McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 www.mcintoshlabs.com

MS500

Music Streamer

Owner’s Manual

Your decision to own this McIntosh MS500 Music

Streamer ranks you at the very top among discrimi-

nating music listeners. You now have the best. The

McIntosh dedication to precision performance assures

many years of musical enjoyment.

Please take a short time to read the information in this

guide. We want you to be as familiar as possible with

all the features and functions of your new McIntosh.

Thank You

Please Take A Moment

Technical Assistance

If at any time you have questions about your McIntosh

product, contact your McIntosh Dealer who is familiar

with your McIntosh equipment and any other brands

that may be part of your system. If you or your Dealer

wish additional help concerning a suspected problem,

you can receive technical assistance for all McIntosh

products at:

McIntosh Laboratory, Inc.

2 Chambers Street

Binghamton, New York 13903

Phone: 607-723-3512

Fax: 607-724-0549

Customer Service

If it is determined that your McIntosh product is in

need of repair, you can return it to your Dealer. You

can also return it to the McIntosh Laboratory Service

Department. For assistance on factory repair return

procedure, contact the McIntosh Service Department

at:

McIntosh Laboratory, Inc.

2 Chambers Street

Binghamton, New York 13903

Phone: 607-723-3515

Fax: 607-723-1917

The serial number, purchase date and McIntosh Dealer

name are important to you for possible insurance

claim or future service. The spaces below have been

provided for you to record that information:

Serial Number: _______________________________

Purchase Date: _______________________________

Dealer Name: ________________________________

Safety Instructions ..................................................... 2

(Separate Sheet) ................... Important Additional

Operation Information Guide

Thank You and Please Take a Moment 2 .......................

Technical Assistance and Customer Service 2 ..............

Table of Contents 2 ........................................................

Trademark and License Information 2 ..........................

General Information ................................................... 3

Connector and Cable Information .............................. 3

Introduction ................................................................. 4

Performance Features ................................................. 4

Dimensions ................................................................. 5

Installation .................................................................. 6

Rear Panel Connections .............................................. 7

AC/DC Adapter .......................................................... 8

MS500 Connections ............................................. 10-11

Front Panel Display and Push-button........................ 12

How to use the Remote Control ................................ 13

How to Operate the Setup Mode ......................... 14-15

How to Operate the MS500 ................................. 16-23

Photos ........................................................................ 25

Specifications ............................................................ 26

Packing Instructions ................................................. 27

Table of Contents

The McIntosh MS500 incorporates copyright protec-

tion technology that is protected by U.S. patents and

other intellectual property rights.

Trademark and License Information

Important Safety Information is supplied in a separate document “Important Additional Operation Information Guide”

concerning battery disposal.

8. If it should become necessary to replace the sup-

plied AC / DC Power

Adapter, order part

number 32059900

from the McIntosh

Parts Department.

9. For additional information on other McIntosh

Products please visit the McIntosh Web Site at

www.mcintoshlabs.com.

10. Mobile Device Apps for remote control operation

of the MS500, are available. Go to the McIntosh

Web Site at http://www.mcintoshlabs.com/us/Sup-

port/Pages/Manuals.aspx

Under “PRODUCT CATEGORY” select “Media

Streamers” then under “MODEL NUMBER”

select “MS500”. Click on “SEARCH” then click

on the MS500 Music Streamer App (iPhone, iPad

or Android) for your mobile device.

1. For additional connection information, refer to the

owner’s manual(s) for any component(s) connected

to the MS500 Music Streamer.

2. When the MS500 Music Streamer is connected to

an audio system, playback of music already stored

on it may be listened to. To take full advantage of

the many features the MS500 is capable of, such

as importing and storing additional music on the

Music Streamer, requires connection to a Com-

puter Network System.

3. For best performance, the speed of the Computer

Network the MS500 Music Streamer would be

connected to should be 1 Gigabit or faster.

4. The MS500 internal Digital to Analog Converter

Circuitry is designed to decode 2-channel PCM

(Pulse Code Modulation) Digital Signals up to

24Bit 192kHz. The Digital Output Signal present

at the Coaxial and Optical Output Connectors is a

2-channel PCM (Pulse Code Modulation).

5. The MS500 is designed to be compatible with the

majority of Audio Power Amplifiers. However,

do to a wide range of Power Amplifier Designs, it

is important the input sensitivity of the amplifier

be at least 2 Volts. This will assure the playback

of most music recordings are reproduced with ad-

equate dynamic range. Check with your McIntosh

Dealer for additional information.

6. The IR Input, with a 3.5mm mini phone jack, is

configured for non-McIntosh IR sensors such as

a Xantech Model DL85K Kit. Use a Connection

Block, such as a Xantech Model ZC21, when two

or more IR sensors need to be connected to the

MS500.

7. When discarding the unit, comply with local rules

or regulations. Batteries should never be

thrown away or incinerated but disposed

of in accordance with the local regulations

phone plug and allow the connection

of other brand IR Receivers to the

MS500.

Power Control Connector

The Power Control Input Jack receives Power On/

Off Signals (+12 volt/0 volt) when connected to other

McIntosh Components. The Power Control Output

Jack sends Power On/Off Signals (+12 volt/0 volt)

when connected to other McIn-

tosh Components. An additional

connection is for controlling the

illumination of the Power Out-

put Meters on McIntosh Power

Amplifiers. A 3.5mm stereo mini phone plug is used

for connection to the Power Control Jacks.

Ethernet RJ45 Socket

1. Transmit Data (+) 5. N/C

2. Transmit Data (-) 6. Receive Data (-)

3. Receive Data (+) 7. N/C

4. N/C 8. N/C

Ethernet Cable - Straight Thru Connections

Pin Number - Wire Color Pin Number - Wire Color

 1.Orange/White → 1.Orange/White

 2.Orange → 2.Orange

 3.Green/White → 3.Green/White

 4.Blue → 4.Blue

 5.Blue/White → 5.Blue/White

 6.Green → 6.Green

 7.Brown/White → 7.Brown/White

 8.Brown → 8.Brown

General Information

Connector and Cable Information

XLR Connectors

Below is the Pin configuration for the XLR Balanced

Output Connectors on the MS500. Refer to the dia-

gram for connection:

PIN 1: Shield/Ground

PIN 2: + Output

PIN 3: - Output

Data and IR Input Port Connectors

The MS500 Data In Port receives Remote Control

Signals. A 3.5mm stereo mini phone

plug is used for connection. The IR

Ports also use a 3.5mm stereo mini

PIN 1 PIN 2

PIN 3

Data

Signal

N/C

Data

Ground

IR Data

Control

Ground

N/C

Power

Control

Ground

Meter

Illumination

Control

Pass Thru

Pin 1

Pin 8

Pin 1

Pin 8
