Miiego AXTIVE M1 Bruksanvisning

Miiego Hörlurar AXTIVE M1

Läs nedan 📖 manual på svenska för Miiego AXTIVE M1 (20 sidor) i kategorin Hörlurar. Denna guide var användbar för 5 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/20
Quick Start Guide
ENG
DK
NOR
SE
DE
1 - 2
3 - 4
5 - 6
7 - 8
9 - 10
FR -
1
211
- 1817PSE
- 1413 LN
EST - 6115
AXTIVE M1
WIRELESS SPEAKER
ENG
1
2
3
5
4
SPECIFICATIONS
CARE, MAINTENANCE, SAFETY
1
This device contains a lithium accumulator.
Improper use can cause erheating and fire. ov
Reflective hanger
- Volume Down / Previous
Song Press once / Hold
Play button: Play, pause,
answer call, TWS.
+ Volume Up / Next Song
Press once / Hold
Power button: Power on/off,
Reset.
Mode button: Switch
between Bluetooth and AUX
LED indicator for charging
Charging port
AUX IN port
LED Bluetooth indicator
Microphone
Any modification of the product may have consequences for safety, warranty
and proper functioning. Keep out of reach for children and animals. Product
storage and working temperature: from -10 celsius degrees to +40. Do not
expose the product to direct sunlight, heat or naked flames as it may cause
damage or explosion. Do not use the product if a part is damaged or defective.
Replace a damaged or defective device immediately. Disconnect the product
from the electrical outlet and other equipment if problems occur. Do not
charge when the product is wet. Do not leave a battery on prolonged charge
when not in use. Do not dismantle, open or shred batteries. Do not drop the
product and avoid bumping. This product may only be serviced by a qualified
technician for maintenance to reduce the risk of electric shock etc.
6
7
8
9
11
10
Bluetooth v5.0 - Wireless transmission range up to 10-15 m. without obstacles.
Rechargeable 800 mAh Li-ion battery. Full charging time: around 2.5 hours.
IPX7. BT frequency range: 2402-2480MHz. Freq. Response: 90Hz-20 KHz.
Charging input power: 5V DC/1A. RMS audio output: 5W. Impedance: 4 .Ω
1
2 3 4
5
6
789
10
11
ENG
2
Pairing your AXTIVE M1 Bluetooth speaker
Charging the AXTIVE M1 speaker
Next time charging
Turning Your AXTIVE M1 On and Off
Activate Siri on iOS-device: Double press the PLAY button (works only in
Bluetooth mode).
Play music from AUX mode
Pairing and connecting 2 x AXTIVE M1 speakers with TWS
1: Make sure the speaker is charged and turned OFF.
2: Press and hold the button for 3 seconds until the indicator light flashes
WHITE (pairing mode).
3: Activate Bluetooth on your phone or other device and search for new
Bluetooth device and select: MIIEGO AXTIVE M1.
When AXTIVE M1 is connected the WHITE LED light is constantly on.
The speaker will remember your phone/device and automatically reconnect
the next time you turn it on.
An unpaired speaker will automatically turn off after 6 minutes.
Use a 5V/1A USB adapter for charging.
During charging the red right is on. When fully charged the red light is off.
Full charging time is around 2.5 hours with 1A.
When you hear a warning tone every 180 seconds, the battery status is
low and needs charging.
ON: Press the Button for 3 seconds until a tone is heard.
OFF: Press the Button until a tone is heard.
Insert AUX audio cable on the bottom of the speaker.
(in AUX mode switching songs on +/- buttons is unavailable)
TWS only works when connecting two AXTIVE M1s by MIIEGO® together.
There needs to be free distance between them.
1: Turn on both speakers (Bluetooth mode). Make sure they are unconnected.
2: Press and hold the PLAY button on one speaker for 2 seconds. The product
emits a tone to indicate entering TWS-pairing mode.
3: The product then emits three tones and the LED indicator light (10) will be
constantly on. This is then the slave speaker. LED indicator light on master
speaker will flash to indicate successful TWS-pairing.
4: Activate Bluetooth on your phone/device and connect with the master
speaker.

Produktspecifikationer

Varumärke: Miiego
Kategori: Hörlurar
Modell: AXTIVE M1
