Installation
Instructions
Island Vent Hood
ZV850, ZV855
Hotte Aspirante Îlot
Instructions d’installation
La section française commence à la page 22
Campana de ventilación en isla
Instrucciones de instalación
La sección en español empieza en la página 43
31-10725-1
GE 11/02/09
2
Safety Information
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT — Save these instructions for
local inspector’s use.
• IMPORTANT — Observe all governing codes
and ordinances.
• — Note to Installer Be sure to leave these
instructions with the Consumer.
• — Note to Consumer Keep these instructions
with your Owner’s Manual for future reference.
• — Skill Level Installation of this appliance requires
basic mechanical and electrical skills.
• — 1 to 3 Hours.Completion Time
•Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the warranty.
For Monogram local service in your area, call 1.800.444.1845.
For Monogram service in Canada, call 1.800.561.3344.
For Monogram Parts and Accessories, call 1.800.626.2002.
CAUTION:
Due to the weight and size of these vent hoods and
to reduce the risk of personal injury or damage to the
product, TWO PEOPLE ARE REQUIRED FOR PROPER
INSTALLATION.
WARNING:
To reduce the risk of fire or electrical shock, do not
use this range hood with any external solid-state speed
control device. Any such alteration from original factory
wiring could result in damage to the unit and/or create
an electrical safety hazard.
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
WARNING: TO REDUCE THE RISK OF
FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Use this unit only in the manner intended
by the manufacturer. If you have any questions,
contact the manufacturer.
B. Before servicing or cleaning the unit, switch
the power off at the service panel and lock the
service disconnecting means to prevent the power
from being switched on accidentally. When the
service disconnecting means cannot be locked,
securely fasten a prominent warning device,
such as a tag, to the service panel.
CAUTION: FOR GENERAL VENTILATING
USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS
MATERIALS, EXPLOSIVE MATERIALS OR VAPORS.
WARNING: TO REDUCE THE RISK OF
FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
•Installation work and electrical wiring must be done
by qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
•Sufficient air is needed for proper combustion
and exhausting of gases through the flue (chimney)
of fuel burning equipment to prevent back-drafting.
Follow the heating equipment manufacturer’s
guidelines and safety standards, such as those
published by the National Fire Protection Association
(NFPA), the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE) and the local
code authorities.
•When cutting or drilling into walls or ceilings, do not
damage electrical wiring and other hidden utilities.
•Ducted systems must always be vented
to the outdoors.
•Local codes vary. Installation of electrical connections
and grounding must comply with applicable codes.
In the absence of local codes, the vent should be
installed in accordance with National Electrical Code
ANSI/NFPA 70-1990 or latest edition.
CAUTION: To reduce risk of fire and to
properly exhaust air, be sure to duct air outside—do not
vent exhaust air into spaces within walls or ceilings or
into attics, crawl spaces or garages.
READ AND SAVE THESE INSTRUCTIONS
Design Information
MODELS AVAILABLE
Model ZV850, 360 CFM
Model ZV855, 500 CFM
These hoods may be installed to vent to the outdoors,
or they may be installed for recirculating operation.
All necessary parts for recirculating operation are
supplied with the hood. No kits required.
• These vent hoods can be installed over any 30
”
or 36
”
Monogram electric or gas cooktop except Monogram
Professional cooktops or ranges larger than 30”.
•Reversible duct covers accommodate recirculating
operation.
•The telescopic duct covers conceal the ductwork
running from the top of the hood to the ceiling.
•The supplied duct cover is sized to reach ceiling heights
over 8 feet. See the table on page 8.
PRODUCT DIMENSIONS AND CLEARANCES
The vent hood must be installed 24 minimum and ″
30″maximum above the cooking surface.
NOTE: Installation height should be measured from
the cooking surface to the lowest part of the hood.
ZX8510SPSS Duct Cover Accessory
This accessory is available for installation with ceiling
heights
of
8
′
7
″to over 10 feet.
See the table on page 8.
The duct cover accessory must be on-site with the
hood at the time of installation.
24” Minimum
30” Maximum
36" Minimum
*Height
to Ceiling
8-1/4"
27-1/2”
35-3/8 (excluding utensil rods)ļ
36-1/2 (including utensil rods)ļ
CONTENTS
Design Information
Models Available ................................................................................3
Product Dimensions..........................................................................3
Advance Planning
Ductwork Planning ..........................................................................4
Ceiling Framing for Adequate Support ..................................4
Installation Preparation
Duct Fittings..........................................................................................5
Power Supply ......................................................................................6
Tools and Materials Required ......................................................6
Remove the Packaging ..................................................................7
Check Installation Hardware ......................................................7
Determine Installation Height......................................................8
Install Ceiling Support Structure ........................................9–11
Installation Instructions
Installation – Vented to the Outside ..............................12–16
Step 1, Mount Template ..............................................................12
Step 2, Install Upper Support Frame......................................12
Step 3, Install Lower Support Frame......................................12
Step 4, Secure Wiring ....................................................................13
Step 5, Size and Install Ductwork ............................................13
Step 6, Install Decorative Duct Covers..................................14
Step 7, Install Hood ........................................................................15
Step 8, Connect Electrical............................................................15
Step 9, Slide Duct Cover
Down, Install Side Utensil Rods ................................................15
Step 10, Install Filters ....................................................................16
Step 11, Finalize Installation ......................................................16
Installation Instructions
Installation – Recirculating..................................................17–21
Step 1, Mount Template ..............................................................17
Step 2, Install Upper Support Frame......................................17
Step 3, Install Lower Support Frame......................................18
Step 4, Secure Wiring ....................................................................18
Step 5, Size and Install Ductwork ............................................18
Step 6, Install Decorative Duct Covers..................................19
Step 7, Install Hood ........................................................................20
Step 8, Connect Electrical............................................................20
Step 9, Slide Duct Cover
Down, Install Side Utensil Rods ................................................20
Step 10, Install Filters ....................................................................21
Step 11, Finalize Installation ......................................................21
3
