INSTALLATION
INSTRUCTIONS
48”Custom Brass Hood
ZVC48DTB1
48” Custom Stainless Steel Hood
ZVC48STSS
MONOGRAM.COM
231-2001216 Rev. 0
Safety Information
READ AND SAVE THESE INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Ŷ IMPORTANT — Save these instructions
for local inspector’s use.
Ŷ IMPORTANT — Observe all governing
codes and ordinances.
ŶNote to Installer — Be sure to leave these
instructions with the Consumer.
ŶNote to Consumer — Keep these instructions with
your Owner’s Manual for future reference.
ŶSkill Level — Installation of this appliance requires
basic mechanical and electrical skills.
Ŷ3URSHULQVWDOODWLRQLVWKHUHVSRQVLELOLW\RIWKH
LQVWDOOHU3URGXFWIDLOXUHGXHWRLPSURSHULQVWDOODWLRQ
is not covered under the warranty. See Owner’s
Manual for warranty information.
WARNING Improper grounding can result in a
risk of electric shock. Consult a qualified electrician
if the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
For Monogram local service in your area,
800.444.1845.
For Monogram Service in Canada, call 800.561.3344.
)RU0RQRJUDP3DUWVDQG$FFHVVRULHVFDOO
800.626.2002.
If you received a damaged vent hood, you should
contact your dealer.
CAUTION Due to the weight and size of these
vent hoods and to reduce the risk of personal injury
or damage to the product, TWO PEOPLE ARE
REQUIRED FOR PROPER INSTALLATION.
WARNING TO REDUCE THE RISK OF FIRE,
(/(&75,&$/6+2&.25,1-85<723(56216
2%6(59(7+()2//2:,1*
Ŷ,QVWDOODWLRQZRUNDQGHOHFWULFDOZLULQJPXVWEHGRQHE\
qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
Ŷ:KHQFXWWLQJRUGULOOLQJLQWRZDOOVRUFHLOLQJVGRQRW
damage electrical wiring and other hidden utilities.
Ŷ'XFWHGV\VWHPVPXVWDOZD\VEHYHQWHGWRWKHRXWGRRUV
CAUTION To reduce risk of fire and to properly
exhaust air, be sure to duct air outside — do not vent
exhaust air into spaces within walls or ceilings or into
attics, crawl spaces or garages.
WARNING TO REDUCE THE RISK OF FIRE,
86(21/<0(7$/'8&7:25.
31-2001216 Rev. 0 3
Installation Instructions
CONTENTS
Safety Information ......................................................... 2
3URGXFW'LPHQVLRQV ...................................................... 3
$GGLWLRQDO3DUWV3URYLGHG .............................................. 3
Tools and Materials Required ....................................... 3
Installation Clearances .................................................. 4
$GYDQFH3ODQQLQJ ......................................................... 4
Unboxing ....................................................................... 4
Step 1, Determine Ductwork and Wiring Locations ...... 5
Step 2, Install Hood onto Wall ....................................... 6
Step 3, Install Hood Insert into Hood ............................ 7
PRODUCT DIMENSIONS
ADDITIONAL PARTS PROVIDED
These parts are packed with the hood.
TOOLS AND MATERIALS REQUIRED
1RWVXSSOLHG
30”
17-5/8”
24”
SIDE VIEW FRONT VIEW
38”
48”
Phillips screwdriver
Flashlight
Safety glasses
Electric or battery operated drill.
1/8” drill bit. 3/16” drill bit.
Phillips driver.
Pencil
Level
Step ladder
Tape measure
Safety Gloves
Wood Support with
short Phillips head screws
2 long Square Drive flat head
screws to secure the wood
support to the wall
Square drive bit
2 short pan head Phillips screws to
secure the hood to the wood support.
There are 2 additional screws already
installed in the wood support.
4 medium pan head Phillips screws to
secure the hood to the wall.
*UHHQ
*URXQG6FUHZV 3DLUVRI1LWULOH
*ORYHVWRSUHYHQW
fingerprinting)
*URXQG:LUH
