Sida 1/12
MAX-Series
INSTRUCTION MANUAL
HANDLEIDING
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
Basic connections / Basis aansluiting / Connexions de base
Wide Range
Cable Connector / Aansluitingen / Connecteur de câble
Regulatory Requirement:
EN 55013
EN 55020
EN 61000-3-2/-3-3
Congratulations to the purchase of our SkyTec speaker box.
Read the instructions thoroughly prior to using the unit.
SAFETY INSTRUCTIONS
• Hearing damage:
SkyTec loudspeakers are easily generating high
sound pressure levels (SPL) sucient to cause
permanent hearing damage to performers,
production crew and audience members. Care
should be taken to avoid prolonged exposure to
SPL in excess of 85 dB.
• Make sure that the amplier is switched o
when the speaker box is connected or
disconnected.
• The box must be installed by a qualied
technician who has knowledge of the
techniques.
• Do not overload the box to avoid damage to the
speakers.
• Connect the box only to a good quality
amplier:
Direct voltage at the amplier output will
damage the speakers
“Clipping” (overdrive) of the amplier can
damage the woofer, tweeter and horn speaker
• Do not overload the speakers to avoid damage
to the components.
• Do not place an open re (candle, etc.) on top
or next to the box - FIRE HAZARD
• For indoor use only. If the box is used outdoors,
you need to make sure that no humidity can
enter the box.
• Make sure that the box is placed on a stable,
solid surface.
• The boxes can be stacked but do not put more
than 60kg weight on the box.
• The boxes can be hung. Use only strong and
approved mounting material. The installation
should only be carried out by a qualied
technician who has knowledge of the
techniques and regulations regarding the
mounting/hanging of speaker boxes. During the
mounting, make sure that nobody is standing
below the mounting area.
• Use only stands which are designed to support
the weight of the speaker. Do not attempt to
place more than one speaker on a stand
designed for a single speaker.
• Do not place liquids on the box and protect it
against humidity. Humidity can shorten the life
time considerably.
• Only use suitable means of transportation if you
want to move the box – BEWARE OF YOUR
BACK!!
• If the unit is damaged to an extent that internal
parts are visible, DO NOT connect the unit and
DO NOT switch it on. Contact your dealer or
Tronios.
• Never try to repair the unit yourself. It does not
contain any user serviceable parts. All repairs
must be carried out by a qualied technician.
• Set the amplier to the lowest volume prior to
switching it on.
• Keep the unit out of the reach of children.
Protect your environment. Recycle packing
material whenever possible.
Do not throw a faulty unit into normal
household waste but bring it to a special
collection point. A large part of it can be
recycled.
CONNECTIONS:
First of all, check the specications of the amplier if it is suitable for your speaker boxes. Pay particular
attention to the power rating and impedance.
Check if the amplier is switched o. If yes, you can switch on the speakers. PLEASE NOTE! Watch the polarity
(+/-). Wires of the same colour must be connected to the same sign of every side i.e. the + of the amplier must
be connected to the + of the speaker box. If the connections are inverted, the sound quality will diminish.
Only use high quality speaker cables that are suitable for the power and distance between the amplier and the
speaker.
Connection of several speakers:
When a second speaker is connected in parallel (see fig.) the impedance will change from 8 Ohms to 4 Ohms.
Check if the amplier can handle this. If more that two speakers are connected in parallel, the impedance will go
below 4 Ohms. Most of the ampliers can’t handle this!
Do not attempt to make any repairs yourself. This would invalid your warranty. Do not make any changes to the unit. This would
also invalid your warranty. The warranty is not applicable in case of accidents or damages caused by inappropriate use or
disrespect of the warnings contained in this manual. Tronios cannot be held responsible for personal injuries caused by a
disrespect of the safety recommendations and warnings. This is also applicable to all damages in whatever form.
