GPEN11

This device allows powering a PoE capable device over the Ethernet,

using the same voltage, as provided with the DC input jack.

Powering

The device accepts power from direct-input power jack (5.5 mm

outside and 2 mm inside, female, pin positive plug) 12-57 V DC⎓.

Power output

The device supports PoE out from Ethernet port located under the

cover. You can power Mikrotik devices which supports passive powering

through Ethernet.

Mounting

Step 1:

1. Remove the cover screw using PH2 screwdriver;

2. Remove cover to access mounting points.

Step 2:

1. Drill holes using drill bid;

2. Insert dovels if needed;

3. Attach the unit to the wall, using wall and secure with screws.

Step 1. Step 2.

See mikrotik.com/products for the latest version of this document. Page 1, Document #46507 Modified on: 29.OCT.2019

Step 3:

1. Plug in the Ethernet cable going to the unit that will be powered;

2. Plug in power source for the GPEN.

* Outgoing Ethernet cable can be guided through position A, or B for cable leading into the wall.

Step 4:

1. Re-attach cover;

2. Secure cover using the screw;

3. Use the sticker to cover the screw location.

Step 3. Step 4.

When mounting on the wall, please ensure that cable feed is pointing downwards.

The IPX rating scale of this device is IPX0. We recommend using Cat6 shielded cables.

Accessories

Package includes the following accessories that come with the device:

•K-62 screw kit

Specifications

For more information about this product, specifications, pictures, downloads please visit our web page:

https://mikrotik.com/product/gpen11

See mikrotik.com/products for the latest version of this document. Page 2, Document #46507 Modified on: 29.OCT.2019

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Note: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the

unit to ensure compliance.

Industry Canada

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,

including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.

L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)

l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en

compromettre le fonctionnement.

See mikrotik.com/products for the latest version of this document. Page 3, Document #46507 Modified on: 29.OCT.2019

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Växla
Modell:	GPEN11
