Sida 1/20
Tηλέφωνο ντους νιπτηρα
Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας
BasIn sHOWer Head aTTaCHMenT
Assembly, operating and safety instructions
BaTerIe Cu duş penTru CHIuveTă
Indicaţii de montaj-, utilizare- şi siguranţă
IAN 273011
BasIn sHOWer Head aTTaCHMenT
Душ
Инструкции за монтаж, обслужване и безопасност
Tuš za uMIvaOnIK
Upute za montažu, uporabu i sigurnost
GB / CY Assembly, operating and safety instructions Page 3
HR Upute za montažu, uporabu i sigurnost Stranica 6
RO Indicaţii de montaj-, utilizare- şi siguranţă Pagina 9
BG Инструкции за монтаж, обслужване и безопасност Страница 12
GR / CY Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας Σελίδα 15
3 GB/CY
Basin Shower Head Attachment
Proper use
This product is suitable for all pressure-tight hot water
systems such as central heating boilers, instantaneous
water heaters, pressurised boilers and the like. It is
not suitable for low-pressure water heaters such as
wood or coal burning bath geysers, oil or gas bath
geysers, open electrically heated water tanks. If in
doubt please seek the advice of a plumber or heating
engineer. The product is intended for personal use
only and not for medical or commercial use.
Description of parts
1 Basin Shower Head Attachment
2 Screw
3 Wall mounting
4 Dowel
5 Push button
6 Shower hose
7 Seal (ø 19 mm)
8 Fitting connection
9 Adapter piece
10 Seal (ø 21 mm)
11 Aerator
12 Spanner
Technical data
Wash basin hand shower: approx. 180 x 33 mm
(length x ø)
Shower hose: approx. 125 cm,
21 mm (½”) standard
connection
Fitting connection: M22 internal thread
(with adapter piece)
M24 external thread
(without adapter
piece)
Safety advice
RISK OF LOSS
OF LIFE OR ACCIDENT TO IN-
FANTS AND CHILDREN! Never
leave children unsupervised with the packaging
materials. Danger of suffocation. Keep the product
away from children. The product is not a toy.
CAUTION! RISK OF INJURY! Please ensure
that no parts are damaged and that all parts are
correctly assembled. Incorrect assembly could
lead to injury.
Please note that seals are wear parts and there-
fore will require to be replaced from time to time.
Damaged parts could adversely affect safety
and proper function.
CAUTION! RISK OF DAMAGE TO
PROPERTY! Have the installation done by
experienced persons only. Leaks or escape of
water can lead to serious damage to buildings
or household fittings and furniture. Check all
connections for leaks carefully.
Ensure that all seals are correctly seated to
prevent leakage of water.
CAUTION! DANGER OF SCALDING!
When making the hot water setting please ensure
that the temperature of the water is not too high.
Please read carefully through these operating
instructions before installing and using the product.
Keep all the safety advice and instructions in a
safe place for future reference!
Do not use the wall mounting for holding onto
or for support. The fastening materials and the
wall mounting itself are not designed for the
loads which would arise.
The assembly is only to be carried out by com-
petent persons.
Do not connect the shower hose 6 directly to
a shut-off valve, always connect the shower
hose with the provided fitting connection 8.
Operation
Note: with fittings with a M22 external thread
please insert the supplied fitting connection with
