Sida 1/16
Place terminal in a secure
position so that it won’t
accidentally contact the
negative battery post
Power cable size
It is critical to use the proper power
and ground cable. Select the size
listed here for your amplier model.
Always use high quality copper
cable. Visit our website for multi amp
system cable recommendations.
Properly route power,
speaker and RCA cables
through the vehicle.
Choose a mounting location
that will provide adequate air
ventilation. Mount the amplier to
a secure surface. Do not mount
the amplier upside down.
Attach the chassis ground, +12V and amp turn on
wire. It is important to make sure these connections
are very secure.
REM TURN ON / DC SENSE ON SWITCH
There are two methods of switching the amplier on and off. Select the appropriate
position suited for your application.
REM TURN ON This will turn on the amplier when a +12v switched power typically
from a source unit, is connected to the Amp Turn On - BLUE wire on the main power
connection harness.
DC SENSE The DC SENSE is for use with source units that do not offer RCA
outputs.
PLEASE NOTE: If switch is set to DC sense on, the amplier will not turn
on via the ampliers remote turn on wire. So if amplier will not turn on
please view this switch on the top control panel and adjust accordingly.
For more information on DC Sense and wiring visit MBQUART.com
Bare metal
Connect the RCA cables to the
INPUT connectors.
Connect the power cable to
positive battery terminal. Th
power cable must be fused
within 18 inches of the batte
terminal.
Re-connect the negative
battery terminal making sure
is securely tightened.
The chassis ground connection
is critical to the performance
of the amplier. Choose a
location that is close to the
amplier. Completely scrape
away the paint and use a nut
and bolt if possible.
DO NOT USE AN EXISTING
FACTORY BOLT!
Disconnect
Negative Battery
Terminal
Run Cables
Mount Amplier
Power
Connection
Signal Input
Connection
Positive Battery
Connection
Re-connect
Negative Batter
Terminal
Speaker
Connections
Chassis Ground
Be prepared t
to enter y
Installation
Before you start
CAUTION
Many new and factory radios require a reset code when
disconnected from battery power. This is an anti-theft
feature. Before unplugging power, you must determine if
your radio/source unit requires a reset code. Check the
operation manual for your vehicle or contact the dealer.
1
2
3
5
6
9
10
84
Turn the GAIN control completely
counter-clockwise to minimum.
Gain Control
7
10ga
Model Cable Size
NA3-560.4
NA3-1000.5
NA3-600.6
CH1 Negative - White / Black
CH2 Positive - Gray
Ground - Black
Amp Turn On- Blue
+12V - Red
GAIN
MIN MAX
Congratulations on your choice of a MBQuart amplier. This “Quick Start
Installation” guide is meant to help you “hook up” and play music. For more
detailed information, on system setting, speaker and subwoofer conguration
and full specications by model please visit our website at www.MBQuart.com
