Sida 1/3
www.av .comsl 5UK User Manual 350.00
2.4Ghz Wireless Digital Intercom
Order ref: 350. 5 00 UK
User Manual
A stylish and attractive wireless digital intercom that allows you to talk to your visitors before opening the
door. No wires are required between the outdoor and indoor units making this system very simple to
install. Both units are powered by a rechargeable battery with the indoor unit doubling as a battery
charger when connected to a suitable USB power source using the charging lead provided. Its also
possible to connect the outdoor unit to an electronic door lock, utilising the door release button on the
indoor unit. Ideal for use in domestic and business applications and helpful for the elderly or less mobile.
Features:
• Simple wire free installation and setup
• Up to 500m transmission range
• 8 Ringtones and adjustable ring volume
• Recharge the batteries using the indoor unit and USB charging lead (supplied)
• Weatherproof outdoor unit can be connected to an electronic lock (not supplied) when connected to
mains power
• Outdoor unit can also be mains powered using additional 12V PSU 350.006UK (not supplied)
• LED indicators for low battery warning and battery charging status
In the box:
• Outdoor unit (IP44)
• Indoor t uni
• Rain shade for outdoor unit
• 2pcs DC3.7V Rechargeable battery
• USB charging lead (1m)
• Electronic lock connecting wire
• Fixing kit
• User guide
Installation:
Outdoor unit
1. Fasten the rain shade on the wall around 1.4~1.7m
above the ground using the screws and plugs provided
in the fixing kit.
2. Open the battery cover using a small Philips screwdriver
and insert one of the DC3.7V rech geable batteries ar
ensuring the correct polarity.
3. Replace the cover and screw then s the unit to the lot in
rain shade.
4. Secure the unit from underneath using the fixing screw
provided in the fixing kit.
5. Its also possible to power the outdoor unit using an
additional DC12V mains power supply (350.006UK not
www.av .comsl 5UK User Manual 350.00
supplied). If mains installation is required, please use a qualified electrician and ensure the
rechargeable battery is removed before installation.
Indoor unit
1. The indoor unit can simply be d on a suitable flat stoo
surface or hung on a wall using the fixing screws provided
and keyhole slots in the back of the unit.
2. Please ensure the unit is kept in a dry environment away
from direct sunlight and any wireless items that may
interfere with the signal such as cordless phones, door in
aerials or WiFi hubs and routers.
3. Open the battery cover using a small Philips screwdriver
and insert one of the DC3.7V rech geable batteries ar
ensuring the correct polarity.
4. Replace the cover and screw to secure the unit.
5. There is also a USB charging port on the top of the indoor
unit which can be used to charge up the batteries used in
both units.
6. Simply insert the USB charging cable provided into the charging port and connect the c le to a ab
suitable USB power source.
7. During charging the unlock button will flash, then go out once the
battery is fully charged.
Electronic door lock
1. Its possible to connect the outdoor unit to an additional elec ic tron
door lock (not supplied) using the connecting wire provide d.
2. This is only possible if the outdoor unit is connected to mains power
using the additional 12V power supply mentioned above.
3. It recommended to use RVV2 x 1.0mm² cable to connect to the is
electronic door lock.
4. Once the door lock is connected correctly the unlock button will also
be activated the indoor unit. on
NOTE: it is recommended that all wiring connections for both the
electronic door lock and 12V DC power supply are undertaken by a
qualified electrician.
Operation:
1. When the call button is pressed on the outdoor unit,
the indoor unit chi will sound and the LED on the me
talk button will flash.
2. Press the talk button to speak to your visitor and
press again to end the conversation.
3. If an electronic door lock is connected you can also
press the unlock button to admit your visitor entry
to your property.
4. It i possible to select a different chime on the s
indoor unit. Simply scroll through the 8 available
melodies by pressing the chime selection button
repeatedly.
www.av .comsl 5UK User Manual 350.00
5. To adjust the chime volume press the volume adjustment b repeatedly select either high, utton to
medium or low volume setting accordingly.
System alerts:
1. The LED on the tdoor uni call button flashing slowly indicates the battery level is low and it should ou t
be rechar d as soon as possible. ge
2. The LED on the indoor unit unlock button ashing slowly indicates the battery level is low and it fl
should be recharged as soon as possible.
Specification:
Frequency
426~440 MHz
Range
Up to 500m (open area)
IP Rating
IP44 (External unit only)
Power supply: indoor unit
18650 Lithium rechargeable battery
(DC3.7V)
Power supply: outdoor unit
18650 Lithium rechargeable battery
(DC3.7V) or DC12V 1~2A Mains
adaptor (not supplied)
Dimensions: door unit in
154 x 54 x 36mm
Dimensions: outdoor unit
158 x 62 x 50.5mm
Weight: indoor unit
165g (including battery)
Weight: outdoor unit
220g (including rain shade battery) &
Warning:
• For reasons of electrical safety, this device must never be immersed in water, exposed to damp
conditions or excessive force.
• Do not use this device if you find that it is damaged in any way.
• Do not attempt to repair this device or take apart under any circumstances, as this will invalidate your
warranty.
IP44
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end
of its useful life. The goods must be disposed of according to your local council guidelines.
Hereby, AVSL Group Ltd. declares that the radio equipment type 350.005: UK compli with Directive 2014/53 U es /E
The full text of the EU declaration of conformity for 350.005UK is available at the following internet address:
http://www.avsl.com/assets/e tdoc/3/5/350005UK%20CE.pdfxpor
Errors and omissions excepted.
Copyright© 21 AVSL Group Ltd Unit 2 Bridgewater Park, AVSL (Europe) Ltd, Unit 3D North Point House, 20 ,
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
