HD Audio Converter
Incorporates HDMI® technology
HDMI I , , A O s nput to HDMI, Optical Coaxial and 3.5mm udio utput
Monoprice Product ID 10251
INTRODUCTION
The Monoprice HD Audio Converter taps into the incoming HDMI® signal to produce Digital Optical,
Digital Coaxial, and Analog 3.5mm TRS stereo audio outputs. The original, unaltered HDMI
audio/video signal is sent to your display as normal, while the audio outputs can be connected to your
home theater audio system for a superior audio experience. The converter supports all HDMI 3D
video modes and high-definition, multichannel audio, including Dolby TrueHD™ and DTS-HD Master
Audio™.
FEATURES
• Converts HDMI audio to Digital Optical Toslink, Digital Coaxial, and 3.5mm stereo TRS
outputs
• Supports all HDMI 3D video modes
Frame packing
Side-by-Side (Half)
Top-and-Bottom
1920x1080p@23.98/24Hz
1920x1080i@59.94/60Hz
1920x1080p@23.98/24Hz
1280x720p@59.94/60Hz
1920x1080i@50Hz
1280x720p@59.94/60Hz
1280x720p@50Hz
1280x720p@50Hz
• 225MHz pixel clock rate (per channel)
• 6.75Gbps total bandwidth/data throughput
• HDCP compliant
• Supports high-definition lossless compressed audio formats, including Dolby TrueHD and
DTS-Master Audio
• Gold plated connectors for smooth, corrosion-free connections

2
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed below. If
anything is missing or damaged, please contact Monoprice Customer Service for a replacement.
• 1x HD audio converter
• 1x 3.5mm to RCA adapter cable
• VDC, 1A AC adapter 1x 5
• 1x User's manual
SAMPLE CONNECTION DIAGRAMS
These sample connection diagrams illustrate typical installations using this converter.
Note: To watch 3D content, both the source device and the sink/display must support the same 3D
video modes. Please check your owner's manuals for details about the capabilities of your devices.
1. Connect to an Amplifier
2. Connect to Amplifier
(with a HDMI switcher)

3
INSTALLATION
1. Using a High Speed HDMI cable (not included) connect the HDMI output on your source
device to the port on the front of the converter. HDMI IN
2. Using a High Speed HDMI cable (not included) connect the HDMI input on your display to
the port on the back of the converter. HDMI OUT
3. (Optional) Using an Optical Toslink cable (not included) connect the optical input on your
amplifier/receiver to the port on the back of the converter. OPTICAL OUT
4. (Optional) Using a Digital Coaxial cable (not included) connect the digital coaxial input on
your amplifier/receiver to the port on the back of the converter. COAX OUT
5. (Optional) Plug the included 3.5mm to RCA adapter into the jack on the back AUDIO OUT
of the converter. Using a stereo RCA cable (not included) connect the auxiliary input jacks
on your amplifier/receiver to the RCA jacks on the 3.5mm to RCA adapter cable.
6. Set the switch on the back of the converter to the A or B position. See the Mode Operating
Modes section below for details of the two modes of operation.
7. Plug the included AC adapter into the port on the back of the converter, then plug DC 5V
the adapter into a nearby power outlet.
8. Your system should now be fully operational, with video on the display and audio on your
home theater speaker system.
OPERATING MODES
When HDMI sink (display) device is connected to a source, the source device checks the audio and
video capabilities of the sink device to determine which audio and video modes can be safely used.
The switch on the back of the converter allows you to determine the audio capability MODE
information that is sent to the source device.
Mode Select Switch
A: The capabilities of the connected sink/display device are sent to the source. In most cases,
this limits the audio output to 2-channel PCM. This is the default setting.
B: The source device is told that all available audio modes are supported. This allows you to
select advanced multichannel audio streams for playback on your home theater audio
system.
Notes:
1. When using a home theater audio system, it is recommended to mute or decrease the
volume of the TV/display so that its audio output does not degrade the audio experience
of your full home theater audio system.
2. When using Mode B, please ensure that your audio system supports the selected audio
