
1 IR extender with 3 LEDs.
1 3.5 mm jack plug/RCA adapter (audio).
1 RCA/RCA cable (white/red/yellow).
1 Scart/scart RCA adapter.
1 User manual.
3. INSTALLING THE TRANSMITTER.
See images 1 and 2.
The transmitter can be connected to any A/V device.
1. Connect the RCA/RCA cable to the ‘A/V IN’ on the back of the transmitter [C+D]. Make
sure the colours of the plugs and the connectors correspond.
2. Connect the other side of the RCA/RCA cables to the A/V device from which you want
the signal to be transmitted.
If the A/V device has a scart connection, we advise you to use it.
Plug the scart/scart RCA adapter included into the scart connection of your A/V device.
If another scart cable has already been connected to the ‘OUT’ connection of your A/V
device, you should remove it. Plug the scart/scart RCA adapter into the scart connection
of your A/V device. The cable you just removed from the A/V device can be reconnected
to the back of the scart/scart RCA adapter. This ensures that the original connection is
preserved.
Connect the RCA/RCA cable to the yellow, red and white connections on the scart/scart
RCA adapter. See image 1 for more details.
3. Switch the channel selector [A] (A-B-C-D) to A.
4MARMITEK
Image 1
GIGAVIDEO TRANSMITTER
ORIGINAL SCART CABLE TO TV
TO A/V DEVICE
SCART/SCART
RCA ADAPTER
20129_20060817_UG_scart300 26-09-2006 11:02 Pagina 4
