DRYER INSTALLATION INSTRUCTIONS
INSTRUCTIONS POUR L’INSTALLATION
DE LA SÉCHEUSE
Para una version de estas instrucciones en español, visite www.whirlpool.com
Table of Contents Table des matières
W11183136B
W11183139B-SP
INSTALLATION NOTES
Date of purchase: ________________________________________
Date of installation: _______________________________________
Installer: _________________________________________________
Model number: ___________________________________________
Serial number: ____________________________________________
NOTES CONCERNANT L’INSTALLATION
Date d’achat: ____________________________________________
Date d’installation: ________________________________________
Installateur: ______________________________________________
Numéro de modéle: _______________________________________
Numéro de série: _________________________________________
DRYER SAFETY 2 .......................................................................
INSTALLATION REQUIREMENTS 4 ...........................................
Tools and Parts ..................................................................................4
LOCATION REQUIREMENTS 5 ..................................................
ELECTRICAL REQUIREMENTS – U.S.A. ONLY 7 .....................
ELECTRIC DRYER POWER HOOKUP – CANADA ONLY 8 ......
GAS DRYER POWER HOOKUP 8 ..............................................
INSTALL LEVELING LEGS 10 .....................................................
MAKE ELECTRICAL CONNECTION – U.S.A. ONLY 11 ............
Power Supply Cord Connection ...................................................11
4-Wire Power Supply Cord Connection ......................................12
MAKE GAS CONNECTION 17 ....................................................
VENTING 18 .................................................................................
Venting Requirements ....................................................................18
Plan Vent System ............................................................................19
Install Vent System ..........................................................................20
CONNECT INLET HOSE 21 .......................................................
CONNECT VENT 22 ....................................................................
LEVEL DRYER 23 ........................................................................
COMPLETE INSTALLATION CHECKLIST............................. 23
DOOR REVERSAL (OPTIONAL) 24 ............................................
SÉCURITÉ DE LA SÉCHEUSE 30 ..............................................
EXIGENCES D’INSTALLATION 32 .............................................
Outillage et pièces ........................................................................32
EXIGENCES D’EMPLACEMENT 33 ...........................................
SÉCHEUSE ÉLECTRIQUE RACCORDEMENT
À L’ALIMENTATION ÉLECTRIQUE –
CANADA SEULEMENT 36 ..........................................................
RACCORDEMENT D’UNE SÉCHEUSE À GAZ 37 ....................
INSTALLATION DES PIEDS DE NIVELLEMENT 38 ..................
RACCORDEMENT AU GAZ 39 ...................................................
ÉVACUATION 40 .........................................................................
Exigences concernant l’évacuation 40 .................................
Planification du système d’évacuation 41 ............................
Installation du système d’évacuation 42 ..............................
RACCORDEMENT DU TUYAU D’ALIMENTATION
(MODÈLE À VAPEUR UNIQUEMENT) 43 ..................................
RACCORDEMENT DU CONDUIT D’ÉVACUATION 44 .............
RÉGLAGE DE L’APLOMB DE LA SÉCHEUSE ..................... 45
ACHEVER L’INSTALLATION LISTE DE VÉRIFICATION 45 .......
INVERSION DE LA PORTE (FACULTATIF) 46 ............................
2
DRYER SAFETY
3
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death or property
damage.
–
–
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
–Installation and service must be performed by a qualified installer, service agency, or
the gas supplier.
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Clear the room, building, or area of all occupants.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the fire department.
IMPORTANT: The gas installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1.
The dryer must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, Part 1, CSA C22.1.
In the State of Massachusetts, the following installation instructions apply:
■ Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gas fitter qualified or licensed by
the State of Massachusetts.
■ Acceptable Shut-off Devices: Gas Cocks and Ball Valves installed for use shall be listed.
■ A flexible gas connector, when used, must not exceed 4 feet (121.9 cm).
