Mini PTZ ameraC
ELAX-2812BPTZ
Packing details
Camera 1 PCS
1 PCS
Details NO
Manual
2.1 Cable interface
4IN1 Bullet PTZ Camera support with UTC (Video coaxial
control) ,support with 4 video mode output
(AHD ,TVI ,CVI ,CVBS ) , setting via DIP Switch
You can refer to the following figure for multiple function
combination cable informationSee Figure 2-1. there might
be some differences among different serial products
2-2 Cable function explain
2-1 Cable Draft
Power connector
input DC 12V Power
1
2
3
Power
Video
DIP Switch
Video connector
Setting mode with video
NO Connector Function
1
2
3
ON
AHD
ON
TVI
ON
CVI
ON
CVBS
Equipment connect
Quick installation guide
V1.0.0
PREFACE
Important Safety Notices
Summary：
Document describes unpacking inspection device structures
installation and quick configuration tool in details
Signal instruction：
These symbols may appear with meanings as following
The following contents are specification for using the
devices correctly please read these notices and warnings
carefully and obey while using it
Attention：
1.1 Power
1.2 Environment
All installation and operation here should conform to your
local electrical safety codes
Only use a regulated 12 V power supply unit with a
minimum rating of 2 A.
Please protect cable being trampled power or squeezed
especially in the socket, and exit Junction
Avoid focusing on highlight (such as the sun or lights),
otherwise it may cause over explosion phenomenon (this is
not device's problem) or may damage camera's
CMOS.
Please transport and store t under allowable , use he camera
temperat humidityrange. Do not put the device under e and
wet, dusty extremely hot or cold, strong electromag
netic radiation or unstable lighting conditions etc.
Prevent water or other liquid falling into the camera.
P .lease keep the ventilation around the device
No heavy ion or er splash stress, violent vibrat wat are
allowed during the transportationand storage.
When transporting camera, it use company the should
packing or use same quality ma terial packing.
Thunder-proof device to is recommended be adopted
for preventing thunder better.
Special explanation
1.3 Operation and maintenance
Do not dismantle the camera no components inside since
which can be repaired by users.
Do not touch optic the CMOS component directly you can
use the blower to clean the dust on the lens surface If
necessary, clean the dust with please gently dry clothwhich
is slightly wet with alcohol.
Please use For heavy dirt, soft cloth to clean the device.
please put little detergent on thecloth to clean and dry. Do
not use volatile solvent, Alcohol, Benzene or Diluent-such as
sor irritant and abrasiveness cleanser to clean the device.
Otherwise, it will damage the device or weaken camera
working performance.
The material of front cover is optic component please do not
t ouch or clean the surface directly.For cleaning, please
use professional optical cleaning method Inadaptable
cleaning method (e. g. cleaning directly with cloth ) may
result harmful effect on theinfrared function of the in a
camera.
Warning:
Be sure to use all the accessories recommended by
manufacturer and theinstallation and repairs should be
conducted by professionals.
Please make sure the CMOS component is out of
the radiation of laser beam devices. Otherwise it may result
in damage on the component.
Because our company continuously adopts new technolo-
gies product parameterschange without prior notice. Some
function of products may have slight differenceafter the
updates.
For receiving the latest procedures and additiona linstruction
document please contact the company s customer service
department.
If there are any problems while using the camera, please feel
free to contact the supplier or the company's customer
service department.
Because of the real environment and other unstable factors,
some data may be differ-ent with instruction guide. If there
are any questions and disputes please regard the
Company's final explanation as the criterion.
Please follow instruction guide, we are not liable for any
problems caused byman-made damage
This manual is for reference only. slight difference may be
found in users interface
1.1 Checking Steps
When user received the bullet PTZ Camera, please check
whether it has obviously damage on the appearance of
equipment Packing material can stand accidental Crash on
transport. Please open the package and check all the
components are included. Please reference the following
form.
1.2 Accessories
Be sure to use all the accessories recommended by manufac-
turer
Checking Box
Bracket change
The wall wight for install the camera ,must be can stand 3
times as much as the camera .
Pls Choose cleanly ,smooth wall .Drilled hole according with
the bracket hole . Putting with the bulged tubeThen Fixed
the camera under the ceiling .
Pls Choose cleanly ,smooth wall .Drilled hole according with
the bracket hole . Putting with the bulged tube
The fault of the bracket is walled mounted ,For ceilling
mounted ,if need,change it by urself . As picture ,take out 2
bolts ,motion the bracket with180
2.2
Structure size
(Unit: mm)
2-4 Dimension
2-5 Dimension
2-3 Dimension
3-1 Draft dimension
3-2 Dimension
4-1 Equipment change draft
Wall mounted
Ceiling
1
2
3
Menu
IR sensitivity
setting
IR Mode setting
call 95
set 71 call N
set 70 call N N : 1.Auto 2,Open ,3 close
Range of settings 1-10
10 = highest sensitivity level
4
5Factory default
Reset /restart
call 82 or call 62
call 94 or call 74
NO Function command explain
Equipment Install
2
3
180°
1
Take out bolts put on bolt
PTZ control is made via the PTZ menu of the recorder
connected (control protocol "Coax").
To show the camera menu, call up the preset 95.
Camera setting
1、LENS MANUAL
2、EXPOSURE ←
3、BACK LIGHT OFF
4、WHITE BAL ATW
5、DAY&NIGHT COLOR
6、 ←NR
7、SPECIAL ←
8、ADJUST ←
9、 SAVE&END ←EXIT
Setting
1、LENS MANUAL
2、EXPOSURE ←
3、BACK LIGHT OFF
4、WHITE BAL ATW
5、DAY&NIGHT COLOR
6、 ←NR
7、SPECIAL ←
8、ADJUST ←
9、 SAVE&END ←EXIT
1、 ←SHARPNESS AUTO
2、 ←MONITOR LCD
3、LSC ON
4、VIDEO/OUT NTSC
5、 ←RETURN RET
ADJUST
Appendix
Set
ting
5 Main menu-1
5 2 Submenu ADJUST-
When all settings have been made, use EXIT
to exit the menu.
