Sida 1/8
INSTALLATION MANUAL
CAU T IO N: DO NOT EXCEED RATED
LISTED WEIGHT CAPAC ITY. SERIOUS
INJURY OR PROPERTY DAMAGE MAY
OCCUR!
Full Motion LED,LCD TV Wall Mount
6
6
6
60
0
0
0k
k
k
kg
g
g
g
(
(
(
(1
1
1
13
3
3
32
2
2
2l
l
l
lb
b
b
bs
s
s
s)
)
)
)
R
R
R
RAT
AT
AT
ATE
E
E
ED
D
D
D
60kg
(132lbs)
RATED
PID:62 00
200x200
400x200/400x400
600x400/800x400
/300x300 70"
MAX
4. Adjustment
Adjust to the desired location or tilt.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your dealer if you have any questions.
12 0°
+0°
-10°
+5° -5°
21
Component Checklist
IMPORTANT: Ensure that you ha ve rec eive d all pa rts according to t he compon ent ch ecklist prior to installat ion.
If any parts are missing or faulty, telephone y our local di stributor for a replacemen t.
Package M
Package W
W-B (x6) W-C (x6)W-A (x6)
wall mount (x1)
A
left a
bracket (x1)
B
dapter right a
bracket (x1)
C
dapter
Allen key
D
(x2)
NOTE: Read the entire instruction manual before you start installation and assembly.
WARNING
• Do not begin the installation until you have read and understood the instructions
and warnings contained in this installation sheet. If you have any question
regarding any of the instructions or warnings, please contact your local distributor.
• This mounting bracket was designed to be installed and utilised ONLY as
specified in this manual. Improper installation of this product may cause damage
or serious injury.
• This product should only be installed by someone with good mechanical ability
who has basic building experience and fully understands this manual.
• Make sure that the supporting surface will safely support the combined weight of
the equipment and all attached hardware and components.
• If mounting to wood wall studs, make sure that mounting screws are anchored
into the center of the studs. The use of a stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position
the equipment.
• Tighten screws firmly, but do not over tighten. Over tightening can cause damage
to the items, This greatly reduces their holding power.
• This product is intended for indoor use only. Using this product outdoors could
lead to product failure and personal injury.
M-F (x4) M-H (x8) M-G (x8)
M8x30
M-D
(x4)M6x30
M-C
(x4)M6x14
M-B
(x4)M5x14
M-A
(x4)
M8x50
M-E
(x4)
