DESCRIPTION
• Metal construction with various finishes identified by suffix
• Designed to be installed through 2, 1-1/4" and 1, 1" min. dia holes
8" on center
• Adaptable for non-8" centers
• Hot and cold indicators available
OPERATION
• Maximum handle rotation angle is 90˚ to full on for either handle
• Rotate hot side counterclockwise to open and clockwise to close
• Rotate cold side clockwise to open and counterclockwise to close
FLOW
• Water usage is limited to these maximum flow rates as indicated by
the corresponding product markings
° 1.2 gpm max (4.5L/min) at 60 psi
° 1.5 gpm max (4.7L/min) at 60 psi
CARTRIDGE
• 1224 cartridge design
• Nonmetallic/nonferrous and stainless steel material
STANDARDS
• Third party certified to WaterSense,® ASME A112.18.1/CSA B125.1, and
all applicable requirements referenced therein
• Certified to NSF 61/9 & 372
• Products marked with 1.2 gpm are compliant with California water
efficiency regulations
• Complies with California Proposition 65 and with the Federal Safe
Drinking Water Act
• for lever handles ADA
WARRANTY
• Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
• 5 year warranty if used in commercial installations
ARRIS™
Two-Handle Wall Mount Faucet
Models: TS43003 series
Valve: 9700
2-11/16"
(68mm)
2-1/4 " Spout Base
(57mm)
2" Handle Base
(51mm)
3-3/32"
(79mm)
8"
(203mm)
3" (76mm) MIN.
MAX WALL THICKNESS
1-3/4” (45mm)
CRITICAL DIMENSIONS
(DO NOT SCALE)
S p e c i f i c a t i o n s
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
Rev. 3/16
M•pact™ System
