User Manual
7495/7496
2-Way Active Wall Mount Speakers
(Pair) - 25W
Introduction
Thank you for purchasing these Monoprice Active Speakers!
For best results, please read this manual completely before
attempting to install or use these speakers. Pay extra attention to
the Safety Tips and Warnings below to ensure both your own
personal safety and the long-term service from of these speakers.
Safety Tips and Warnings
Do not expose these speakers to water or moisture of any kind.
They are not waterproof and exposure could result in fire, electrical
shock, and damage to the speakers and surrounding property.
Take care to ensure that the power cords do not become worn or
damaged. Inspect the power cord for damage prior to plugging it
into a live electric circuit. If the cord is damaged replace it with a
standard PC power cord (IEC 60320 C13 plug to NEMA 5-15 plug).
When plugging or unplugging the power cord, grip the connector
head and not the cord itself. Pulling on the cord can result in
damage to the cord, which could in turn lead to an electric short
and/or fire.
Never touch the power cord or speaker with wet hands or when
standing in water. Doing so could lead to electric shock.
Avoid installing or using the speakers in a humid or dusty environ-
ment.
FREQUENCY RESPONSE
RMS
OUEPUT SENSITIVIT Y
25Wx2@8
0.7V
DIMENSION(mm)
GROSS WEIGH T
0220X196X29
TREBLE CONTROL
AC POW SUPPLY E R
10db
MODEL
, b20Hz~20KHz/1W 0.5d
BASS CONTROL 10db
10.1Kg
MPA-25-BK
AC120V/50Hz~60Hz
AC120V/50Hz~60Hz
SPECIFICATIONSDIMENSION
INSTALLATION
220 mm
1 96 m m
2 90 mm
220 mm
235 mm
100 mm
AC 2 20 V~ 240 V /50 Hz ~60 Hz
10 mm 4m m
13 m m.5 12 5m m
1 2
3
Wal Wall l
Wal Wall l W all
4
Wa ll
5
1. Ensure that the mounting surface can
support the speaker weight of Speaker weight
of 22.3 lbs (10.1 Kg).
3. You can mount the bracket using the
two keyholed mounting points or with a
single screw through the hole in the
center.
4. Insert the speaker into the speaker
bracket and secure it in place using the
two bracket mounting screws.
5. Your speaker is now mounted correctly.
Repeat the process with the other
bracket and speaker.
2. Using the speaker bracket, mark the installation with a pencil. Use a
carpenter's level to ensure the bracket will be correctly aligned.
(Figure: Bracket dimensions)
Power Supply
Power Switch
R/Speaker output
Power indicator
R/S indicator
L/S indicator
Right balanced input
Mode switch
Left balanced input
3.5mm stereo jack input
L/R unbalanced input
Volume control
Treble control
Bass control
